2017 MAZDA MODEL CX-3 navigation

5–120
Interior Features
Audio Set [Type B (touchscreen)]
Playback
Select the icon on the home screen to display the Entertainment screen. When is
selected, the following icons are displayed at the bottom of the centre display. The displayed
icon differs depending on the selected station.
In addition, icons other than the following icons may be displayed.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the main menu.
Use to switch to other stations.

Displays the content list.
Use to switch to other desired content on the station.

Shout
Records voice.
Records voice and posts it as playable audio to Facebook and other social stations.

Like
*1

Evaluates the current content as “Like”.

Dislike
*1

Evaluates the current content as “Dislike”.

Reverses for 15 seconds.

Map (vehicles with navigation system)
Displays the destination searched by the location based services on the navigation system.

Call
A call can be made to the telephone number of a shop searched using the Location Based
Services. Available when a device is connected as a Hands-Free.

Returns to the previous content.

Pauses playback of the content. When selected again, playback resumes.

Goes to the next content.

5–122
Interior Features
Audio Set [Type B (touchscreen)]
Example of use (Location Based
Services)
1. Select the desired station from the
“Nearby” tab on the main menu.
The destination name or address
playback starts in the order of the
destination name list.


2. When the
icon is selected, the
currently displayed destination is
displayed on the navigation system
(vehicles with navigation system).
3. When the
icon is selected, a phone
call is placed to the currently displayed
destination.
4. Select the
icon to display the
content list.
Selection of other destinations from the
list can be made.


Shout
Some social stations, such as Facebook or
Caraoke, support the ability to record and
share voice messages using the “Shout”
function.

1. Select the icon and start the
countdown (3, 2, 1, 0). Recording starts
when the countdown reaches zero.
2. Records voice.
3. Select
and store/post the
recording.

NOTE
  Recordable time varies depending on
the station (Max. 30 seconds).
  Recording stops automatically when
the recordable time has elapsed. You
can then post or delete the recording.

5–137
Interior Features
Audio Set [Type B (touchscreen)]
Voice Command List
Voice command
When the talk button is pressed and the following command is spoken, the audio or
navigation can be operated. The commands in the () can be omitted. The speci¿ ed name and
number are put into the {}.
Standard command
Voice command Function
cancel Ends the voice recognition mode.
(go) back Returns to the previous operation.
help Usable commands can be veri¿ ed.
tutorial Basic voice commands and methods of use can be veri¿ ed.
(go to) home (screen)/main menu Moves to the home screen.
(go to) communication Moves to the communication screen.
(go to) navigation Moves to the navigation screen.
(go to) entertainment (menu) Moves to the entertainment screen.
(go to) settings Moves to the setting screen.
(go to) favourites Moves to the favourites screen.

Communication (phone) related command
Voice command Function
Call {name in phonebook} (mobile/
home/work/other)
Example: “Call John Mobile” Call to the contact in the downloaded phonebook.
Refer to Making a Call on page 5-126 .
Redial Call to the last contact you called.
Refer to Making a Call on page 5-126 .
Callback Call to the last contact who called you.
Refer to Making a Call on page 5-126 .

5–138
Interior Features
Audio Set [Type B (touchscreen)]
Entertainment (audio) related command
Voice command Function Corresponding audio
source
(Go to/Play) AM (Radio) Switches the audio source to AM radio. All
(Go to/Play) FM (Radio) Switches the audio source to FM radio. All
(Go to/Play) Bluetooth (Audio) Switches the audio source to BT audio. All
(Go to/Play) Aha (Radio) Switches the audio source to Aha
™ Radio. All
(Go to/Play) Stitcher Switches the audio source to Stitcher™ Radio. All
(Go to/Play) USB 1 Switches the audio source to USB 1. All
(Go to/Play) USB 2 Switches the audio source to USB 2. All
Play Playlist {Playlist name} Plays the selected playlist. USB
Play Artist {Artist name} Plays the selected artist. USB
Play Album {Album name} Plays the selected album. USB
Play Genre {Genre name} Plays the selected genre. USB
Play Folder {Folder name} Plays the selected folder. USB

Navigation related command
For the navigation screen voice commands, refer to the separate navigation system manual.
NOTE
  Some commands cannot be used depending on the grade and speci¿ cation.
 Some commands cannot be used depending on the device connection conditions and
the use conditions.
  The commands are examples of the available commands.

7–2
If Trouble Arises
Mazda ERA-GLONASS (Russia)
Mazda ERA-GLONASS
The Mazda ERA-GLONASS is available only in Russia.
When an emergency situation such as an accident or sudden illness occurs, the Mazda ERA-
GLONASS dials the call centre automatically or the user can make a call to the call centre
manually to enable a voice call.
The system operates automatically when the vehicle receives an impact of a certain level or
more in a collision, or it can be operated manually using the Mazda ERA-GLONASS switch
if an emergency situation arises such as sudden illness.
The call centre operator con¿ rms the status via the voice call, con¿ rms the vehicle's position
information using the GPS/GLONASS
*1 , and calls the police or emergency services.
*1 GPS/GLONASS, short for “Global Positioning System/Global Navigation Satellite
System”, is a system that obtains the vehicle's current location by receiving radio waves
emitted from the GPS/GLONASS (operated by the Russian Federation) satellites to the
ground.


Status information
Emergency vehicle Dial &
Position
information
Position Satellite
Mobile phone
base station
Emergency situation occursCall centre
Police and emergency
services

8–4
Customer Information
Cell Phones
Cell Phones Warning
WARNING
Please comply with the legal regulations concerning the use of communication
equipment in vehicles in your country:
Use of any electrical devices such as cell phones, computers, portable radios, vehicle
navigation or other devices by the driver while the vehicle is moving is dangerous.
Dialing a number on a cell phone while driving also ties-up the driver's hands. Use of
these devices will cause the driver to be distracted and could lead to a serious accident.
If a passenger is unable to use the device, pull off the right-of-way to a safe area before
use. If use of a cell phone is necessary despite this warning, use a hands-free system
to at least leave the hands free to drive the vehicle. Never use a cell phone or other
electrical devices while the vehicle is moving and, instead, concentrate on the full-time
job of driving.

9–17
Speci¿ cations
Personalisation Features
Item Feature Factory
Setting Available
Settings Settings
Change
Method


Active Driving Display (page 4-33 )
Display Setting can be changed so that the Active
Driving Display is not displayed. On On/Off C —


The display height (up/down position) can be
changed. 0 13 steps up/
down from
initial setting
(total: 27
steps) C —


The method for adjusting the display
brightness (automatically/manually) can be
changed. AUTO AUTO/
MANUAL C —


The standard brightness while automatic
adjustment is selected can be changed using
the brightness adjustment. 0 2 steps up/
down from
initial setting
(total: 5
steps) C —


The standard brightness while manual
adjustment is selected can be changed using
the brightness adjustment. 0 20 steps up/
down from
initial setting
(total: 41
steps) C —


Navigation guidance The display information can be changed. Adaptive
Lane/Street/
Turn Adaptive
Lane/Street/
Turn
Lane
Guidance &
Turn by Turn
Street Name
& Turn by
Turn
OFF C —


*1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends
that these systems remain On.
*2 For vehicles with an audio system other than the on-screen function type, the warning sound cannot be changed.
The warning sound is only a beep.
*3 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. The
volume of the warning beep during Rear Cross Traf¿ c Alert (RCTA) operation cannot be changed.
*4 This system functions only when the navigation system is functioning.
*5 If the auto-wiper control is set to Off, the wiper lever
position is set to intermittent operation.
*6 The operation may stop in 15 minutes due to the effect of the outside temperature even if the operation time of
the rear window defogger has been changed to Continuous.
*7 Available only in display from the centre display.
