Central lockingAutomatic locking ............................ 64
Important safety notes .................... 63
Locking/unlocking (buttons) ........... 63
Locking/unlocking (SmartKey) ........ 59
Locking/unlocking manually ............ 63
Central locking system
see Central locking
Change of address .............................. 24
Change of ownership .......................... 24
Changing bulbs
Additional indicators (roof) .............. 92
Additional turn signals ..................... 89
Backup lamp (Chassis Cab) ............. 91
Backup lamps .................................. 90
Bi-Xenon bulbs ................................. 87
Brake lamps ..................................... 90
Brake lamps (Chassis Cab) .............. 91
Cornering lamps .............................. 88
Courtesy lights ................................. 92
Daytime running lamps (halogen
headlamps) ...................................... 88
Display message ............................ 182
Front interior light ............................ 93
High-beam headlamps ..................... 88
Interior light ..................................... 93
Interior lighting ................................ 93
License plate lamp ........................... 91
License plate lamp (Chassis Cab) .... 91
Low-beam headlamps ...................... 88
Overview of lamp types (front
bulbs) ............................................... 87
Overview of lamp types (rear
bulbs, Cargo Van/Passenger
Van) ................................................. 90
Overview of lamp types (rear
bulbs, Chassis Cab) ......................... 91
Parking lamps .................................. 88
Perimeter lamp .......................... 91, 92
Rear fog lamp .................................. 90
Rear fog lamp (Chassis Cab) ............ 91
Rear interior light ............................. 93
Standing lamps (rear, Chassis
Cab) ................................................. 91
Standing lamps (rear) ...................... 90
Tail lamps ........................................ 90
T

ail lamps (Chassis Cab) .................. 91
Turn signals (front) ........................... 89 Turn signals (rear, Chassis Cab) ....... 91
Turn signals (rear) ............................ 90
Warning and indicator lamps ......... 198
see Replacing bulbs
Changing bulbs
see Replacing bulbs
Checklist
Before driving off-road ................... 136
Child
Restraint system .............................. 49
Child seat
Forward-facing restraint system ...... 51
LATCH-type (ISOFIX) child seat
anchors ............................................ 50
On the front-passenger seat ............ 51
Rearward-facing restraint system .... 51
Top Tether ....................................... 50
Child-proof locks
Important safety notes .................... 52
Rear door ......................................... 52
Children
Special seat belt retractor ............... 48
Children in the vehicle
Important safety notes .................... 47
Chock ................................................. 129
Cigarette lighter ................................ 205
Cleaning
Mirror turn signal ........................... 232
Trailer tow hitch ............................. 233
Cleaning
see Care
Climate control
Air conditioning in the rear com-
partment ........................................ 100
Air-conditioning system ................... 98
Auxiliary heating ............................ 105
Checking/cleaning the air filter
(rear-compartment air condition-
ing) ................................................ 221
Cooling with air dehumidification .. 101
Defrosting the windows ................. 102
Heating ............................................ 97
Heating in the rear compartment ..... 99
Important safety notes .................... 97
Operating the cargo compartment
air vents ......................................... 115
Overview of systems ........................ 97
Index7

Tow-starting (vehicle) ..................... 242
Engine electronics
Notes ............................................. 271
Problem (malfunction) ...................1 20
Engine oil
Adding ...........................................2 18
Additives ........................................ 278
Checking the oil level (on-board
computer) ...................................... 216
Checking the oil level using the
dipstick .......................................... 217
Display message ............................ 186
Filling capacity ............................... 278
Information about oil consump-
tion ................................................ 278
Mixing ............................................ 278
Notes about oil grades ................... 277
Oil change ...................................... 278
Oil level (note) ............................... 216
Viscosity ........................................ 277
Warning lamp ................................. 195
Engine speed setting (working
mode) ................................................. 151
Engine, jump-starting ....................... 238
ESP
®(Electronic Stability Pro-
gram)
Display message ............................ 181
Important safety information ........... 55
Indicator lamp ................................ 194
Warning lamp ................................. 190
Exhaust check ................................... 131
Exhaust gas aftertreatment
DEF level indicator ......................... 159
DEF reducing agent ....................... 275
Diesel Exhaust Fluid (DEF) ............. 275
Display messages (vehicles with
steering wheel buttons) ................. 184
Display messages (vehicles with-
out steering wheel buttons) ........... 175
Indicator lamp ....................... 193, 197
Malfunction ....................................1 84
Refilling DEF .................................. 126
Exterior lighting
see Lights
Exterior mirrors
Adjusting ......................................... 78
Important safety notes .................... 78 Eyegl
asses compartment
................. 201
F
Fire extinguisher............................... 238
First-aid kit ......................................... 237
Flat tire
Changing a wheel/mounting the
spare wheel ................................... 263
General notes ................................ 262
Fog lamps
Switching on/off .............................. 81
Fogged up-up windows
see Climate control
Folding seat ......................................... 74
Frequencies
Mobile phone ................................. 271
Two-way radio ................................ 271
Front fog lamps
Switching on/off .............................. 81
Front interior light
Replacing bulbs ............................... 93
Front windshield
see Windshield
Fuel
Additives (diesel) ........................... 274
Consumption information .............. 275
Consumption statistics .................. 171
Diesel at very low outside temper-atures ............................................ 274
Display message ............................ 185
Driving tips ....................................1 30
Fuel gauge ..................................... 159
Problem (malfunction) ................... 126
Quality (diesel) ............................... 274
Refueling ........................................ 124
Showing the range (on-board
computer with steering wheel but-
tons) .............................................. 171
Showing the range (vehicles with
steering wheel buttons) ................. 171
Tank content/reserve fuel ............. 274
Fuel filter with water separator
draining ......................................... 220
Indicator lamp ................................ 198
Fuel gauge ......................................... 159
Fuel tank
Problem (malfunction) ................... 126
Index11

Fuel tanksee Fuel tank
Fuel tank content
Reserve, display message .............. 185
Fuses .................................................. 242
G
Gasoline
Reserve fuel warning lamp ............ .196
General driving tips
Driving short distances .................. 131
Genuine parts ...................................... 29
Glove box ...........................................2 00
GTW (Gross Trailer Weight) (defini-
tion) .................................................... 260
H
Handbrake
see Parking brake
Handbrake
see Parking brake
Hazard warning lamps ........................ 83
Head restraints
Adjusting ......................................... 76
Adjusting (rear) ................................ 76
Headlamps
Adding fluid to cleaning system ..... 220
Cleaning system (function) .............. 83
Fogging up ....................................... 84
see Automatic headlamp mode
Headliner (cleaning instructions) .... 234
Heating
see Climate control
High-beam headlamps
Highbeam Assist .............................. 84
Replacing bulbs ............................... 88
Switching on/off .............................. 82
Highbeam Assist
Function/notes ................................ 84
Switching Highbeam Assist
on/off ............................................ 168
Hood
Closing ...........................................2 15
Display message ............................ 189
Important safety notes .................. 214
Indicator lamp ................................ 198 Opening ......................................... 214
Hot-water auxiliary heater
Problem (malfunction) ................... 111
Hydroplaning ..................................... 134
I
Ignition lock
see Key positions
Ignition lock
see SmartKey positions (ignition lock)
Immobilizer .......................................... 57
Indicator lamp
see Warning and indicator lamps
Indicators
see Turn signals
Insect protection on the radiator ...... 29
Installing a wheel
Installing the adapter (spare
wheel) ............................................ 265
Instrument cluster
Fuel gage ....................................... 159
Important safety notes .................. 158
Instrument cluster lighting ............. 159
Outside temperature display .......... 159
Overview .......................................... 33
Speedometer ................................. 159
Tachometer ................................... 159
Warning and indicator lamps ........... 34
Instrument cluster lighting .............. 159
Instrument lighting
see Instrument cluster lighting
Interior lighting ................................... 85
Front ................................................ 85
Motion detectors ............................. 86
Notes on replacing bulbs ................. 93
Overview .......................................... 85
Replacing bulbs ............................... 93
Switching the rear compartment
lighting on centrally ......................... 85
Interior motion sensor
Arming ............................................. 58
Deactivating ..................................... 58
Function ........................................... 58
Switching off .................................... 58
12Index

J
JackJacking points ................................ 263
Preparation .................................... 263
Storage location ............................2 36
Using ............................................. 263
Jump-starting ..................................... 238
K
Key
Position in the ignition lock ............ 117
Key positions ..................................... 117
Kickdown ...........................................1 23
L
Lamps
see Warning and indicator lamps
Lane Keeping Assist
Activating/deactivating ................. 144
Function/notes .............................1 43
Language
Display (vehicles with steering
wheel buttons) ............................... 167
Lashing points and tie downs
Permissible tensile load ................. 281
LATCH-type (ISOFIX) child seat
anchors ................................................ 50
License plate lamp
Replacing bulbs ............................... 91
License plate lamp (Chassis Cab)
Replacing bulbs ............................... 91
Light sensor ......................................... 81
Lighting
see Lights
Lights
Activating/deactivating daytime
running lamps (on-board com-
puter with steering wheel but-
tons) .............................................. 168
Activating/deactivating surround
lighting (vehicles with steering
wheel buttons) ............................... 169
Automatic headlamp mode .............. 81
Bulb failure indicator ........................ 80
Cornering light function ................... 83
Driving abroad ............................... 132 Fog lamps ........................................ 81
Hazard warning lamps ..................... 83
Headlamp range .............................. 82
High beam flasher ............................ 82
High-beam headlamps ..................... 82
Highbeam Assist .............................. 84
Important safety notes .................... 80
Light switch ..................................... 80
Low-beam headlamps ...................... 80
Parking lamps .................................. 80
Rear fog lamp .................................. 81
Setting the exterior lighting
delayed switch-off (vehicles with
steering wheel buttons) ................. 169
Switching the daytime running
lamps on/off (switch) ...................... 80
Turn signals ..................................... 82
see Changing a bulb
see Interior lighting
Limited Warranty ................................ 23
Load distribution ............................... 210
Load securing aids
Carrier systems ............................. 212
Loading gui deli
nes
Important safety notes .................. 208
Loading rails
Installing cargo tie-down rings ....... 212
Maximum tensile strength ............. 282
Loads
Securing ........................................ 210
Transporting .................................. 208
Locator lighting
Setting (vehicles with steering
wheel buttons) ............................... 169
Locking
see Central locking
Locking and unlocking manually ....... 63
Locking centrally
see Central locking
LOW RANGE ....................................... 145
LOW RANGE transmission ratio ....... 145
Low-beam headlamps
Display message ............................ 182
Driving abroad ............................... 132
Replacing bulbs ............................... 88
Switching on/off .............................. 80
Lumbar support ................................... 73
Index13

R
Radiator cover..................................... 29
Radio
Changing stations (vehicles with
steering wheel buttons) ................. 164
see separate operating instructions
Radio-wave reception/transmis-
sion in the vehicle
Declaration of conformity ................ 27
Rain and light sensor
Setting the sensitivity (vehicles
with steering wheel buttons) ......... 170
Windshield wiper .............................. 94
Range (vehicles with steering
wheel buttons) .................................. 171
Rear bench seat
Installing/removing (Passenger
Van) ................................................. 75
Stowage compartment (crewcab) .. 203
Rear compartment
Activating/deactivating climate
control ........................................... 100
Setting the air vents ...................... 105
Rear door
Child-proof locks .............................. 52
Important safety notes .................... 67
Opening/closing .............................. 67
Opening/closing from inside ........... 69
Rear fog lamp
Replacing bulbs ............................... 90
Switching on/off .............................. 81
Rear fog lamp (Chassis Cab)
Replacing bulbs ............................... 91
Rear interior light
Replacing bulbs ............................... 93
Rear lamps
see Lights
Rear rack
Notes ............................................. 212
Rear view camera
Cleaning instructions ..................... 232
Important safety notes .................. 151
Switching on .................................. 151
Rear window defroster
Problem (malfunction) ................... 103
Switching on/off ........................... 103 Rear window wiper
............................. 95
Switching on/off .............................. 95
Rear-compartment air-condition-
ing system
see Climate control
Rear-compartment heating
see Climate control
Rear-view mirror
Anti-glare mode ............................... 78
Refilling
DEF filler neck ............................... 126
Important safety notes (Diesel
Exhaust Fluid – DEF) ...................... 126
Refilling procedure (Diesel
Exhaust Flu id – DEF) ...................... 126
Re

frigerant ......................................... 281
Refueling
Fuel filler flap ................................. 125
Fuel gauge ..................................... 159
Important safety notes (fuel) ......... 124
Refueling procedure (fuel) ............. 125
see Fuel
Releasing the parking lock man-
ually (automatic transmission) ........ 124
Remote control
Changing the operating duration
(auxiliary heating) .......................... 109
Replacing the battery (auxiliary
heating ) ........................................ 110
Switching on/off (auxiliary heat-
ing) ................................................ 109
Synchronizing (auxiliary heating) ... 109
Replacing bulbs
Important safety notes .................... 87
Replacing the battery (auxiliary
heating remote control) .................... 110
Replacing the fuel filter .................... 198
Reporting safety defects .................... 28
Rescue card ......................................... 30
Restraint system
Introduction ..................................... 40
Warning lamp (function) .......... 40, 194
Reverse warning feature .................. 119
Roadside Assistance (breakdown) .... 24
Roof carrier
Maximum payload .......................... 282
Notes ............................................. 212
16Index

Useful information
This Operator's Manual describes all models as
well as standard and optional equipment of your
vehicle that were available at the time of going
to print. Country-specific variations are possi-
ble. Note that your vehicle may not be equipped
with all of the described functions. This also
applies to systems and functions relevant to
safety.
Read the information on qualified specialist
workshops (
Ypage 27).
Exterior lighting
Important safety notes
For reasons of safety, we recommend that you
drive with the lights switched on even during the
daytime. There may be differences in operation
due to legal requirements and voluntary recom-
mendations in some countries.
Bulb failure indicator
The bulb failure indicator is only an aid. You are
responsible for the proper functioning of the
vehicle lighting. Insufficient or non-functioning
vehicle lighting puts the operating safety of the
vehicle at risk.
For this reason, check the condition and func-
tion of your vehicle's lighting system and, if nec-
essary, that of the trailer before each journey.
The bulb failure indicator monitors all of the
exterior lighting lamps, except the perimeter
lamp and the trailer lighting. If a bulb fails, either
the b(
Ypage 34) indicator lamp lights up, or
you will see a corresponding message in the
display (
Ypage 182).
iDepending on the equipment, the bulb fail-
ure indicator can fail for all lamps with the
exception of the turn signal lamps.
Light switch
Operation
1 ÃAutomatic headlamp mode/daytime
running lamps
2$Lights off
3TParking lamps, license plate and
instrument lighting
4LLow-beam/high-beam headlamps
5NFog lamps
6RRear fog lamp
If you hear a warning tone when you leave the
vehicle, the lights may still be switched on.
XTurn the light switch to $orÃ.
or
XIf the rear fog lamp is switched on: press the
light switch in to the stop.
The turn signals, high-beam headlamps and the
high-beam flasher are operated using the com-
bination switch (
Ypage 82).
Low-beam headlamp
XTo switch on: turn the key to position 2in the
ignition lock or start the engine.
XTurn the light switch to position L.
The L indicator lamp in the instrument
cluster lights up.
Daytime running lamps
You can activate/deactivate the daytime run-
ning lamps function using the on-board com-
puter.
This is not possible in countries where daytime
running lamps are a legal requirement.
80Exterior lighting
Lights and windshield wipers

Changing bulbs
Important safety notes
GDANGER
Xenon bulbs carry a high voltage. You can get an electric shock if you remove the cover of
the Xenon bulb and touch the electrical con-
tacts. There is a risk of fatal injury.
Never touch the parts or the electrical con-
tacts of the Xenon bulb. Always have work on
the Xenon bulbs carried out at a qualified spe-
cialist workshop.
GWARNING
Bulbs, lamps and connectors can get very hot
when operating. If you change a bulb, you
could burn yourself on these components.
There is a risk of injury.
Allow these components to cool down before
changing a bulb.
!Make sure the bulbs are always securely
installed.
If your vehicle is equipped with Bi-Xenon bulbs,
you can recognize this by the following: the cone
of light from the Xenon bulbs moves from the
top to the bottom and back again when you start
the engine. For this to be observed, the low-
beam headlamps must be switched on before
starting the engine.
The bulbs and lamps are an essential compo-
nent of vehicle safety. You must therefore make
sure that these function correctly at all times.
Have the headlamp setting checked regularly.
RAlways switch off the vehicle's lighting sys-
tem before changing a bulb.
This will prevent a short circuit.
RDo not touch the glass tube of new bulbs with your bare hands. Always use a clean, lint-free
cloth or only touch the base of the bulb when
installing.
Even minor contamination can burn into the
glass surface and reduce the service life of the
bulbs.
RDo not use a bulb that has been dropped or
that has scratches on its glass tube.
The bulb could explode.
ROnly use bulbs in closed lamps which have
been designed for this purpose.
ROnly use spare bulbs of the same type and
with the prescribed voltage
RProtect the bulbs from moisture when in use.
If the new bulb still does not light up, consult a
qualified specialist workshop.
RHave the LEDs and bulbs of the following
lamps changed at a qualified specialist work-
shop:
-the additional turn signals in the exterior
mirrors
-the high-mounted brake lamp
-LED daytime running lamps (Bi-Xenon
headlamps)
-Bi-Xenon lamps (Bi-Xenon headlamps)
-front fog lamps
If you require assistance changing bulbs, con-
sult a qualified specialist workshop.
Front bulbs
Overview of bulb replacement – bulb
types
The following bulbs can be replaced. Bulb types can be found in the legend.
Vehicle swit hhalogen headlamps
:
Turn signal: PY21W
;Daytime running lamps: W21W
=Low-beam headlamps: H7 55W
?High-beam headlamps: H7 55W
AParking lamps/standing lamps: W5W
Changing bulbs87
Lights and windshield wipers
Z

Rear bulbs (Cargo Van/Passenger
Van)
Overview of bulb types
LightsBulb type
:High-mounted brake
lampLED
;Brake lamp/tail lampP21W/5W
=Turn signal lampsPY 21 W
?Tail lamps/standing
lampsR5W
ALicense plate lampW5W
BRear fog lamps (driver's
side)P21W
CBackup lampsP21W
Tail lamps
XSwitch off the lighting system.
XOpen the rear door.
XUndo screws :and unclip the lamp lens in
the direction of the arrow.
XPull the connector off the bulb holder.
;Retaining lugs
=Brake lamps
?Turn signal lamps
AStanding lamp/tail lamp
BBackup lamps
CRear fog lamp
90Changing bulbs
Lights and windshield wipers
