2017 KIA RIO Features and Functions Guide

GETTING TO KNOW YOUR RIO
Congratulations on Your New Kia Purchase!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable
driving. Kia is committed to quality, innovation, safety and — above all — your satisfaction.

Using This Guide
The information contained in this guide is a brief overview that will help you become familiar with the operation and features of your new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations help to ensure the instructions are easy to follow.
This Features & Functions Guide, and the specific operational and safety information it provides, is not a substitute for your Owner’s Manual. In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury, Kia reminds you to carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle specifications without notice in advance or after the fact, and assumes no liability in connection with such changes.
www.kia.com
Consumer - Roadside Assistance 1-800-333-4KIA (4542)
See Back Pages for Vehicle Maintenance Schedule Always check the Owner’s Manual for complete operating information and safety warnings.

Air Conditioning / Climate Control . . . . . . . . . . . . . . . . . .23
Active ECO System* . . . . . . . . . . . . . . . . . . . . . . . . . . . .08
Audio System - Standard Audio System ( Type A)* . . . . . .19
Audio System - Standard Audio System ( Type B)* . . . . . .20
Audio System - UVO eServices System* . . . . . . . . . . . . .21
Audio System - UVO eServices with Navigation* . . . . . . .22
Aux/USB/iPod® Port & Power Outlets* . . . . . . . . . . . . . . .23
Bluetooth® Wireless Technology* . . . . . . . . . . . . . . . . . . .16
Cruise Control* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Digital Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Folding Rear Seatback . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Idle, Stop and Go (ISG) System* . . . . . . . . . . . . . . . . . . . .09
Manual Gear Shift* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Passenger Airbag Off Indicator . . . . . . . . . . . . . . . . . . . .35
Smart Key* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Tire Mobility Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Tire Pressure Monitoring System (TPMS) . . . . . . . . . . . .05
Windshield/Rear Wipers & Washers* . . . . . . . . . . . . . . . .14
VIDEOS & QR CODES . . . . . . . . . . . . . . . . . . . . . . .02
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . . . . . . . . . . . . . .03
Indicators & Warning Lights . . . . . . . . . . . . . . . . . . . . . . . .04
Tire Pressure Monitoring System (TPMS) . . . . . . . . . . . . . .05
Trip Computer / Tripmeter . . . . . . . . . . . . . . . . . . . . . . . . . .06
Instant Fuel Consumption Mode . . . . . . . . . . . . . . . . . . . . .06
Fuel Economy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06
User Settings* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07
Service Mode (Maintenance)* . . . . . . . . . . . . . . . . . . . . . .07
Active ECO System* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .08
DRIVER’S PANEL
Idle, Stop and Go (ISG) System* . . . . . . . . . . . . . . . . . . . . .09
Instrument Panel Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . .10
Electronic Stability Control (ESC) . . . . . . . . . . . . . . . . . . . .10
Hill-Start Assist Control (HAC) . . . . . . . . . . . . . . . . . . . . . . .10
Power Windows, Window Lock & Central Door Lock* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Power/Heated Outside Mirrors*
. . . . . . . . . . . . . . . . . . . . . .11
Power Folding Outside Mirrors* . . . . . . . . . . . . . . . . . . . . .11
Engine Start/Stop Button* . . . . . . . . . . . . . . . . . . . . . . . . . .12
STEERING WHEEL CONTROLS
Headlights & High Beams . . . . . . . . . . . . . . . . . . . . . . . . . .13
Turn Signals & Fog Lights* . . . . . . . . . . . . . . . . . . . . . . . . .13
Windshield Wipers & Washers . . . . . . . . . . . . . . . . . . . . . . .14
Rear Wiper & Washer* . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Tilt/ Telescoping Steering Wheel* . . . . . . . . . . . . . . . . . . . .15
Bluetooth® Wireless Technology* . . . . . . . . . . . . . . . . . . . .16
Audio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Cruise Control* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
AUDIO SYSTEMS
Standard Audio System ( Type A)* . . . . . . . . . . . . . . . . . . . .19
Standard Audio System ( Type B)* . . . . . . . . . . . . . . . . . . . .20
UVO eServices System* . . . . . . . . . . . . . . . . . . . . . . . . . . .21
UVO eServices with Navigation* . . . . . . . . . . . . . . . . . . . . .22
CENTER PANEL
Digital Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Aux/USB/iPod® Port & Power Outlets . . . . . . . . . . . . . . . . .23
Manual Climate Control . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Automatic Gear Shift / Sportmatic® Shifting* . . . . . . . . . . .25
Manual Gear Shift* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
S E AT I N G
Seat Warmers* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
6-Way Adjustable Driver’s Seat . . . . . . . . . . . . . . . . . . . . . .27
Front Seat Headrest Adjustment . . . . . . . . . . . . . . . . . . . . .27
Folding Rear Seatback . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
OTHER KEY FEATURES
Smart Key* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Remote Keyless Entry (Folding Key)* . . . . . . . . . . . . . . . . .30
Double-Turn Lock /Unlock All* . . . . . . . . . . . . . . . . . . . . . . .30
Fuel Cap / Malfunction Indicator . . . . . . . . . . . . . . . . . . . . .30
Hood Release Lever and Latch . . . . . . . . . . . . . . . . . . . . . .31
Fuel Door Release Lever . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Trunk Release Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Map/Room Lamps* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Sunroof Operation* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Rear-Camera Display* . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Child Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Tire Mobility Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
SAFETY FEATURES
Occupant Detection System (ODS)/ Passenger Airbag Off Indicator . . . . . . . . . . . . . . . . . . . . . .36
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Seat Belt Retractor Locks . . . . . . . . . . . . . . . . . . . . . . . . . .36
NORMAL MAINTENANCE SCHEDULE . . . . .37
LEGAL DISCLAIMERS (See Back Inside Cover Page)
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe personal injury and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or that are not permissible by law should never be used during operation of the vehicle.
RIO FE ATURES & FUNCTIONS GUIDE*IF EQUIPPED
ESSENTIAL FEATURES

2
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS
One Click Fuel Cap Video To view a video on your mobile device, snap this QR Code or visit the listed website .
www.KuTechVideos.com/ub13/2017
QR CODEKia provides a number of video resources at your disposal to assist you with becoming familiar with the features and
functions found in your Kia vehicle . You can access these resources by snapping the QR Codes with your smartphone/tablet
(mobile devices) or by visiting the following website: www.KuTechVideos.com/ub13/2017. Continue reading for a more
in-depth look at QR Codes and for instructions on how to use them .
REMINDER: When accessing videos on your mobile device, standard cellular data rates may apply .
What are QR Codes?
A QR Code is a square, 2-dimensional barcode that can be
read by mobile devices loaded with an appropriate barcode
or QR Code Reader App . The app reads the barcode image
and then launches/uploads the specific information the
code contains, such as URLs, text, photos, videos and so
much more .
How to Use QR Codes
If you have a mobile device with a QR Code Reader App, you
can snap the code with your phone and you’ll be provided a
video with additional information pertaining to the topic . For
example, in the Fuel Cap section, if you would like additional
information, just snap the code with your mobile device to
view the selected Kia Features & Functions Video .
How to snap a QR Code
1 . With your mobile device, download a QR Code Reader
App . With many devices, you can do this through an app
store or marketplace
2 . Open the QR Code Reader App on your mobile device
3 . The app will utilize your device’s camera . Center the
code in the camera viewing area:
• With some apps, as soon as the app recognizes the
code, it will launch the corresponding video
• With other apps, you will have to snap or take a
picture of the code . The app will then launch the
corresponding video
• For operation specifics, refer to the instructions that
come with the QR Code Reader App
1 . If you’re having trouble scanning codes, check the following: •The code should be centered and focused in your mobile device’s camera screen •Consider moving your device closer to or farther away from the code •The code should be well lit, without significant shadow
2 . After scanning, if a “connecting” message appears and then nothing happens or there’s a “connection error” message, this typically indicates that your device is having trouble connecting to the Internet
3 . When accessing videos on your mobile device, standard cellular data rates will apply
QUICK TIPS
•Avoid scanning from a significant angle •Confirm that the device’s app supports 2D QR Code scanning •Try another QR Code Reader App; not all apps are created equal
RIO FEATURES & FUNCTIONS GUIDE
*IF EQUIPPED

3
(Type A cluster)*
A
Instrument Cluster Overview
A Tachometer
B Turn Signal Indicators
C Speedometer
D Warning and Indicator Lights
E Gear Shift Position Indicator
F Odometer
G Trip Computer
H Fuel Gauge
I Engine Coolant Temperature Gauge
REMINDERS:
• Your vehicle’s instrument cluster & indicator light locations may differ from those in the illustrations
• For more information on the instrument cluster and the function of all indicator and warning lights, please refer to the Owner’s Manual
C
G
F
B
H
I
EBD
D
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER

4
Low Fuel Level Warning Light
ECOMINDER® Indicator*
Low Tire Pressure Light
Engine Coolant Temperature Warning Light
Anti-lock Braking System (ABS) Warning Light*
Parking Brake & Brake Fluid Warning Light
Door Ajar Warning Light
Electronic Brake Force Distribution (EBD) System Warning Light
Immobilizer Indicator*
Engine Oil Pressure Warning Light
Airbag Warning Light
Malfunction Indicator
Seat Belt Warning Light
Electric Power Steering (EPS) System Warning Light*
Charging System Warning Light
Auto Stop (ISG system) Indicator*
Tail Light Indicator
Front Fog Light Indicator
High Beam Indicator
Trunk /Hatch Open Warning Light*
Cruise Control Indicator*
Cruise SET Indicator*
Electronic Stability Control (ESC) Indicator*
Electronic Stability Control (ESC) OFF Indicator*
REMINDERS:
• Your vehicle’s instrument cluster & indicator light locations may differ from those in the illustrations
• For more information on the instrument cluster and the function of all indicator and warning lights, please refer to the Owner’s Manual
Indicators & Warning Lights
(Type B cluster)*
RIO FEATURES & FUNCTIONS GUIDE
*IF EQUIPPED
INSTRUMENT CLUSTER

5

•Even with TPMS, tire pressure should be checked manually at least once a month . Only adjust Tire Pressure on “cold tires” •For proper maintenance, safety and optimal fuel economy, maintain recommended tire inflation pressures and stay within the load limits and weight distribution recommended for your vehicle •In winter or cold weather, the TPMS light may illuminate if the tire pressure was adjusted to the recommended tire inflation pressure during warm weather
QUICK TIPS Tire Pressure Monitoring System Video To view a video on your mobile device, snap this QR Code or visit the listed website .
Refer to page 2 for more information .
www.KuTechVideos.com/ub13/2017
QR CODETire Pressure Monitoring System (TPMS)
The TPMS indicator functions as both Low Tire Pressure
Light and TPMS Malfunction Indicator .
The indicator will illuminate if one or more tires is
significantly underinflated, or if a spare tire has been
installed that does not have a TPMS device or when the
outside temperature drops considerably .
Inflate tire(s) to specifications using an accurate digital tire
pressure gauge to turn off Low Tire Pressure Light . See
front driver’s door jamb for PSI specification .
When there is a problem with the TPMS, the TPMS Malfunction
Indicator will blink for approximately one minute and then
illuminate - See dealer for service .
REMINDER: Consult your dealer for service if Low Tire Pressure Light remains illuminated after inflating your tire(s) .
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER

6
Fuel Economy
There are several factors that
contribute to your vehicle’s
fuel economy, including
maintenance of your vehicle,
driving style, environmental
conditions, vehicle weight
and vehicle aerodynamics .
Below are tips on how to help
improve fuel economy:
•Keep your vehicle in good
condition with regular
maintenance
•Don’t let the engine idle
longer than necessary
•Drive at a moderate speed,
accelerating smoothly and
at a moderate rate
•Keep tires inflated to the recommended pressure
•Travel lightly, without carrying unnecessary weight in
your vehicles
•Avoid placing large or heavy items on roof racks
•Avoid hilly, winding or poorly maintained roads
REMINDER: Driving range varies depending on a vehicle’s fuel tank size, e .g .12-gal .vs .24-gal . Even though the two vehicles’ MPG may be the same, the vehicle with the larger tank will have the greater range .
For more information on Fuel Economy, you can snap the QR code above to view a video or refer to the brochure “GETTING MORE OUT OF EVERY GALLON, FUEL-SAVING TIPS TO DRIVE BY” available at your local dealership.
Fuel Economy Video To view a video on your mobile device, snap this QR Code or visit the listed website .
Refer to page 2 for more information .
www.KuTechVideos.com/ub13/2017
QR CODETR IP
RESET
(Located on the right side of the Steering Wheel)
A
B
Tr ip A
Tr ip B
Elapsed Time
Distance to empty
Avg . MPG
Instant MPG
Avg . MPH
(Type B cluster)
(Type B cluster)
Trip Computer / Tripmeter
The Trip Computer is a driver information system that
displays information related to driving . It appears on
the display when the ignition switch or the ENGINE
START/STOP button* is in the ON position .
To cycle through the different Trip Computer modes,
press the TRIP button A .
To display the Tripmeter, press the TRIP button A, then select Trip A
or Trip B . Press the RESET button B for more than 1 second to reset
the Tripmeter to zero .
REMINDERS:
• Appearance of Trip Computer / Tripmeter display may differ, as equipped
• All stored driving information (except Odometer and Range / Distance to Empty) is reset if the battery is disconnected
Instant Fuel Consumption Mode*
Press the TRIP button A to cycle to the Instant Fuel Consumption
mode . This screen displays the calculated fuel consumption during
the past few seconds .
1 . Keep your vehicle in good condition with regular maintenance
2 . Travel lightly, without carrying unnecessary weight in your vehicle
3 . Don’t let the engine idle longer than necessary
REMINDERS:
•Not to be used in calculating or as a reference for AVER AGE fuel economy
• If the vehicle speed exceeds 1 MPH (1 .6 km/h) after being refueled with more than 1 .6 gallons (6 liters), the average fuel economy will be cleared to zero (----)
RIO FEATURES & FUNCTIONS GUIDE
*IF EQUIPPED
INSTRUMENT CLUSTER
