8-30Maintenance and do-it-yourself
HEADLIGHTSGUID-02DF20E9-197E-4198-84C1-8F022CF37578Fog may temporarily form inside the lens of the
exterior lights in the rain or in a car wash. A
temperature difference between the inside and
the outside of the lens causes the fog. This does
not indicate that there is a malfunction. If large
drops of water collect inside the lens, contact a
GT-R certified NISSAN dealer.
ReplacingGUID-00DF49DB-1667-41BE-B931-A5B723F5290D
LED headlight:GUID-E22DEED8-E349-45C2-B1F1-0C9BCF3B8FB9If replacement is necessary, see a GT-R certified
NISSAN dealer.
EXTERIOR AND INTERIOR LIGHTSGUID-30C39BC5-0F51-49AB-82BF-6F2132601083
ItemWattage (W)Bulb No.
Headlight assembly
low-beam* LEDÐ
high-beam* LEDÐ
Front turn signal light* 28/87444NA
Front parking light* LEDÐ
Daytime running light* LEDÐ
Front side marker light* 3.8T10
Rear combination light*
back-up 16W16W
turn signal 21WY21W
stop/tail LEDÐ
Rear side marker light* LEDÐ
License plate light* 5W5W
Map light 8Ð
Vanity mirror light 2Ð
Step light* 2.7Ð
Trunk light* 3.4Ð
High-mounted stop light* LEDÐ
*: It is recommended you see a GT-R certified NISSAN dealer for replacement.
