2016 TOYOTA PRIUS V steering wheel adjustment

TABLE OF CONTENTS4
PRIUS v_OM_OM47B12U_(U)5-1. Basic Operations
Audio system types .......... 268
Audio system .................... 269
Using the steering wheel
audio switches ................ 272
AUX Port/USB Port........... 273
Basic audio operations ..... 274
5-2. Setup
Setup menu ...................... 276
General settings ............... 277
Audio settings ................... 279
Display settings ................ 281
Voice settings ................... 284
5-3. Using the Multimedia
system
Selecting the audio
source ............................. 285
List screen operation ........ 286
Optimal use of the audio
system ............................ 288
Audio screen
adjustment ...................... 2895-4. Using the radio
Radio operation................. 290
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation .......... 292
5-6. Using an external device
Listening to an iPod .......... 298
Listening to a USB
memory device ............... 303
Using the AUX .................. 308
VTR ................................... 309
5-7. Connecting Bluetooth
®
Preparations to
use wireless
communication ................ 310
Registering a Bluetooth
®
audio player for the
first time .......................... 313
Registering a Bluetooth
®
phone for the first time .... 314
Registering a
Bluetooth
® device ........... 315
Connecting a
Bluetooth
® device ........... 317
Displaying a Bluetooth®
device details .................. 319
Detailed Bluetooth
®
system settings ............... 320
5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio............................... 321
5Audio system

1473-4. Adjusting the steering wheel and mirrors
3
Operation of each component
PRIUS v_OM_OM47B12U_(U)
Steering wheel
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
■After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.
Adjustment procedure
1
2
Horn

1513-4. Adjusting the steering wheel and mirrors
3
Operation of each component
PRIUS v_OM_OM47B12U_(U)
Outside rear view mirrors
To select a mirror to adjust,
press the switch.
Left
Right
To adjust the mirror, press the
switch.
Up
Right
Down
Left
Push the mirror back in the direc-
tion of the vehicle’s rear.
Adjustment procedure
1
1
2
2
1
2
3
4
Folding the mirrors

266
PRIUS v_OM_OM47B12U_(U)
5-1. Basic OperationsAudio system types .......... 268
Audio system .................... 269
Using the steering wheel audio switches ................ 272
AUX Port/USB Port .......... 273
Basic audio operations ..... 274
5-2. Setup Setup menu ...................... 276
General settings ............... 277
Audio settings ................... 279
Display settings ................ 281
Voice settings ................... 284
5-3. Using the Multimedia system
Selecting the audio source............................. 285
List screen operation ........ 286
Optimal use of the audio system ............................ 288
Audio screen adjustment ...................... 289
5-4. Using the radio Radio operation ................ 290
5Audio system

4988-2. Steps to take in an emergency
PRIUS v_OM_OM47B12U_(U)
WARNING
■If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Toyota
dealer. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.
■When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold
firmly and operate using more force than usual.
■
If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause a loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light comes on even after tire inflation pres-
sure adjustment, it is probable that you have a flat tire. Check the tires.
If a tire is flat, change it with the spare tire and have the flat tire
repaired by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

615Alphabetical index
PRIUS v_OM_OM47B12U_(U)
Seats
Adjustment .................... 138, 142
Adjustment precautions ........ 140
Child seats/child restraint
system installation .......... 58, 62
Cleaning................................ 410
Front seats ............................ 138
Head restraint ....................... 145
Properly sitting in the seat ...... 30
Seat heaters ......................... 372
Sensor
Automatic headlight
system ................................ 192
Automatic High Beam
system ................................ 194
Inside rear view mirror .......... 150
LDA (Lane Departure
Alert) ................................... 227
Radar sensor ................ 221, 255
Service reminder indicators ..... 86
Shift lever ................................. 181
Shift lever light......................... 373
Side airbags ............................... 41
Side doors ................................ 120
Side marker lights
Light switch ........................... 189
Replacing light bulbs..... 472, 478
Wattage ................................ 560
Side mirrors ............................. 151
Adjustment ............................ 151
Folding .................................. 151
Heaters ................................. 366Smart key system .................... 130
Antenna location ................... 130
Entry functions ...................... 120
Starting the hybrid system .... 174
Warning message................. 517
Snow tires ................................ 263
“SOS” button ........................... 398
Spare tire
Inflation pressure .................. 559
Storage location.................... 522
Spark plug ................................ 557
Specifications .......................... 552
Speedometer.............................. 92
SRS airbags ............................... 41
Steering wheel
Adjustment............................ 147
Audio switches...................... 272
DISP button ............................ 94
Meter control switches .......... 100
Telephone switches .............. 337
TRIP button ............................ 93
Stop/tail lights.......................... 478
Storage feature ........................ 376
Storage precautions................ 376
