Scrapping of your Toyota
Perchlorate Material
WARNING
■
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■ General precaution regard ing children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof, or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

22Pictorial index
MIRAI_OM_USA_OM62004U
■Interior
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 36
Floor mats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 145
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
Console box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 273
Inside lock buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274
Assist grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 2821
2
3
4
5
6
7
8
9

25
For safety and security1
MIRAI_OM_USA_OM62004U1-1. For safe use
Before driving ...................... 26
For safety drive ................... 28
Seat belts ............................ 30
SRS airbags ........................ 36
Front passenger occupant classification system ......... 49
Safety information for children ............................. 55
Child restraint systems........ 56
1-2. Theft deterrent system Immobilizer system ............. 72
Alarm................................... 74
Theft prevention labels........ 76

361-1. For safe use
MIRAI_OM_USA_OM62004U
SRS airbags
◆SRS front airbagsSRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front pas-
senger from impact with interior components
SRS knee airbag
Can help provide driver protection
SRS seat cushion airbag
Can help restrain the front passenger
The SRS airbags inflate when the vehicle is subjected to certain
types of severe impacts that may cause significant injury to the
occupants. They work together with the seat belts to help reduce
the risk of death or serious injury.
1
2
3

371-1. For safe use
1
For safety and security
MIRAI_OM_USA_OM62004U
◆SRS side and curtain shield airbagsSRS side airbags
Can help protect the torso and pelvis of the front seat occupants
SRS curtain shield airbags
●Can help protect primarily the head of occupants
● Can help prevent the occupants from being thrown from the
vehicle in the event of vehicle rollover
4
5

381-1. For safe use
MIRAI_OM_USA_OM62004U
SRS airbag system components
Curtain shield airbags
Side airbags
Driver airbag
Side impact sensors (rear)
Side impact sensors (front)
Seat belt pretensioners and
force limiters
Side impact sensors (front
doors)
Driver’s seat belt buckle
switch
Driver’s seat position sensorFront passenger’s seat belt
buckle switch
Front passenger occupant
classification system (ECU
and sensors)
Knee airbag
Airbag sensor assembly
Passenger seat cushion air-
bag
Front impact sensors
Front passenger airbag
SRS warning light
“AIR BAG ON” and “AIR BAG
OFF” indicator lights1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
