2017 MAZDA MODEL CX-3 bluetooth

5–114
Interior Features
Audio Set [Type B (touchscreen)]
*Some models.
Available Language *
The language can be changed.
Refer to Settings on page 5-139 .
NOTE
Depending on the language, it may only
be available for the screen display, but
not for the voice recognition.
Bluetooth ® Audio
Applicable Bluetooth ® speci¿ cation
(Recommended)
Ver. 1.1/1.2/2.0
EDR/2.1 EDR/3.0
(conformity)
Response pro¿ le




 A2DP (Advanced Audio Distribution
Pro¿ le) Ver. 1.0/1.2




 AVRCP (Audio/Video Remote Control
Pro¿ le) Ver. 1.0/1.3/1.4


A2DP is a pro¿ le which transmits only
audio to the Bluetooth
® unit. If your
Bluetooth ® audio device corresponds
only to A2DP, but not AVRCP, you
cannot operate it using the control panel
of the vehicle's audio system. In this
case, only the operations on the mobile
device are available the same as when a
portable audio device for a non-compliant
Bluetooth
® device is connected to the
AUX terminal.

Function A2DP AVRCP
Ver. 1.0 Ver. 1.3 Ver. 1.4
Playback X X X X
Pause X X X X
File (Track)
up/down — X X X
Reverse — — X X
Fast-forward — — X X
Text display — — X X
Repeat — —
Depends
on device Depends
on device
ShufÀ e — — Depends
on device Depends
on device
Scan — — Depends
on device Depends
on device
Folder up/
down — — — Depends
on device
X: Available
—: Not available

5–115
Interior Features
Audio Set [Type B (touchscreen)]
NOTE
  The battery consumption of
Bluetooth ® audio devices increases
while Bluetooth ® is connected.   If a general mobile phone device
is USB connected during music
playback over the Bluetooth
®
connection, the Bluetooth ®
connection is disconnected. For
this reason, you cannot have
music playback over a Bluetooth
®
connection and music playback using
a USB connection at the same time.
  The system may not operate
normally depending on the
Bluetooth
® audio device.

5–116
Interior Features
Audio Set [Type B (touchscreen)]
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded to a Bluetooth ® audio device, switch to the
Bluetooth ® audio mode to operate the audio device using the audio system control panel.
Any Bluetooth ® audio device must be paired to the vehicle's Bluetooth ® unit before it can be
used.
Refer to Bluetooth
® Preparation (Type B) on page 5-111 .
1. Turn on the Bluetooth ® audio device's power.
2. Switch the ignition to ACC or ON.
3. Select the
icon on the home screen to display the Entertainment screen.
4. When
is selected, switches to the Bluetooth ® audio mode to begin playback.
NOTE
  If Bluetooth ® audio is used after using Aha™ or Stitcher™ radio, the application on the
mobile device has to be closed ¿ rst.

 If the Bluetooth ® audio device does not begin playback, select the icon.
 If the mode is switched from Bluetooth ® audio mode to another mode (radio mode),
audio playback from the Bluetooth ® audio device stops.

5–117
Interior Features
Audio Set [Type B (touchscreen)]
Playback
To listen to a Bluetooth ® audio device over the vehicle's speaker system, switch the mode to
Bluetooth ® audio mode. (Refer to “Switching to Bluetooth ® audio mode”)
After switching to the Bluetooth ® audio mode, the following icons are displayed in the
lower part of the display. Icons which can be used differ depending on the version of the
Bluetooth
® audio device which you are currently using.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

(AVRCP Ver. 1.4 only)
Displays the top level folder/¿ le list.
Select the folder which you want to select.
The ¿ les in the selected folder are displayed.
Select the ¿ le you want to play.

(AVRCP Ver. 1.3 or higher)
Replays the song currently being played repeatedly.
When selected again, the songs in the folder are played repeatedly.
Select it again to cancel.
Icons change when the song is repeated or the folder is repeated.

(AVRCP Ver. 1.3 or higher)
Plays songs in the folder in random order.
When selected again, the songs on the device are played in random order.
Select it again to cancel.
Icons change during folder shufÀ e or device shufÀ e.

Scans the titles in a folder and plays the beginning of each song to aid in ¿ nding a desired
song.
When selected again, the beginning of each song on the device is played.
When selected again, the operation is cancelled and the song currently being played
continues.

Returns to the beginning of the previous song.
Long-press to fast reverse. It stops when you remove your hand from the icon or the
commander knob.

Plays the Bluetooth
® audio. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song.
Long-press to fast forward. It stops when you remove your hand from the icon or the
commander knob.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-86 .

5–118
Interior Features
Audio Set [Type B (touchscreen)]
Bluetooth ® Audio Device
Information Display
If a Bluetooth ® audio device is connected,
the following information is displayed in
the centre display.

AVRCP
Ve r. l o w e r
than 1.3 AVRCP
Ver. 1.3 AVRCP
Ver. 1.4 or
higher
Device name X X X
Remaining
battery
charge of
device X X X
Song name — X X
Artist name — X X
Album name — X X
Playback
time — X X
Genre name — X X
Album art
image — — —
X: Available
—: Not available

NOTE
Some information may not display
depending on the device, and if the
information cannot be displayed,
“Unknown - - -” is indicated.

5–119
Interior Features
Audio Set [Type B (touchscreen)]
How to Use Aha™
What is Aha™?
A h a *1 is an application which can be used to enjoy various Internet content such as Internet
radio and podcasts.
Stay connected to your friends activities by getting updates from Facebook and Twitter.
Using the location-based service, nearby services and destinations can be searched or real-
time local information can be obtained.
For details on Aha, refer to “http://www.aharadio.com/”.

*1 Aha, the Aha logo, and the Aha trade dress are trademarks or registered trademarks of
Harman International Industries, Inc., used with permission.

NOTE
  The service content provided by Aha varies depending on the country in which the user
resides. In addition, the service is not available in some countries.
  To operate Aha from your Bluetooth ® device, perform the following in advance:



 Install the Aha application to your device.



 Create an Aha account for your device.



 Log onto Aha using your device.



 Select the preset station on your device.

5–123
Interior Features
Audio Set [Type B (touchscreen)]
How to Use Stitcher™ Radio
What is Stitcher™ Radio?
Stitcher™ *1 radio is an application which can be used to listen to Internet radio or stream
podcasts.
Recommended content is automatically selected by registering content which you put into
your favourites, or by pressing the Like or Dislike button.
For details on Stitcher
™ Radio, refer to “http://stitcher.com/”.
*1 Stitcher™, the Stitcher™ logo, and the Stitcher™ trade dress are trademarks or registered
trademarks of Stitcher, Inc., used with permission.

NOTE
To operate Stitcher™ Radio from your Bluetooth ® device, perform the following in
advance:

 Install the Stitcher™ Radio application to your device.
 Create a Stitcher™ Radio account for your device.
 Log onto Stitcher™ Radio using your device.

5–126
Interior Features
Audio Set [Type B (touchscreen)]
Add to your favourites
If the current programme has not been
registered to your favourites, it can be
registered to your favourites.

1. Select the icon to display the
favourites station which the registration
can be added.
2. Select the station name which you want
to register.
3. Select
to add the programme to the
selected favourites station.

NOTE
  Multiple favourites stations can be
selected and registered.
  Favourites stations registered by
oneself as well those set by default
are displayed.
Delete from your favourites
If the current programme has already
been registered to your favourites, the
programme can be deleted from your
favourites.

1. Select the icon.
2. The programme is automatically
deleted from the favourites station.

Bluetooth ® Hands-Free
Making a Call
Phonebook Usage
Telephone calls can be made by saying
the contact name in the downloaded
phonebook or the name of a person whose
phone number has been registered in the
Bluetooth
® Hands-Free. Refer to Import
contact (Download Phonebook).

1. Press the talk button.
2. Wait for the beep sound.
3. Say: “Call XXXXX... (Ex. “John”)
Mobile”.
4. Follow the voice guidance to place the
call.

Screen operation
1. Select the
icon on the home screen
to display the Communication screen.
2.
Select to display the contact list.
3. Select the contact you would like
to call to display the details for the
contact.
4. Select the desired phone number to
make the call.

Import contact (Download Phonebook)
Phonebook data from your device (Mobile
phone) can be sent and registered to your
Bluetooth
® Hands-Free phonebook using
Bluetooth ® .
(Automatic downloading)
The “Auto Download Contacts”
setting must be on. When hands-free is
connected to the device, the phonebook is
downloaded automatically.
Refer to Communication Settings on page
5-135 .
