2017 NISSAN PATHFINDER navigation

is deleted.
STORING LOCATION BY MOVING
MAP
1. Move to the preferred location on the mapand touch [].
2. Touch [Store Location]. Confirm the contentsof the message then touch [Yes].
3. The icon representing the stored location is displayed on the map.
INFO:
The address is stored in the first available
position number in the Store Location list.
STORING ROUTE
A maximum of five calculated routes can be
stored. Stored routes can be easily retrieved and
set as the suggested route.
If any waypoints are not set on the route, the
route cannot be stored.
1. Push and touch [Edit Route].
2. Touch [Store Route]. A confirmation mes- sage is displayed. Select [Yes] to store the
current route.
Other settings
A route can also be stored using the following
procedure.
1. Push .
2. Touch [Navigation] and touch [Edit/Delete Stored Locations].
3. Touch [Stored Route Plans].
4. Touch [Store Current Route]. A confirmation message is displayed.
5. Confirm the contents of the message then touch [Yes]. The current route is stored.
INFO:
. A stored route includes only locations
(destination and waypoints) and route cal-
culation conditions, not the route itself.
. The route is stored in the first available
position number in the store current route
list.
. When five routes are already stored in the
address book, a new route cannot be stored
until a route is deleted.
“Deleting stored item” (page 6-9)
6-3
6. Storing a location/route

STORING AVOID AREA
An Avoid Area can be stored. The Avoid Area is
an area that can be excluded from a route, such
as a road that is always congested. Once Avoid
Areas are stored, the system avoids those areas
when calculating a route. Up to 10 Avoid Areas
can be stored.
1. Push.
2. Touch [Navigation] and touch [Edit/Delete Stored Locations].
3. Touch [Avoid Areas].
4. Touch [Add New]. Touch the appropriate method to search for a
location.
“Destination screen” (page 4-3)
5. Adjust the location edit the contents of the Avoid area as necessary.
“Editing avoid area” (page 6-8) 6. After finishing the setting, touch [
].
INFO:
. A maximum of 10 Avoid Areas can be stored.
When 10 Avoid Areas are already stored, a
new Avoid Area cannot be stored until a
currently stored Avoid Area is deleted.
“Deleting stored item” (page 6-9)
6-4
6. Storing a location/route

EDITING STORED INFORMATION
Items stored in the system can be modified. These settings can be edited to make the navigation system more useful.
EDITING STORED HOME AND LOCATION
Step 1Step 2Step 3 Step 4 Action
1.Push.
2.Touch [Navigation].
3.Touch [Edit/Delete
Stored Locations].
4.Touch [Stored Locations].
[Sort] Sort the stored locations.
[Add New]
“Storing location by searching” (page 6-2)
[Home Location] [Edit] [Move Location] Adjust the location of the stored location.
[Phone No.] Stores the telephone number of the home location.
[Icon] Changes the icon of the home to the preferred one.
[Show Icon on Map] Displays the home icon on the map.
[Alarm Sounds] Sets the tone of the alarm that sounds when the vehicleapproaches the home.
[Alarm Direction] Sets the alarm to sound when approaching from a specific direction.
6-5
6. Storing a location/route

EDITING AVOID AREA
Step 1Step 2 Step 3 Action
1.Push.
2.Touch [Navigation].
3.Touch [Edit/Delete Stored Loca-
tions].
4.Touch [Avoid Areas].
5.Touch the preferred Avoid Area
from the list.
[Edit] [Move Location] Display the Avoid Area, and adjusts the location of the Avoid Area.
[Rename] Changes the name of an Avoid Area.
[Resize Area] Adjusts the range of the Avoid Area.
[Minimize Toll Roads] Sets the route to include or not include freeways.
[Delete] Delete an Avoid Area.
INFO:
. Touch [Add New] on the list screen to add a new avoid area.
. Touch [Map] on the list screen to display the avoid area location.
. The Avoid Area is displayed in green if it includes a freeway or in blue if it does not include a freeway.
. If the current vehicle location is set to an Avoid Area, the system will not provide route guidance.
6-8
6. Storing a location/route

EDITING STORED ROUTE
1. Push.
2. Touch [Navigation] and touch [Edit/Delete Stored Locations].
3. Touch [Stored Route Plans].
4. Touch the preferred stored route from the list.
Available setting items
. [Rename]:
Changes the stored route name.
. [Delete]:
Delete the stored route.
INFO:
Touch [Store Current Route] to store the current
route.
DELETING STORED ITEM
The locations and routes in the Address Book
can be deleted. Two deletion methods are
available: deleting an individual item and deleting
all stored items.
INFO:
. Deleted items cannot be restored. Before
deleting an item, always make sure that the
item is no longer needed.
6-9
6. Storing a location/route

DELETING STORED ITEM INDIVIDUALLY
1. Push.
2. Touch [Navigation] and touch [Edit/Delete Stored Locations].
Step 1 Step 2Step3 Action
[Delete Stored Items] [Delete Stored Loca- tions][Sort]
Sort stored locations in [By Number]/[By Name]/[By Icon]/[By Group].
[Delete All] Delete all stored locations.
[Multi Select] Delete the selected stored locations.
Touch [Select All] to select all stored locations. Touch [Clear All] to reset
the selected stored location.
Stored location list Touch the preferred item from the list, delete the selected stored location
individually.
[Delete Stored Route
Plans] [Delete All]
Delete all stored routes.
Touch the preferred item from the list. Delete the selected stored routes.
[Delete Avoid Areas] [Delete All] Delete all Avoid Areas.
Touch the preferred item from the list. Delete the selected Avoid Area.
[Reset Learned Routes] Delete the learned routes.
6-10
6. Storing a location/route

DELETING INDIVIDUAL ITEM ON
MAP
1. Align the cross pointer over the preferredstored location for deletion by moving on the
map, and then touch [
].
2. Touch [Delete Stored Location]. A confirma-tion message is displayed.
3. Touch [Yes]. The stored location is deleted from the Stored Locations.
4. Touch [
] to return to the current location.
TRANSFERRING INFORMATION
TO/FROM ADDRESS BOOK
The information of the stored home and ad-
dresses can be exported and imported using a
USB memory device.
INFO:
A USB memory device can be used to transfer
data but it is not possible to edit the data using a
personal computer, etc.
Two USB ports are located in the center console
box. Refer to the vehicle Owner’s Manual for
details.
1. Insert a USB memory device and push and touch [Navigation].
2. Touch [Edit/Delete Stored Locations] and touch [Transfer Address Book]. 3. Touch [Transfer Address Book to USB] or
[Transfer Address Book from USB].
4. Touch [All], [Home Location] or [Stored Locations].
NOTE:
Do not remove the USB memory until the
system completely imports or exports the
data.
INFO:
. If the USB memory already has the data for a
stored address, a confirmation message is
displayed. Once overwritten, the original
data cannot be recovered.
6-11
6. Storing a location/route

7 Information and settings
Information screen .................................................................... 7-2
SiriusXM Traffic information .................................................... 7-4Viewing traffic information ................................................. 7-4
Viewing available traffic information ................................ 7-4
Display urgent traffic information ..................................... 7-5
Traffic Information Settings ............................................... 7-6
Traffic information on map ................................................. 7-6
SiriusXM Travel Link
Š............................................................... 7-7
Viewing SiriusXM Travel LinkŠ......................................... 7-8
NissanConnectSMServices ................................................. 7-14
Subscription to NissanConnectSMServices ............. 7-14
Important information regarding access to
NissanConnect
SMServices ........................................... 7-14 NissanConnect
SMServices features ......................... 7-14
Connecting to Interactive Voice Menu ...................... 7-18
Setting route to a searched destination ................... 7-19
Viewing information feeds ............................................ 7-19
Emergency support ....................................................... 7-21
NissanConnect
SMServices settings ......................... 7-23
Settings screen ...................................................................... 7-24
Clock settings ................................................................. 7-26
Language setting ............................................................ 7-27
Volume settings .............................................................. 7-28
Screen Settings .............................................................. 7-29
Navigation settings ................................................................ 7-30
