2016 TOYOTA MIRAI tire type

4299-1. Specifications
MIRAI_OM_USA_OM62004U
9
Vehicle specifications
Production options
weight
The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy
duty 12-volt battery, and special trim
Rim
A metal support for a tire or a tire and tube
assembly upon which the tire beads are
seated
Rim diameter
(Wheel diameter)Nominal diameter of the bead seat
Rim size designationRim diameter and width
Rim type designationThe industry manufacturer’s designation for a
rim by style or code
Rim widthNominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity)The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tire
The load on an individual tire that is deter-
mined by distributing to each axle its share of
the maximum loaded vehicle weight, and
dividing by two
Vehicle normal load on
the tire
The load on an individual tire that is deter-
mined by distributing to each axle its share of
curb weight, accessory weight, and normal
occupant weight (distributed in accordance
with Table 1
* below), and dividing by two
Weather sideThe surface area of the rim not covered by the
inflated tire
Bead
The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Bead separationA breakdown of the bond between compo-
nents in the bead
Tire related termMeaning

448What to do if... (Troubleshooting)
MIRAI_OM_USA_OM62004U
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 371)
●The brake system warning light is on
Is the parking brake released? (P. 186)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 369, 376)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 74)
To stop the alarm, turn the power switch to ON mode or start the fuel cell sys-
tem.

●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( P. 376)
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 369, 376.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (P. 381)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 412)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
An alarm is activated and the horn sounds
A warning light turns on or a warning message or indicator
is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

453Alphabetical index
MIRAI_OM_USA_OM62004U
Flat tire...................................... 381
Floor mats .................................. 26
FluidBrake .................................... 420
Transmission ........................ 420
Washer ................................. 327
Front interior lights ................. 270 Wattage ................................ 421
Front passenger occupant classification system .............. 49
Front seats ............................... 138
Adjustment ............................ 138
Cleaning................................ 310
Correct driving posture ........... 28
Driving position memory ....... 140
Head restraints ..................... 145
Power easy access system ......... ....................... 140
Seat heaters ......................... 268
Seat position memory ........... 140
Front side marker lights.......... 187 Light switch ........................... 187
Replacing light bulbs............. 358
Front turn signal lights ........... 185 Replacing light bulbs............. 358
Turn signal lever ................... 185
Fuel
Capacity ................................ 418
Fuel gauge ............................ 102
Hydrogen station information.......................... 464
Refueling............................... 198
Type .............................. 198, 418
Warning light ......................... 371
Fuel cell stack ............................ 86
Fuel cell stack coolant Capacity ................................ 419
Checking ............................... 324 Fuel cell system
Characteristics ........................ 78
Cold temperatures ................ 175
Coolant type ......................... 419
Indicators .............................. 100
Multi-information display ....... 107
Precautions............................. 82
Starting the system ............... 172
Stopping the system ............. 173
Warning lights ......................... 99
Fuel cell system indicator ...... 110
Fuel cell vehicles
Characteristics ........................ 78
Charging the traction battery .................................. 81
Driving advice ......................... 94
Emergency shut off system .... 84
Emergency start function ...... 397
Emergency stops .................. 361
Fuel....................................... 418
Handling hydrogen gas........... 90
High-voltage components ....... 83
Hydrogen gas ......................... 89
Hydrogen-related components.......................... 82
If the 12-volt battery is discharged.......................... 401
If the fuel cell system will not start ........................ 396
Maintenance, repair,
recycling, and disposal ......... 81
F

458Alphabetical index
MIRAI_OM_USA_OM62004U
Radar cruise control (dynamic radar cruise control) ............. 203
Radiator .................................... 325
Radio
*
Rear Crossing Traffic Alert ..... 245
Rear interior lights................... 270 Wattage ................................ 421
Rear side marker lights ........... 187
Light switch ........................... 187
Replacing light bulbs............. 358
Rear turn signal lights............. 185
Replacing light bulbs............. 358
Turn signal lever ................... 185
Rear view mirror
Inside rear view mirror .......... 149
Outside rear view mirrors...... 151
Rear view monitor system
*
Rear window defogger ............ 261
Refueling .................................. 198 Capacity ................................ 418
Fuel types ............................. 418
Opening the fuel door ........... 200
Regenerative braking ................ 81
Replacing
Electronic key battery ........... 353
Fuses .................................... 355
Light bulbs ............................ 358
Tires ...................................... 339
Reporting safety defects for U.S. owners ...................... 444
Road accident cautions ............ 92 Safety Connect ........................ 299
Seat belt reminder light .......... 371
Seat belts ................................... 30
Adjusting the seat belt ............ 31
Automatic Locking Retractor (ALR) .................... 32
Child restra int system
installation ............................ 56
Cleaning and maintaining the seat belt........................ 311
Emergency Locking Retractor
(ELR) .................................... 32
How to wear your seat belt ..... 30
How your child should wear the seat belt.......................... 32
Pregnant women, proper seat belt use ......................... 33
Reminder light and buzzer.... 371
Seat belt extender .................. 32
Seat belt pretensioners........... 31
SRS warning light ................. 370
Seat heaters ............................. 268
Seat position memory ............. 140
Seating capacity ...................... 169
RS

464
MIRAI_OM_USA_OM62004U
HYDROGEN STATION INFORMATION
Auxiliary catch leverTrunk openerFuel door
P. 320 P. 126 P. 200
Hood lock release leverFuel door openerTire inflation pressure
P. 320 P. 200P. 421
Hydrogen tanks’ fuel
capacity (Reference)32.3 gal. (122.4 L, 26.9 Imp.gal.)
(Approximately 11.0 lb. [5 kg]
*)
*: This is the maximum possible fill amount. The
actual fuel amount achieved at hydrogen sta-
tions may be lower due to station capacity or
station settings.
Fuel type Compressed hydrogen gas P. 198, 418
Cold tire inflation
pressure P. 4 2 1
