2016 TOYOTA PRIUS V clock

PRIUS v_OM_OM47B12U_(U)
4757-3. Do-it-yourself maintenance
7
Maintenance and care
■Front turn signal lights
Turn the bulb base counterclockwise.
Remove the light bulb.
When installing, reverse the steps listed.
1
Vehicles with halogen head-
lightsVehicles with LED headlights
2
3

476
PRIUS v_OM_OM47B12U_(U)
7-3. Do-it-yourself maintenance
■Rear turn signal lights and back-up lights
Open the back door and
remove the cover.
To prevent damage, cover the
tip of the screwdriver with a rag.
Turn the bulb base counter-
clockwise.
Rear turn signal light
Back-up light
Remove the light bulb.
Rear turn signal light
Back-up light
When installing, reverse the steps listed.
1
2
1
2
3
1
2
4

PRIUS v_OM_OM47B12U_(U)
4777-3. Do-it-yourself maintenance
7
Maintenance and care
■License plate lights
Open the back door and
remove the cover.
To prevent damage, cover the
tip of the screwdriver with a rag.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
ITO43P150
3
4

606Alphabetical index
PRIUS v_OM_OM47B12U_(U)
Child-protectors....................... 123
Cleaning
Aluminum wheels.................. 407
Exterior ................................. 406
Interior................................... 410
Panoramic roof ..................... 409
Radar sensor ................ 226, 258
Seat belts .............................. 411
Climate remote control ........... 371
Clock ................................... 92, 386
Condenser ................................ 433
Console box ............................. 377
Coolant
Capacity ................................ 557
Checking ............................... 431
Preparing and checking
before winter....................... 263
Cooling system ........................ 431
Hybrid system overheating ... 543
Consumption screen ............... 108
Cruise control
Cruise control........................ 210
Dynamic radar cruise
control................................. 214
Warning messages ............... 506
Cup holders.............................. 378
Curtain shield airbags ............... 41
Customizable features ............ 575Daytime running light
system.................................... 192
Defogger
Outside rear view mirrors ..... 366
Rear window ......................... 366
Windshield ............................ 366
Dimension ................................ 552
Dinghy towing.......................... 173
Display
Drive information .................. 102
Dynamic radar cruise
control ................................ 214
Energy monitor ............. 102, 108
LDA (Lane Departure
Alert)................................... 227
Multi-information display ....... 100
Trip information....................... 94
Warning messages ............... 503
Do-it-yourself maintenance .... 419
Door courtesy lights ............... 373
Location ................................ 373
Wattage ................................ 560D

616Alphabetical index
PRIUS v_OM_OM47B12U_(U)
Stuck
If the vehicle becomes
stuck ................................... 548
Sun visors ................................ 385
Sunshade
Panoramic roof shades ......... 389
Switch
Audio remote control
switches.............................. 272
Automatic High Beam
switch ................................. 194
Climate remote control
switches.............................. 371
Clock adjustment buttons ..... 386
Cruise control switch..... 210, 214
DISP button ............................ 94
Door lock switch.................... 122
Driving mode select switch ... 245
Emergency flashers switch ... 482
Engine switch........................ 174
EV drive mode switch ........... 179
Fog light switch ..................... 200
Garage door opener
switches.............................. 391
Ignition switch ....................... 174
LDA (Lane Departure
Alert) ................................... 227
Light switches ....................... 189
MPH or km/h button ................ 93
Meter control switches .......... 100
Outside rear view mirror
switches.............................. 151Panoramic roof shades......... 389
PCS switch ........................... 254
Power door lock switch ......... 122
Power switch ........................ 174
Power window switch ........... 153
Rear window wiper and
washer switch..................... 205
Rear window and outside
rear view mirror
defoggers switch ................ 366
Seat heater switches ............ 372
“SOS” button......................... 398
Talk switch ............................ 337
Telephone switches .............. 337
Tire pressure warning
reset switch ........................ 445
TRIP button ............................ 93
Vehicle-to-vehicle
distance button ................... 217
VSC OFF switch ................... 248
Window lock switch .............. 153
Windshield wipers and
washer switch..................... 202
