Description
2-1
2
EAU63371
Left view
123456
789
1. Air filter element (page 6-17)
2. Idle adjusting screw (page 6-19)
3. Seat lock (page 3-18)
4. Fuses (page 6-36)
5. Owner’s tool kit (page 6-2)
6. Storage compartment (page 3-20)
7. Shift pedal (page 3-12)
8. Engine oil filter cartridge (page 6-11)
9. Engine oil drain bolt (page 6-11)
UBS1E0E0.book Page 1 Thursday, October 8, 2015 3:40 PM

Periodic maintenance an d a djustment
6-36
6
EAU47174
Replacin g the fuses
The main fuse and the fuse boxes,
which contain the fuses for the individ-
ual circuits, are located under the seat.
(See page 3-18.)
TIP
To access the main fuse, remove the
starter relay cover as shown.
XJ6F
XJ6F XJ6FA
XJ6FA
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
1. Starter relay cover
2. Main fuse
3. Spare main fuse
4. Fuse box
1. Taillight fuse
2. Spare fuse
3. Headlight fuse
4. Ignition fuse
5. Signaling system fuse
6. Backup fuse (for clock and immobilizer sys-
tem)
7. Fuel injection system fuse
8. Radiator fan motor fuse
2
4
3
1
1
2
3
4
5
6
7
8
1. Starter relay cover
2. Main fuse
3. Spare main fuse
4. Fuse box
1. Taillight fuse
2. ABS control unit fuse
3. ABS solenoid fuse
4. ABS motor fuse
5. Spare fuse
6. Headlight fuse
7. Ignition fuse
8. Signaling system fuse
9. Backup fuse (for clock and immobilizer sys-
tem)
10.Fuel injection system fuse
11.Radiator fan motor fuse
2
4
3
1
1
5 56
7
8
9
10
11
234
UBS1E0E0.book Page 36 Thursday, October 8, 2015 3:40 PM

Periodic maintenance an d a djustment
6-37
6 ratin
g than recommen ded to
avoi d causin g extensive d am-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
EAU47412
Replacin g the hea dlig ht bul b
This model is equipped with a halogen
bulb headlight. If the headlight bulb
burns out, replace it as follows.
NOTICE
ECA10651
Take care not to d amage the follow-
in g parts:
 Hea dlig ht bul b
Do not touch the glass part of
the hea dlig ht bul b to keep it free
from oil, otherwise the transpar-
ency of the glass, the luminosity
of the b ulb, an d the b ulb life will
b e ad versely affected . Thor-
ou ghly clean off any d irt and fin-
g erprints on the hea dlig ht bul b
usin g a cloth moistene d with al-
cohol or thinner.
 Hea dlig ht lens
Do not affix any type of tinted
film or stickers to the head light
lens.
Do not use a hea dlig ht bul b of a
watta ge hi gher than specifie d.
1. Remove cowlings A and C. (See
page 6-7.)
2. Disconnect the headlight coupler, and then remove the headlight
bulb cover.
Specifie d fuses:
Main fuse: 30.0 A
Headlight fuse:
20.0 A
Taillight fuse: 10.0 A
Signaling system fuse: 7.5 A
Ignition fuse:
10.0 A
Radiator fan motor fuse: 20.0 A
Fuel injection system fuse: 10.0 A
Backup fuse:
7.5 A
ABS motor fuse: 30.0 A (XJ6FA)
ABS control unit fuse: 7.5 A (XJ6FA)
ABS solenoid fuse:
20.0 A (XJ6FA)
1. Do not touch the glass part of the bulb.
UBS1E0E0.book Page 37 Thursday, October 8, 2015 3:40 PM

Specifications
8-3
8
Battery:
Model:GT12B-4
Voltage, capacity:
12 V, 10.0 Ah (10 HR)
Hea dlig ht:
Bulb type:
Halogen bulb
Bul b watta ge × quantity:
Headlight:
H4, 60.0 W/55.0 W x 1
Brake/tail light: 21.0 W/5.0 W × 1
Front turn signal light:
10.0 W × 2
Rear turn signal light:
10.0 W × 2
Auxiliary light: 5.0 W × 1
License plate light: 5.0 W × 1
Meter lighting:
LED
Neutral indicator light: LED
High beam indicator light: LED
Oil level warning light:
LED
Turn signal indicator light: LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
ABS warning light: LED (XJ6FA)
Immobilizer system indicator light: LED
Fuse(s):
Main fuse:30.0 A
Headlight fuse: 20.0 A
Taillight fuse:
10.0 A
Signaling system fuse: 7.5 A
Ignition fuse: 10.0 A Radiator fan motor fuse:
20.0 A
Fuel injection system fuse: 10.0 A
ABS control unit fuse:
7.5 A (XJ6FA)
ABS motor fuse: 30.0 A (XJ6FA)
ABS solenoid fuse: 20.0 A (XJ6FA)
Backup fuse:
7.5 A
