2016 TOYOTA VENZA checking oil

4934-3. Do-it-yourself maintenance
4
Maintenance and care
VENZA_OM_OM73030U_(U) Engine oil
With the engine at operating temperature and turned off, check the oil
level on the dipstick.
■ Checking the engine oil
Park the vehicle on level ground. After warming up the engine
and turning it off, wait more than five minutes for the oil to
drain back into the bottom of the engine.
Hold a rag under the end and
pull the dipstick out.
Wipe the dipstick clean.
Reinsert the dipstick fully. STEP 1
STEP 2
STEP 3
STEP 4

4954-3. Do-it-yourself maintenance
4
Maintenance and care
VENZA_OM_OM73030U_(U) ■ Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as already in
the engine.
Make sure to check the oil type and prepare the items needed before
adding oil.
Remove the oil filler cap.
Add engine oil slowly, checking the dipstick.
Install the filler cap, turning it clockwise.Engine oil selection  P. 616
Oil quantity
(Low  Full) 1.6 qt. (1.5 L, 1.3 Imp. qt.)
Items Clean funnelSTEP 1
STEP 2
STEP 3

5
When trouble arises
5655-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
Have the vehicle inspected immediately.
Failing to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.Warning light Warning light/Details
Charging system warning light
Malfunction in the vehicle’s charging system.
Low engine oil pressure warning light
Abnormal level of engine oil pressure.
This warning light may turn on if the level of engine oil
declines. The light should turn off after checking the oil
and adding oil if necessary.
Warning light Warning light/Details
Malfunction indicator lamp
Malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system.

679Alphabetical index
VENZA_OM_OM73030U_(U) Engine coolan t temperature
gauge ..................................... 188
Engine immobilizer system .... 109
Engine oil
Capacity ............................... 616
Checking .............................. 493
Preparing and checking
before winter ...................... 276
Engine switch .................. 173, 177
Entune Audio Plus
* EPS ........................................... 256
Event data recorder .................. 23
Floor mat .................................. 453
Fluid
Brake .................................... 500
Washer ................................. 505
Fog lights
Replacing light bulbs ............ 543
Switch ................................... 223
Wattage ................................ 624
Four-wheel drive system ........ 257
Front fog lights
Replacing light bulbs ............ 543
Switch ................................... 223
Wattage ................................ 624
Front passenger occupant
classification system............ 134
Front passenger’s seat belt
reminder light ........................ 567
Front seats
Adjustment ............................. 67
Driving position memory ......... 73
Front side marker light
Replacing light bulbs ............ 546
Wattage ................................ 624
Front turn signal lights
Replacing light bulbs ............ 544
Wattage ................................ 624 Fuel
Capacity ................................615
Fuel gauge ............................188
Fuel pump shut off system ....563
Information ............................626
Refueling ...............................105
Type ......................................626
Fuel door...................................105
Fuel filler door ..........................105
Fuel pump shut off
system ....................................563
Fuses.........................................527
Garage door opener.................457
Gauges ......................................188
Glove box..................................435
Glove box light .........................435
Hands-free system
(for cellular phone) ................379
HD Radio ®
system
* Head restraints
Adjusting .................................78
Headlights
Replacing light bulbs .............537
Switch....................................212
Wattage .................................624
Heaters
Seat heaters ..........................449
Side mirror.............................316
Hill-start assist control ............262
Hood ..........................................487
Hooks
Cargo hook............................455
Shopping bag hooks .............455
Horn...........................................187F G
H
* : Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

684Alphabetical index
VENZA_OM_OM73030U_(U) Vanity lights
Vanity lights ........................... 446
Wattage ................................. 624
Vanity mirrors........................... 446
Vehicle identification
number ................................... 613
Vehicle stability control........... 256
Voice command system
* ........ 426
VSC............................................ 256
Warning buzzers
Brake system ........................ 564
Open door ............................ 567
Seat belt reminder ................. 567
Warning lights
Active Torque Control 4WD
system ................................ 568
Automatic headlight leveling
system ................................ 566
Anti-lock brake system .......... 566
Brake system ........................ 564
Charging system .... .......... ..... 565
Electric power steering .......... 566
Engine oil pressure ............... 565
Low fuel level ........................ 568
Maintenance required
reminder.............................. 569
Malfunction indicator lamp .... 565
Master warning...................... 568
Open door ............................. 567
Seat belt reminder ................. 567
SRS airbags .......................... 566
Tire pressure ......................... 567
Washer fluid .......................... 568 Warning messages .................. 578
Washer
Checking ............................... 505
Preparing and checking
before winter ....................... 276
Switch ........................... 225, 229
Washing and waxing ............... 470
Weight
Cargo capacity ...................... 269
Load limits ............................. 274
Weight ................................... 612
Wheels ...................................... 517
Window glasses ........................ 96
Window lock switch................... 96
Windows
Power windows ....................... 96
Rear window defogger .......... 316
Washer.................................. 225
Windshield wiper de-icer ........ 316
Windshield wipers ................... 225
Wireless remote control key
Replacing the battery ............ 523
Wireless remote control key.... 45
WMA disc.................................. 343
XM ®
Satellite Radio
*V
W
X
* : Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
