2016 TOYOTA VENZA child restraint

TABLE OF CONTENTS Index
2
VENZA_OM_OM73030U_(U) 1-1. Key information
Keys ..................................... 28
1-2. Opening, closing and
locking the doors
Smart key system................. 30
Wireless remote control ....... 45
Side doors ............................ 50
Back door ............................. 56
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ........................... 67
Rear seats ............................ 70
Driving position memory....... 73
Head restraints ..................... 78
Seat belts ............................. 81
Steering wheel ..................... 88
Inside rear view mirror.......... 89
Outside rear view mirrors ..... 92 1-4. Opening and closing
the windows and moon roof
Power windows..................... 96
Moon roof ........................... 100
Sunshade ........................... 104
1-5. Refueling
Opening the fuel tank
cap .................................... 105
1-6. Theft deterrent system
Engine immobilizer
system .............................. 109
Alarm .................................. 112
Theft prevention labels
(U.S.A.)............................. 116
1-7. Safety information
Correct driving posture ....... 117
SRS airbags ....................... 119
Front passenger occupant
classification system ......... 134
Child restraint systems ....... 140
Installing child restraints ..... 1461
Before driving For vehicles with an Entune Premium Au dio with Navigation or Entune Audio
Plus, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL” for information regarding the equipment listed below.
• Navigation system • Audio system

Before driving
1
27
VENZA_OM_OM73030U_(U) 1-1. Key information
Keys ................................... 28
1-2. Opening, closing and
locking the doors
Smart key system .............. 30
Wireless remote
control .............................. 45
Side doors .......................... 50
Back door ........................... 56
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ......................... 67
Rear seats.......................... 70
Driving position memory .... 73
Head restraints................... 78
Seat belts ........................... 81
Steering wheel ................... 88
Inside rear view mirror ....... 89
Outside rear view
mirrors.............................. 92 1-4. Opening and closing the
windows and moon roof
Power windows .................. 96
Moon roof ......................... 100
Sunshade ......................... 104
1-5. Refueling
Opening the fuel tank
cap ................................. 105
1-6. Theft deterrent system
Engine immobilizer
system ........................... 109
Alarm................................ 112
Theft prevention labels
(U.S.A.) .......................... 116
1-7. Safety information
Correct driving posture..... 117
SRS airbags ..................... 119
Front passenger
occupant classification
system ........................... 134
Child restraint
systems.......................... 140
Installing child
restraints ........................ 146

831-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
VENZA_OM_OM73030U_(U) ■ Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend, and you can move around fully.
■ Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then
retracted even slightly, the belt is locked in that position and cannot be
extended. This feature is used to hold the child restraint system (CRS) firmly.
To free the belt again, fully retract the belt and then pull the belt out once
more. (  P. 146)
■ When not using the rear outboard seat belts
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
● Use a child restraint system appropriately for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. (  P. 140)
● When the child becomes large enough to properly wear the vehicle’s
seat belt, follow the instructions on P. 81 regarding seat belt usage. Pass the outer seat belts and plates
through the seat belt hangers to prevent
the shoulder belts from being damaged.

841-3. Adjustable components (s eats, mirrors, steering wheel)
VENZA_OM_OM73030U_(U) ■ Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate
for the first collision, but will not activate for the second or subsequent colli-
sions.
■ Seat belt extender
CAUTIONObserve the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failing to do so may cause death or serious injury.
■ Wearing a seat belt
● Ensure that all passengers wear a seat belt.
● Always wear a seat belt properly.
● Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at the same time, including children.
● Toyota recommends that children should be seated in the rear seat and
always use a seat belt and/or an appropriate child restraint system.
● Do not recline the seat any more than necessary to achieve a proper seat-
ing position. The seat belt is most effective when the occupants are sitting
up straight and well back in the seats.
● Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips. If your seat belts cannot be fastened
securely because they are not long
enough, a personalized seat belt
extender is available from your Toyota
dealer free of charge.

871-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
VENZA_OM_OM73030U_(U) CAUTION■ Using a seat belt extender
● Do not wear the seat belt extender, if you can fasten the seat belt without
the extender.
● Do not use the seat belt extender when installing a child restraint system,
because the belt will not securely hold the child restraint system, increas-
ing the risk of death or serious injury in the event of a sudden stop, sudden
swerve or an accident.
● The personalized extender may not be safe on another vehicle, when
used by another person, or at a different seating position other than the
one originally intended.
NOTICE■ When using a seat belt extender
When releasing the seat belt, press on the buckle release button on the
extender, not on the seat belt.
This helps prevent damage to the vehicle interior and the extender itself.

1291-7. Safety information
1
Before driving
VENZA_OM_OM73030U_(U) CAUTION■ SRS airbag precautions
● The SRS front passenger airbag also deploys with considerable force, and
can cause death or serious injury especially if the front passenger is very
close to the airbag. The front passenger seat should be as far from the air-
bag as possible with the seatback adjusted, so the front passenger sits
upright.
● Improperly seated and/or restrained infants and children can be killed or
seriously injured by a deploying airbag. An infant or child who is too small
to use a seat belt should be properly secured using a child restraint sys-
tem. Toyota strongly recommends that all infants and children be placed in
the rear seats of the vehicle and properly restrained. The rear seats are
the safest for infants and children. (  P. 140)● If the seat belt extender has been con-
nected to the front seat belt buckles but
the seat belt extender has not also
been fastened to the latch plate of the
seat belt, the SRS front airbags will
judge that the driver and front passen-
ger are wearing the seat belt even
though the seat belt has not been con-
nected. In this case, the SRS front air-
bags may not activate correctly in a
collision, resulting in death or serious
injury in the event of a collision. Be sure
to wear the seat belt with the seat belt
extender.

1351-7. Safety information
1
Before driving
VENZA_OM_OM73030U_(U) Condition and operation in the fr ont passenger occupant classi-
fication system
■ Adult
* 1
■ Child
* 3
or child restraint system
* 4Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
ON”
SRS warning light Off
Front passenger’s seat belt reminder light Flashing
* 2
Devices Front passenger airbag
ActivatedSide airbag on the front passenger seat
Curtain shield airbag
in the front passenger side
Front passenger’s seat belt pretensioner
Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF”
* 5
SRS warning light Off
Front passenger’s seat belt reminder light Flashing
* 2
Devices Front passenger airbag Deactivated
Side airbag on the front passenger seat
ActivatedCurtain shield airbag
in the front passenger side
Front passenger’s seat belt pretensioner

1371-7. Safety information
1
Before driving
VENZA_OM_OM73030U_(U) ■ System malfunction
* 1
: The system judges a person of adult size as an adult. When a
smaller adult sits in the front passenger seat, the system may rec-
ognize him/her as a child depe nding on his/her physique and pos-
ture.
* 2
: In the event the front passenger does not wear a seat belt.
* 3
: When a larger child who has outgrow n a child restraint system sits
in the front passenger seat, the system may recognize him/her as
an adult depending on his/her physique or posture.
* 4
: Never install a rear-facing child restraint system on the front pas-
senger seat. A forward-facing child restraint system should only
be installed on the front passenger seat when it is unavoidable.
(  P. 140)
* 5
: In case the indicator is not illumi nated, consult this manual as for
installing the child restra int system properly. (  P. 146)
* 6
: In the event of a side collision. Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF”
SRS warning light On
Front passenger’s seat belt reminder light Off
Devices Front passenger airbag Deactivated
Side airbag on the front passenger seat
ActivatedCurtain shield airbag
in the front passenger side
Front passenger’s seat belt pretensioner
