2017 NISSAN QUEST rear view mirror

12
3RD ROW SEAT ADJUSTMENTS
To adjust the angle of the seatback, pull the strap
1 on the seatback and lean back.
Release the strap at the desired angle.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your Owner’s Manual.1
AUTOMATIC DRIVE POSITIONER (if so equipped)
Two positions for the driver’s seat and outside mirrors can be stored in the
automatic drive positioner memory.
Follow this procedure to set the memory positions:



•

C
onfirm the shif t lever is in the P (PARK) position.



•

Plac
e the ignition switch in the ON position.



•

A
djust the driver’s seat and outside mirrors to the desired positions using the
adjusting switches for each feature.



•

Push the
SET switch, and within 5 seconds, push the memory switch (1 or 2) for
at least 1 second.



• The indic
ator light on the memory switch you select will illuminate for
approximately 5 seconds.



• The driv
er’s seat and outside mirror positions are now set to your preferences.
These memoriz ed positions can also be linked to your Nissan Intelligent Key®. To
link a memorized position to your Intelligent Key, press the unlock button on the
key fob af ter completing the previous step.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
3RD ROW POWER FOLDING SEATS (if so equipped)
To fold the power 3rd row seats, push the front
side of the switch
1 located on the right
or lef t side of the cargo area. The
corresponding 3
rd row seatback will be folded
down automatically.
Push and hold the r ear side of the switch 2.
A beep will sound and the rear seatback will
rise up while you are holding the switch. A beep will sound when the seatback is
returned to its fully upright position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
12
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 129/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
OUTSIDE MIRROR CONTROL SWITCH
To select the right or lef t side mirror, turn the control switch
1 right or lef t.
To adjust the mirror angle, move the control switch
1 up, down, right or lef t.
To prevent accidentally moving the mirror, turn and set the switch to the center
(neutral) position.
REVERSE TILT-DOWN FEATURE (if so equipped)
The reverse tilt-down feature will turn both of the outside mirror surfaces downward
to provide better rear visibility close to the vehicle.



1.
Place the ignition switch in the ON position.



2.

Choose either the right or lef
t outside mirror by operating the outside mirror
control switch
1.



3.

Move the shif t lever to the R (REVERSE) position.



4.

Both outside mirror surfaces will turn downward.
The outside mirror surfaces will return to their original positions when one of the
following conditions has occurred:



•

The shif t lever is moved to any position other than R (REVERSE).



•

The outside mirror control switch is set to the center (neutral) position.



•

The ignition switch is placed in the OFF position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of
your Owner’s Manual.
1
STARTING/STOPPING THE ENGINE
It is impor tant to make sure the Nissan
Intelligent Key® is with you (that is, in your
pocket or purse).
Depress the brake pedal.



•

If the br
ake pedal is not depressed,
pushing the ignition switch once enters the
ACC mode.



•

If the ignition switch is pushed a sec
ond time, the vehicle will enter the ON mode.
Press the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF
Move the shif t lever to the P (PARK) position and apply the parking brake.
Press the ignition switch START/STOP button to turn the engine off.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2512696_17a_Quest_US_pQRG_092016.indd 139/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

17
7 AIR RECIRCULATION BUTTON
Press the air recirculation button to recirculate interior air inside the
vehicle. The indicator light on the button will illuminate. This system is used to
avoid certain outside odors and to help adjust the inside vehicle temperature
more effectively.
The air recirculation mode cannot be activated when the climate control system is in the front defroster mode
FRONT or in the front defroster and
foot vent mode
.8 AUTO-RECIRCULATION BUTTON
Press the auto-recirculation button AUTO to switch to the automatic air
intake control mode. The indicator light on the button will illuminate.
In this mode, the sensor detects certain odors and gases to
automatically switch between the air recirculation mode and the outside air
circulation mode.
The auto-r ecirculation mode cannot be activated when the air flow control
is in the front defroster mode
FRONT or in the front defroster and foot
outlet mode
.9 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the front defroster button FRONT to turn the system on.
The A/C automatically turns on when the front defroster mode is selected.
This feature removes humidity from the air.
Press the temperature control buttons or to set the desired temperature.
To defrost the front and side windows quickly, set the temperature controls
and fan speed controls to their maximum settings.
10 DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS (if so equipped)
Push the r ear window defroster switch REAR to turn the system on or off.
This function automatically turns off af ter approximately 15 minutes.
11 A/C BUTTON
Press the A/C button to turn the air conditioner system on or off. This system
helps cool and dehumidify the air inside the cabin and defog the windows.
12 REAR BUT TON
To control the rear automatic air conditioning system with the front air
conditioner control panel, press the REAR button.
When the r ear automatic air conditioning
system is on, the indicator light on the REAR
button will illuminate and the front display
will switch to the rear air conditioner screen.
To adjust the front air conditioning system, press the REAR button again or wait 10 seconds.
The rear passenger controls are unavailable when REAR is shown on
the front display.
13 ON•OFF BUT TON
Press the ON•OFF button to turn the climate control system on or off.Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” and the“Monitor, heater, air
conditioner, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.
