2017 KIA BORREGO remote control

Features of your vehicle
44
4
Remote control
The electric remote control mirror
switch allows you to adjust the posi-
tion of the left and right outside
rearview mirrors. To adjust the posi-tion of either mirror the ignition
switch should be in the ACC position.
Push the switch (1) to R or L to select
the right side mirror or the left side
mirror, then press a correspondingpoint on the mirror adjustment con-
trol to position the selected mirror up,
down, left or right.
After the adjustment, put the switch
into the neutral (center) position to
prevent inadvertent adjustment.
CAUTION
Do not scrape ice off the mirror
face; this may damage the sur-face of the glass. If ice should restrict the movement of themirror, do not force the mirrorfor adjustment. To remove ice, use a deicer spray, or a spongeor soft cloth with warm water.
CAUTION
If the mirror is jammed with ice,do not adjust the mirror by force.Use an approved spray de-icer (not radiator antifreeze) torelease the frozen mechanism ormove the vehicle to a warm place and allow the ice to melt.
WARNING
Do not adjust or fold the outside
rearview mirrors while the vehi-
cle is moving. This could result in
loss of control, and an accident
which could cause death, seri-
ous injury or property damage.
OHM048040

445
Features of your vehicle
Reverse parking aid function (if equipped)
While the vehicle is moving back-
ward, the outside rearview mirror(s)
will move downward to aid reverse
parking. According to the position of
the outside rearview mirror switch
(1), the outside rearview mirror(s) will
operate as follows: L/R : When the remote control out-
side rearview mirror switch is selected to the L (left) or R
(right) position, both outside
rearview mirrors will move
downward. Neutral
: When the remote control
out-side rearview mirror
switch is placed in the mid-dle position, the outside
rearview mirrors will not
operate while the vehicle is
moving backward.
✽✽ NOTICE
The outside rearview mirrors will
automatically revert to their original
positions under the following condi-
tions:
1. Ignition switch is in the LOCK position.
2. Shift lever is moved to any posi- tion except R.
3. Remote control outside rearview mirror switch is placed in the
middle position.
CAUTION
The mirrors stop moving when
they reach the maximumadjusting angles, but themotor continues to operatewhile the switch is pressed. Do not press the switch longerthan necessary, the motormay be damaged.
Do not attempt to adjust the outside rearview mirror byhand. Doing so may damagethe parts.
OHM048032N

Audio system
35
Steering wheel audio controls (if equipped)
The steering wheel may incorporate
audio control buttons.VOLUME ( / ) (1)
• Press the lever upward ( ) toincrease the volume.
Press the lever downward ( ) to decrease the volume.
SEEK/PRESET ( / ) (2)
The SEEK/PRESET lever has differ- ent functions based on the system
mode. For the following functions the
lever should be pressed for 0.8 sec-
onds or more.
RADIO mode
It will function as the AUTO SEEK
select button. It will SEEK until you
release the button.
MEDIA mode
It will function as the FF/REW button.
If the SEEK/PRESET button is
pressed for less than 0.8 seconds, it
will work as follows in each mode. RADIO mode
It will function as the PRESET STA-
TION buttons.
MEDIA mode
It will function as TRACK UP/DOWN
button.
MODE ( ) (3)
Press the button to change audio
source. FM
➟ AM ➟ CD ➟ USB/iPod ®
➟ AUX ➟
MY MUSIC ➟
Bluetooth®wireless
technology audio
MUTE ( ) (4)
Press the button to mute the sound.
Press the button to turn off the microphone during a telephone call.
Detailed information for audio control
buttons are described in the followingpages in this section.
OHM046355L
■ Type A
■Type C
■Type B
CAUTION
Do not operate audio remote
control buttons simultaneously.

Audio system
516
✽✽NOTICE - Using the
Bluetooth®Wireless
Technology Audio Mode
 Bluetooth ®
Wireless Technology
Audio Mode can be used only
when a Bluetooth®
Wireless
Technology phone has been con-
nected.
 Bluetooth ®
Wireless Technology
Audio Mode will not be available
when connecting mobile phones
that do not support this feature.
 If a Bluetooth ®
Wireless Technology
Phone is being used to play music
and receives an incoming or out-
going phone call, then the music
will stop.
 Moving the Track up/down while playing Bluetooth®
Wireless
Technology audio mode may
result in pop noises with some
mobile phones.
 Bluetooth ®
Wireless Technology
streaming audio may not be sup-
ported in some mobile phones. (Continued)(Continued)
 When returning to
Bluetooth®
Wireless Technology Audio mode
after ending a call, the mode may
not automatically restart in some
mobile phones.
 Receiving an incoming call or making an outgoing call while
playing Bluetooth®
Wireless
Technology Audio may result in
audio interference. ✽
✽
NOTICE - Using the
Bluetooth®Wireless
Technology Cellular Phone
 Bluetooth ®
Wireless Technology
Handsfree refers to a device which
allows the user to conveniently
make phone calls with Bluetooth®
Wireless Technology mobile
phones through the audio system.
 Bluetooth ®
Wireless Technology
allows devices to be connected in a
short distance, including hands-
free devices, stereo headsets, wire-
less remote controllers, etc. For
more information, visit the
Bluetooth ®
Wireless Technology
website at www
.Bluetooth.com.
Before using Bluetooth®
Wireless
Technology audio features.
 The Bluetooth ®
word mark and
logos are registered trademarks
owned by Bluetooth ®
SIG, Inc. and
any use of such marks by Kia is
under license. Other trademarks
and trade names are those of their
respective owners. A Bluetooth ®
enabled cell phone is required to use
Bluetooth ®
Wireless Technology.
(Continued)

I9
Index
Maintenance
Engine compartment ....................................................8-3
Maintenance services ....................................................8-5
Owner maintenance ......................................................8-8
Scheduled maintenance service ..................................8-10
Explanation of scheduled maintenance items ............8-18
Tire maintenance ........................................................8-47
Maintenance schedule....................................................8-10 Normal Maintenance Schedule ..................................8-11
Maintenance Under Severe Usage Conditions ..........8-16
Maintenance services ......................................................8-5 Owner’s responsibility ..................................................8-5
Owner maintenance precautions ..................................8-5
Engine compartment precautions (Diesel engine) ............................................................8-6
Manual mode - Automatic transaxle ............................6-19
Map lamp ....................................................................4-112
Mirrors ..........................................................................4-42 Inside rearview mirror ................................................4-42
Day/night rearview mirror ..........................................4-42
Electrochromic mirror (ECM) ..................................4-42
Outside rearview mirror ..............................................4-43
Remote control ............................................................4-44
Folding the outside rearview mirror ..........................4-46 Non-inflation conditions(Air bags) ..............................3-68
Odometer ......................................................................4-53
Oil (Engine) ..................................................................8-22
Outside rearview mirror ................................................4-43
Outside Temperature ......................................................4-53
Overheats ........................................................................7-8
Owner maintenance ........................................................8-8
Owner maintenance schedule ......................................8-8
Parking assist system ....................................................4-91 Types of warning indicator and sound........................4-92
Parking brake ................................................................6-36
Parking brake ................................................................8-29 Checking the parking brake ........................................8-29
Parking light position ....................................................4-99
Power brakes ..................................................................6-34
Power outlet ................................................................4-147
Power steering................................................................4-39
Power steering fluid ......................................................8-28 Checking the power steering fluid level ....................8-28
Checking the power steering hose ..............................8-28
M
O
N
P

Index
10
I
Power window lock button ............................................4-28
Precautions (for seat belt) ..............................................3-35
Pre-tensioner seat belt....................................................3-32
Rear combination light bulb replacement......................8-72
Rear fog light bulb replacement ....................................8-75
Rear parking assist system ............................................4-87
Type of warning sound ..............................................4-88
Rear seat ......................................................................3-16
Rear view camera ..........................................................4-96
Recommended lubricants and capacities ........................9-6 Recommended SAE viscosity number ........................9-8
Record your key number ................................................4-4
Remote control (outside rear view mirror) ....................4-44
Remote keyless entry Remote keyless entry system operations ....................4-10
Transmitter precautions ..............................................4-11
Battery replacement ....................................................4-12
Remote keyless entry system operations ......................4-10
Road warning ..................................................................7-2
Rocking the vehicle ......................................................6-71
Room lamp ..................................................................4-112
Rotation (Tire) ..............................................................8-44 Scheduled maintenance service ....................................8-10
Normal Maintenance Schedule ..................................8-11
Maintenance Under Severe Usage Conditions ..........8-16
Seat belt restraint system ..............................................3-24
Seat belts ........................................................................3-24 Seat belt restraint system ............................................3-24
Lap/Shoulder belt ........................................................3-26
Lap belt ......................................................................3-29
Pre-tensioner seat belt ................................................3-32
Precautions ..................................................................3-35
Care of seat belts ........................................................3-38
Seat belts warning ..........................................................3-26
Seat warmer ................................................................4-145
Seatback pocket (front) ..................................................3-15
Seats ................................................................................3-2 Front seat adjustment (manual) ....................................3-6
Front seat adjustment (power) ......................................3-7
Headrest(front) ............................................................3-12
Seatback pocket (front) ..............................................3-15
Rear seat ....................................................................3-16
Headrest (rear) ............................................................3-22
Service Mode ................................................................4-60
Shift-lock override - Automatic transaxle ....................6-20
Side air bag ....................................................................3-61
Side repeater lamp replacement ....................................8-72
Smart key ........................................................................4-7
R
S
