8-2. Steps to take in an emergency
If the hybrid system will not star t
One of the following may be the cause of the problem:
●The electronic key may not be functioning properly.
* (P. 536)
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle. (P. 79)
●There may be a malfunction in the immobilizer system.
* (P. 8 2 )
●There may be a malfunction in the shift control system.
*
(P. 177, 492, 505)
●The hybrid system may be malfunctioning due to an electrical prob-
lem such as electronic key battery depletion or a blown fuse. How-
ever, depending on the type of malfunction, an interim measure is
available to start the hybrid system. (P. 535)
*: It may not be possible to shift the shift position other than P.
One of the following may be the cause of the problem:
●The 12-volt battery may be discharged. (P. 538)
●The 12-volt battery terminal connections may be loose or corroded.
(P. 439)
Reasons for the hybrid system not starting vary depending on
the situation. Check the following and perform the appropriate
procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. (P. 174)
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.

5358-2. Steps to take in an emergency
PRIUS v_OM_OM47B12U_(U)
8
When trouble arises
One of the following may be the cause of the problem:
●The 12-volt battery may be discharged. (P. 538)
●One or both of the 12-volt battery terminals may be disconnected.
(P. 439)
Contact your Toyota dealer if the problem cannot be repaired, or if
repair procedures are unknown.
When the hybrid system does not start, the following steps can be
used as an interim measure to start the hybrid system if the power
switch is functioning normally.
Do not use this starting procedure except in cases of emergency.
Set the parking brake.
Turn the power switch to ACCESSORY mode.
Press and hold the power switch for about 15 seconds while
depressing the brake pedal firmly.
Even if the hybrid system can be started using the above steps, the
system may be malfunctioning. Have the vehicle inspected by your
Toyota dealer.
The interior lights and headlights do not turn on, or the horn
does not sound.
Emergency start function
1
2
3

5408-2. Steps to take in an emergency
PRIUS v_OM_OM47B12U_(U)
Make sure the “READY” indicator comes on. If the indicator light
does not come on, contact your Toyota dealer.
Once the hybrid system has started, remove the jumper cables in
the exact reverse order from which they were connected.
Close the exclusive jump starting terminal cover, and reinstall the
fuse box cover to its original position.
When installing, first hook the fuse box cover onto the two rear tabs.
Once the hybrid system starts, have the vehicle inspected at your
Toyota dealer as soon as possible.
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is off.
●Turn off any unnecessary electrical components when the vehicle is running
at a low speed for an extended period, such as in heavy traffic.
■When the 12-volt battery is removed or discharged
●The hybrid system may not start. (P. 440)
●If the 12-volt battery discharges while the shift position is in P, it may not be
possible to shift the shift position to other positions. In this case, the vehicle
cannot be towed without lifting both front wheels because the front wheels
will be locked. (P. 484)
●When the 12-volt battery is reconnected, start the hybrid system and con-
firm that the shift position can be changed to each position using the shift
position indicator.
■Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects of
certain electrical appliances. If the vehicle is left for a long time, the 12-volt
battery may discharge, and the hybrid system may be unable to start. (The
12-volt battery recharges automatically while the hybrid system is operating.)
6
7
8

560
PRIUS v_OM_OM47B12U_(U)
9-1. Specifications
Light bulbs
Light bulbsBulb No.WTy p e
Exterior
Halogen headlights*
Low beam
High beamH11
HB355
60A
B
Fog lights*H1619C
Front turn signal lights
Halogen headlights
LED headlights
7444NA
WY21W28
21D
D
Front side marker lights (vehi-
cles with halogen headlights)W5W5E
Parking lights (vehicles with
halogen headlights)W5W5E
Rear turn signal lightsWY21W21D
Back-up lightsW21W21E
License plate lightsW5W5E
Interior
Vanity lights8E
Personal/interior lights
Vehicles without
panoramic roof
Vehicles with
panoramic roof

5
8E
E
Rear interior light8F
Door courtesy lights5E
Luggage compartment light5E
A: H11 halogen bulbs
B: HB3 halogen bulbs
C: H16 halogen bulbs
D: Wedge base bulbs (amber)E: Wedge base bulbs (clear)
F: Double end bulbs
*: If equipped

578
PRIUS v_OM_OM47B12U_(U)
9-2. Customization
■Wireless remote control (P. 116)
■Automatic light control system (P. 189)
*1: Entune Premium Audio with Navigation only.
*2: This function cannot be customized for vehicles sold in Canada.
FunctionDefault
settingCustomized
setting
Wireless remote control On Off – – O
Unlocking operation
Driver’s door
unlocked in first
step, all doors
unlocked in sec-
ond step
All doors
unlocked in first
step
–OO
Panic function OnOff––O
123
FunctionDefault
settingCustomized
setting
Time elapsed before the
headlights turn off30 secondsOff
–OO 60 seconds
90 seconds
Light sensor sensitivityLevel 0Level -2 to 2–OO
Daytime running lights*2OnOff–O*1O
123
