2016 TOYOTA PRIUS V remote control

5
1
9 8
7
6 4 3
2
PRIUS v_OM_OM47B12U_(U)
10
5
5-9. Bluetooth® phone
Using a Bluetooth®
Phone ............................. 323
Making a call..................... 326
Receiving a call ................ 329
Speaking on the phone..... 330
Bluetooth
® phone
message function ........... 333
Using the steering wheel
switches.......................... 337
Bluetooth
® phone
settings ........................... 338
Contact/Call History
Settings .......................... 339
What to do if...
(Troubleshooting) ........... 348
5-10. Bluetooth
®
Bluetooth®........................ 352
5-11. Using the voice
command system
Voice command system ... 3586-1. Using the air conditioning
system and defogger
Automatic air conditioning
system ............................. 364
Using the steering wheel
climate remote control
switches........................... 371
Seat heaters ...................... 372
6-2. Using the interior lights
Interior lights list................. 373
• Front interior light .......... 374
• Front personal lights ...... 374
• Rear interior light ........... 375
6-3. Using the storage features
List of storage features ...... 376
• Glove boxes .................. 377
• Console box .................. 377
• Cup holders/
bottle holders/
door pockets.................. 378
• Auxiliary boxes .............. 380
• Card holder ................... 380
Luggage compartment
features ........................... 381
6Interior features

12
PRIUS v_OM_OM47B12U_(U)The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
Scrapping of your Toyota
Perchlorate Material
WARNING
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.

22Pictorial index
PRIUS v_OM_OM47B12U_(U)Audio remote control switches
*1. . . . . . . . . . . . . . . . . . . . . P. 272
Meter control switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100
Climate remote control switches
*2 . . . . . . . . . . . . . . . . . . . P. 371
DISP button
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 94
TRIP button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 93
Cruise control switch
Cruise control
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Dynamic radar cruise control
*2 . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Vehicle-to-vehicle distance button
*2. . . . . . . . . . . . . . . . . . P. 217
Telephone switches
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 337
Talk switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 337
1
2
3
4
5
6
7
8
9

116
PRIUS v_OM_OM47B12U_(U)
3-1. Key information
Keys
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart key system
(P. 130)
• Operating the wireless remote
control function
Mechanical keys
Key number plate
Locks all the doors (P. 120)
Check that the door is securely
locked.
Unlocks all the doors (P. 120)
Sounds the alarm (P. 117)
The keys
1
2
3
Wireless remote control
1
2
3

118
PRIUS v_OM_OM47B12U_(U)
3-1. Key information
■Electronic key battery depletion
●The standard battery life is 1 to 2 years.
●If the battery becomes low, an alarm will sound in the cabin and a message
will be displayed on the multi-information display (if equipped) when the
hybrid system stops. (P. 520)
●As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. (P. 461)
• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
●To avoid serious deterioration, do not leave the electronic key within 3 ft.
(1 m) of the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Induction cookers
• Table lamps
■Replacing the battery
P. 461
■If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.

120
PRIUS v_OM_OM47B12U_(U)
3-2. Opening, closing and locking the doors
Side doors
◆Smart key system
Carry the electronic key to enable this function.
Grip the driver’s door handle
or front passenger door han-
dle with the sensor (if
equipped) to unlock the door.
Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
Touch the lock sensor (the indentation on the upper part of the
front door handle) to lock the doors.
Check that the door is securely locked.
◆Wireless remote control
Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
Pressing the button unlocks the
driver’s door. Pressing the but-
ton again within 3 seconds
unlocks the other doors.
The vehicle can be locked and unlocked using the entry func-
tion, wireless remote control or door lock switch.
Unlocking and locking the doors from the outside
1
2
1
2

PRIUS v_OM_OM47B12U_(U)
1213-2. Opening, closing and locking the doors
3
Operation of each component
■Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
■Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
■When the door cannot be locked by the lock sensor on the upper part of
the door handle
■Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously for 5 seconds. Fully close the door to stop the
buzzer, and lock the vehicle once more.
■If the smart key system or the wireless remote control does not operate
properly
●Use the mechanical key to lock and open the doors. (P. 536)
●Replace the key battery with a new one if it is depleted. (P. 461) If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor
areas at the same time.

125
PRIUS v_OM_OM47B12U_(U)
3-2. Opening, closing and locking the doors
3
Operation of each component
Back door
◆Smart key system (if equipped)
Carry the electronic key to enable this function.
Locks all the doors
Check that the door is securely
locked.
Unlocks all the doors
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
Check that the door is securely
locked.
◆Wireless remote control
P. 1 1 6
◆Door lock switch
P. 1 2 2
Raise the back door while pushing
up the back door opener switch.
The back door can be unlocked/locked and opened by the fol-
lowing procedures.
1
2
Opening the back door from outside the vehicle
