Page 337 of 530

Once the desired temperature is displayed, the ATC System
will automatically achieve and maintain that comfort level.
When the system is set up for your comfort level, it is not
necessary to change the settings. You will experience the
greatest efficiency by simply allowing the system to func-
tion automatically.
NOTE:
•It is not necessary to move the temperature settings. The
system automatically adjusts the temperature, mode and
fan speed to provide comfort as quickly as possible.
• The temperature can be displayed in English or Metric
units by selecting the “Display Units of Measure in”
customer-programmable feature. Refer to the “Instru-
ment Cluster Display” in this Section.
Rear Blower Control
The rear blower control knob can be manually set to off, or
any fixed blower speed, by rotating the knob from low to
high. This allows the rear seat occupants to control the
volume of air circulated in the rear of the vehicle.
CAUTION!
Interior air enters the Rear Automatic Temperature
Control System through an intake grille, located in the
right side trim panel behind the third row seats. The
heater outlets are located in the right side trim panel,
just behind the sliding door. Do not block or place
objects directly in front of the inlet grille or heater
outlets. The electrical system could overload causing
damage to the blower motor.
Rear Temperature Control
To change the temperature in the rear of the vehicle, rotate
the temperature knob counterclockwise to lower the tem-
perature, and clockwise to increase the temperature. The
rear temperature settings are displayed in the front ATC
panel.
When rear controls are locked by the front system, the Rear
Temperature Lock symbol on the temperature knob is
illuminated and any rear overhead adjustments are ig-
nored.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 335
Page 338 of 530

Rear Mode Control
•Headliner Mode
Air comes from the outlets in the headliner. Each of
these outlets can be individually adjusted to direct
the flow of air. Moving the air vanes of the outlets to one
side will shut off the airflow.
• Bi-Level Mode
Air comes from both the headliner outlets and the
floor outlets.
NOTE: In many temperature positions, the Bi-Level mode
is designed to provide cooler air out of the headliner
outlets and warmer air from the floor outlets.
• Floor Mode
Air comes from the floor outlets.
Operating Tips
NOTE: Refer to the chart at the end of this section for
suggested control settings for various weather conditions.
Summer Operation
The engine cooling system must be protected with a
high-quality antifreeze coolant to provide proper corrosion
protection and to protect against engine overheating. OAT
coolant (conforming to MS.90032) is recommended. Refer
to “Maintenance Procedures” in “Maintaining Your Ve-
hicle” for proper coolant selection.
Winter Operation
To ensure the best possible heater and defroster perfor-
mance, make sure the engine cooling system is functioning
properly and the proper amount, type, and concentration
of coolant is used. Refer to “Maintenance Procedures” in
“Maintaining Your Vehicle” for proper coolant selection.
Use of the air Recirculation mode during Winter months is
not recommended, because it may cause window fogging.
336 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 339 of 530

Vacation/Storage
Before you store your vehicle, or keep it out of service (i.e.,
vacation) for two weeks or more, run the air conditioning
system at idle for about five minutes, in fresh air with the
blower setting on high. This will ensure adequate system
lubrication to minimize the possibility of compressor dam-
age when the system is started again.
Window Fogging
Vehicle windows tend to fog on the inside in mild, rainy
and/or humid weather. To clear the windows, select De-
frost or Mix mode and increase the front blower speed. Do
not use the Recirculation mode without A/C for long
periods, as fogging may occur.
Outside Air Intake
Make sure the air intake, located directly in front of the
windshield, is free of obstructions such as leaves. Leaves
collected in the air intake may reduce airflow, and if they
enter the plenum, they could plug the water drains. In
winter months, make sure the air intake is clear of ice,
slush, and snow.
A/C Air Filter
The climate control system filters out dust and pollen from
the air. Refer to “Air Conditioning” in “Maintaining Your
Vehicle” for filter replacement instructions.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 337
Page 340 of 530
Operating Tips Chart
338 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 341 of 530

STARTING AND OPERATING
CONTENTS
STARTING PROCEDURES .................342
▫ Automatic Transmission ..................342
▫ Normal Starting ........................342
▫ Extreme Cold Weather (Below –22°F Or 30°C) .343
▫ If The Engine Fails To Start ...............343
▫ After Starting ..........................343
ENGINE BLOCK HEATER — IF EQUIPPED . . . .344
AUTOMATIC TRANSMISSION ..............344
▫ Key Ignition Park Interlock ................345
▫ Brake/Transmission Shift Interlock System . . . .346
▫ Fuel Economy (ECON) Mode ..............346
▫ Six-Speed Automatic Transmission ...........347
▫ Gear Ranges ..........................348
DRIVING ON SLIPPERY SURFACES ..........353▫
Acceleration .......................... .353
▫ Traction ............................ .354
DRIVING THROUGH WATER ..............354
▫ Flowing/Rising Water ...................354
▫ Shallow Standing Water ..................355
POWER STEERING ..................... .356
▫ Power Steering Fluid Check ...............356
PARKING BRAKE .......................357
BRAKE SYSTEM ........................359
ELECTRONIC BRAKE CONTROL SYSTEM .....359
▫ Electronic Brake Force Distribution (EBD) ......359
▫ Brake System Warning Light ...............359
▫ Anti-Lock Brake System (ABS) .............360
▫ Anti-Lock Brake
Warning Light.............361
5
Page 342 of 530

▫Brake Assist System (BAS) ................361
▫ Hill Start Assist (HSA) ...................362
▫ Traction Control System (TCS) .............364
▫ Electronic Stability Control (ESC) ...........364
▫ Electronic Roll Mitigation (ERM) ............367
▫ Trailer Sway Control (TSC) ................368
TIRE SAFETY INFORMATION ..............368
▫ Tire Markings ........................ .368
▫ Tire Identification Number (TIN) ............372
▫ Tire Terminology And Definitions ...........373
▫ Tire Loading And Tire Pressure ............374
TIRES — GENERAL INFORMATION .........379
▫ Tire Pressure ..........................379
▫ Tire Inflation Pressures ..................380
▫ Tire Pressures For High Speed Operation .....381
▫ Radial Ply Tires ........................381
▫ Tire Types ............................382 ▫
Run Flat Tires — If Equipped ..............383
▫ Spare Tires — If Equipped ................383
▫ Tire Spinning ........................ .386
▫ Tread Wear Indicators ...................386
▫ Life Of Tire .......................... .387
▫ Replacement Tires ..................... .387
TIRE CHAINS (TRACTION DEVICES) .........388
TIRE ROTATION RECOMMENDATIONS ......389
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY
GRADES..................390
▫ Treadwear ............................390
▫ Traction Grades ........................390
▫ Temperature Grades .....................391
TIRE PRESSURE MONITOR SYSTEM (TPMS) . . .391
▫ Base System .......................... .393
▫ Premium System .......................395
FUEL REQUIREMENTS ...................399
340 STARTING AND OPERATING
Page 343 of 530

▫3.6L Engine .......................... .399
▫ Reformulated Gasoline ..................399
▫ Gasoline/Oxygenate Blends ...............399
▫ E-85 Usage In Non-Flex Fuel Vehicles .........400
▫ CNG And LP Fuel System Modifications ......400
▫ MMT In Gasoline .......................400
▫ Materials Added To Fuel .................401
▫ Fuel System Cautions ....................401
▫ Carbon Monoxide Warnings ...............402
FLEXIBLE FUEL — IF EQUIPPED ............402
▫ E-85 General Information .................402
▫ Ethanol Fuel (E-85) ..................... .402
▫ Fuel Requirements .....................403
▫ Selection Of Engine Oil For Flexible Fuel Vehicles
(E-85) And Gasoline Vehicles ..............403
▫ Starting ............................ .404▫
Cruising Range ........................404
▫ Replacement Parts ..................... .404
▫ Maintenance ..........................404
ADDING FUEL ........................ .404
▫ Fuel Filler Cap (Gas Cap) .................404
▫ Loose Fuel Filler Cap Message .............406
VEHICLE LOADING .....................406
▫ Vehicle Certification Label ................406
TRAILER TOWING ..................... .408
▫ Common Towing Definitions ...............409
▫ Towing Tips ..........................417
RECREA
TIONAL TOWING (BEHIND
MOTORHOME, ETC.) ....................418
▫ Towing This Vehicle Behind Another Vehicle . . .418
▫ Recreational Towing — All Models ..........419
5
STARTING AND OPERATING 341
Page 344 of 530

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust the
inside and outside mirrors, fasten your seat belt, and if
present, instruct all other occupants to buckle their seat
belts.
WARNING!
•When leaving the vehicle, always remove the key fob
from the ignition and lock your vehicle.
• Never leave children alone in a vehicle, or with
access to an unlocked vehicle.
• Allowing children to be in a vehicle unattended is
dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.
• Do not leave the key fob in or near the vehicle, or in
a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.
• Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.
Automatic Transmission
The gear selector must be in the NEUTRAL or PARK
position before you can start the engine. Press the brake
pedal before shifting into any driving gear.
Normal Starting
1. Do not press the accelerator.
2. Use the fob with Integrated Key to briefly turn the
ignition switch to the START position and release it as
soon as the starter engages. The starter motor will
continue to run, and it will disengage automatically
when the engine is running.
3. If the engine fails to start, the starter will disengage automatically in 10 seconds. If this occurs, turn the
ignition switch to the OFF position, wait 10 to 15
seconds, then repeat the “Normal Starting” procedure
(Steps 1–3 above).
NOTE: This vehicle is equipped with a transmission
shift interlocking system. The brake pedal must be
pressed to shift out of PARK.
342 STARTING AND OPERATING
