Page 9 of 32
7
FM/AM/SAT RADIO WITH COMPACT DISC (CD) PLAYER (Type A) (if so equipped)
1.
R
otate the TUNE SCROLL knob
4 until
“Clock Adjust” is displayed and press the
ENTER/SETTING button.
2.
Turn the TUNE SCROLL knob
4 to adjust
the hour and then press the ENTER/SETTING
button
3.
3.
Turn the TUNE SCROLL knob
4 to adjust the
minute and then press the ENTER/SETTING
button
3.
FM/AM/SAT RADIO WITH COMPACT DISC (CD) PLAYER (Type B) (if so equipped)
To adjust the time and the appearance of the clock on the display:
1.
Press the SETTING button on the
control panel.
2.
Touch the “Others” key.
3.
Touch the “Clock” key.
The following settings can be adjusted:
•
On-screen Clock: The clock in the upper
right corner of the display can be turned ON or off.
•
Clock Format (24h): The clock can be set to 12 hours or 24 hours.
•
Offset (hour): The time can be adjusted by increasing or decreasing per hour.
•
Offset (min): The time can be adjusted by increasing or decreasing per minute.
•
Daylight Savings Time: The application of Daylight Savings Time can be turned
ON or off.
•
Time Zone: Adjust the time zone. Choose a time zone from the available list.
Touch the “ BACK” key to return to the previous screen.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Monitor, heater, air conditioner, audio, phone and voice recognition
systems (section 4)” of your Owner’s Manual.
4
3
2512696_17a_Quest_US_pQRG_092016.indd 79/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 10 of 32
8
NISSAN INTELLIGENT KEY® SYSTEM
The Nissan Intelligent Key® System allows you to
lock or unlock your vehicle, open your lif tgate and
start the engine. It is important to make sure the
Intelligent Key is with you (that is, in your pocket
or purse).
The operating range of the Intelligent
Key is within 31.5 in (80 cm) from each
request switch.
To lock the vehicle, push either door handle request switch
1 or the lif tgate request
switch
2 or press the button 3 on
the key fob.
To unlock the vehicle, perform one of the following procedures:
•
Push either door hand
le request switch
1
or the lif tgate request switch
2; the
corresponding door will unlock. Push the
request switch again within 1 minute; all
other doors will unlock, or
•
Pr
ess the
button 4 on the key fob to
unlock the driver’s side door. Press the
button
4 again within 1 minute; all other
doors will unlock.
To open the power lif tgate (if so equipped), press the
button 5 for more than 1 second.
The Intel ligent Key can also be used to activate the panic alarm by pressing and
holding the
button 6 for more than 1 second. Once activated, the panic
alarm and headlights will stay on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE
If the bat tery of the Intelligent Key is
discharged or environmental conditions
interfere with the Intelligent Key
operation, start the engine according to the
following procedure:
1.
Mo
ve the shif t lever to the
P (PARK) position.
2.
Firml
y apply the foot brake.
3.
T
ouch the ignition switch with the Intelligent Key and a chime will sound.
4.
Within 10 sec
onds af ter the chime sounds, push the ignition switch
START/STOP button while depressing the brake pedal and the engine will start.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and
driving (section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.
1
3
4
5
6
FIRST DRIVE FEATURES
2
2512696_17a_Quest_US_pQRG_092016.indd 89/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 11 of 32
9
POWER SLIDING DOOR RELEASE
(if so equipped)
Use one of the following methods to open the
power sliding doors:
Press the driver’s side 1 or the passenger’s
side
2 button on the Nissan Intelligent Key®
for approximately 1 second.
From the driver’s seat, push the driver’s side
3 or passenger’s side 4 sliding door
switch for about 0.5 seconds. The switches are
located on the driver’s side instrument panel.
Pull the sliding door handle (inside or outside) until you hear the chime.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
43
1
2
2512696_17a_Quest_US_pQRG_092016.indd 99/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 12 of 32
10
FRONT POWER SEAT ADJUSTMENTS (if so equipped)
To slide the seat forward or backward, push the switch
1 forward or backward.
To adjust the angle of the seatback, push the switch
2 forward or backward.
POWER SEAT LIFTER (driver’s seat)
To raise or lower the height of the seat, push the switch 1 up or down.
To raise or lower the front portion of the seat, push the front or back end of the switch
1 up or down.
POWER LUMBAR SUPPORT (driver’s seat)
To adjust the seat lumbar area, push the front or back portion of the switch 3.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
123
POWER LIFTGATE RELEASE (if so equipped)
Use one of the following methods to open
the lif tgate:
Press the button 1 on the Nissan
Intelligent Key® for more than 1 second.
Once unlocked, push the lif tgate opener switch
2 while carrying the
Intelligent Key with you (that
is, in your pocket or purse).
From inside the vehicle, push the power lif tgate switch
3 located on the instrument
panel to the lef t of the steering wheel.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
1
3
2
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 109/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 13 of 32
11
FOLDING THE 2ND ROW SEATS
Secure the seat belts on the seat belt hooks
1 on the side wall.
To fold down the seatbacks, pull the lever
2 on the 2nd row seat.
To return the seatbacks, lif t up each
seatback and push it to the upright position
until it is latched.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your
Owner’s Manual.
1
2
2ND ROW SEAT ADJUSTMENTS
To slide the seat forward or backward, pull the lever
1 up and hold it while you
slide the seat forward or backward to the
desired position.
Release the lever 1 to lock the seat in position.
To adjust the angle of the seatback, pull the lever 2 up and lean back. To bring
the seatback forward, pull the lever up and lean your body forward.
Release the lever 2 to lock the seatback in position. Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
ENTERING/EXITING THE 3RD ROW SEATS
The 2nd row seats can tilt and slide
forward for easy entry and exit to and from
the 3
rd row seats.
To enter or exit the 3rd row seat, pull the lever
1 or 2 up to tilt down the seatback and
slide the seat forward.
Return and lock the 2nd row seats by sliding
the seats to the rearmost position and tilting
up the seatback af ter use.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your
Owner’s Manual.1
2
2
1
2512696_17a_Quest_US_pQRG_092016.indd 119/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 14 of 32
12
3RD ROW SEAT ADJUSTMENTS
To adjust the angle of the seatback, pull the strap
1 on the seatback and lean back.
Release the strap at the desired angle.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your Owner’s Manual.1
AUTOMATIC DRIVE POSITIONER (if so equipped)
Two positions for the driver’s seat and outside mirrors can be stored in the
automatic drive positioner memory.
Follow this procedure to set the memory positions:
•
C
onfirm the shif t lever is in the P (PARK) position.
•
Plac
e the ignition switch in the ON position.
•
A
djust the driver’s seat and outside mirrors to the desired positions using the
adjusting switches for each feature.
•
Push the
SET switch, and within 5 seconds, push the memory switch (1 or 2) for
at least 1 second.
• The indic
ator light on the memory switch you select will illuminate for
approximately 5 seconds.
• The driv
er’s seat and outside mirror positions are now set to your preferences.
These memoriz ed positions can also be linked to your Nissan Intelligent Key®. To
link a memorized position to your Intelligent Key, press the unlock button on the
key fob af ter completing the previous step.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
3RD ROW POWER FOLDING SEATS (if so equipped)
To fold the power 3rd row seats, push the front
side of the switch
1 located on the right
or lef t side of the cargo area. The
corresponding 3
rd row seatback will be folded
down automatically.
Push and hold the r ear side of the switch 2.
A beep will sound and the rear seatback will
rise up while you are holding the switch. A beep will sound when the seatback is
returned to its fully upright position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
12
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 129/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 15 of 32
13
OUTSIDE MIRROR CONTROL SWITCH
To select the right or lef t side mirror, turn the control switch
1 right or lef t.
To adjust the mirror angle, move the control switch
1 up, down, right or lef t.
To prevent accidentally moving the mirror, turn and set the switch to the center
(neutral) position.
REVERSE TILT-DOWN FEATURE (if so equipped)
The reverse tilt-down feature will turn both of the outside mirror surfaces downward
to provide better rear visibility close to the vehicle.
1.
Place the ignition switch in the ON position.
2.
Choose either the right or lef
t outside mirror by operating the outside mirror
control switch
1.
3.
Move the shif t lever to the R (REVERSE) position.
4.
Both outside mirror surfaces will turn downward.
The outside mirror surfaces will return to their original positions when one of the
following conditions has occurred:
•
The shif t lever is moved to any position other than R (REVERSE).
•
The outside mirror control switch is set to the center (neutral) position.
•
The ignition switch is placed in the OFF position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of
your Owner’s Manual.
1
STARTING/STOPPING THE ENGINE
It is impor tant to make sure the Nissan
Intelligent Key® is with you (that is, in your
pocket or purse).
Depress the brake pedal.
•
If the br
ake pedal is not depressed,
pushing the ignition switch once enters the
ACC mode.
•
If the ignition switch is pushed a sec
ond time, the vehicle will enter the ON mode.
Press the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF
Move the shif t lever to the P (PARK) position and apply the parking brake.
Press the ignition switch START/STOP button to turn the engine off.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2512696_17a_Quest_US_pQRG_092016.indd 139/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 16 of 32
14
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL
Turn the headlight control switch to the
position 1 to turn on the front parking,
side marker, tail, license plate and instrument
panel lights. Turn the switch to the
position
2 to turn on the headlights.
AUTOLIGHT SYSTEM (if so equipped)
The autolight system wil l automatically turn the headlights on when it is dark
and off when it is light. The system will keep the headlights on for a period of
time af ter you turn the ignition off and all doors are closed.
To activate the autolight system, turn the headlight control switch to the AUTO
position
3 then place the ignition switch in the ON position. To deactivate the
autolight system, turn the headlight control switch to the OFF position,
position 1 or position 2.
HIGH BEAM SELECT
With the he adlights ON (either in the AUTO
or
position), push the headlight control
switch forward
4 to select the high beam
function. The blue indicator light will
illuminate in the instrument panel. Pull the
headlight switch back to the original position
to select the low beam
. The blue indicator
light will extinguish.
Pull and release the headlight control switch
5 to flash the headlight high beams
on and off.
FOG LIGHT SWITCH (if so equipped)
The headlights must be on and the low beams
selected for the fog lights to operate.
Turn the switch (inside collar) to the
position
6 to turn the fog lights on.
Turn the switch (inside collar) to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL
Move the lever up or down until the turn signal begins to flash but the lever does not latch to signal a lane change. Hold the lever until the lane change is
completed.
Move the lever up or down until the turn signal begins to flash but the lever does not latch and release the lever. The turn signal will automatically flash three times.
Choose the appr opriate method to signal a lane change based on the road and
traffic conditions.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
3
2
45
6
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 149/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
