2016 TOYOTA LAND CRUISER windshield wipers

LC200_OM_OM60M88U_(U)
2174-3. Operating the lights and wipers
4
Driving
The sensor sensitivity can be adjusted when “AUTO” is selected.Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers operate automati-
cally. (After operating several
times, the wipers operate one
more time after a short delay to
prevent dripping.)
■The windshield wiper and washer can be operated when
The engine switch is in IGNITION ON mode.
■ Raindrop sensor (vehicles with ra in-sensing windshield wipers)
● If the wiper switch is turned to the “AUTO” position while the engine switch is
in IGNITION ON mode, the wipers will operate once to show that “AUTO”
mode is activated.
● When the sensor sensitivity ring is turned toward high while in “AUTO”
mode, the wipers will operate once to indicate that the sensor sensitivity is
enhanced.
● If the temperature of the rain drop sensor is 185 F (85 C) or higher, or -22 F
(-30 C) or lower, the automatic operation may not occur. In this case, oper-
ate the wipers in any mode other than “AUTO”.
5
6
7
● The raindrop sensor judges the amount
of raindrops.
An optical sensor is adopted. It may not
operate properly when sunlight from the
rising or setting of the sun intermittently
strikes the windshield, or if bugs etc. are
present on the windshield.

218
LC200_OM_OM60M88U_(U)
4-3. Operating the lights and wipers
■Effects of vehicle speed on wiper operation (vehicles with rain-sensing
windshield wipers)
Vehicle speed affects the wiper operation when the washer is being used
(delay until drip prevention wiper sweep occurs) even when the wipers are
not in “AUTO” mode.
With the low speed operation selected, wiper operation will be switched from
low speed to intermittent wiper operation only when the vehicle is stationary.
(However, when the sensor sensitivity is adjusted to the highest level, the
mode cannot be switched.)
■ If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid reservoir.
WARNING
■Caution regarding the use of windshie ld wipers in “AUTO” mode (vehi-
cles with rain-sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or
the windshield is subject to vibration in “AUTO” mode. Take care that your
fingers etc. anything else does not become caught in the windshield wipers.
■ Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.
NOTICE
■When the windshield is dry
Do not use the wipers, as they may damage the windshield.
■ When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may over-
heat.
■ When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled
toward you and held continually.
■ When a nozzle becomes blocked
Do not try to clear it with a pin or other object. The nozzle will be damaged\
.

230
LC200_OM_OM60M88U_(U)
4-5. Using the driving support systems
WARNING
■To avoid malfunction of the camera sensor
Observe the following precautions.
Otherwise, the camera sensor may not operate properly, possibly leading to
an accident resulting in death or serious injury.
●Keep the windshield clean at all times.
If the windshield is dirty or covered with an oily film, water droplets, snow,
etc., clear the windshield.
If the inner side of the windshield where the camera sensor is installed is
dirty, contact your Toyota dealer.
● If the part of the windshield in front of the camera sensor is fogged up or
covered with condensation or ice, use the windshield defogger to remove
the fog, condensation or ice. ( P. 374)
● Do not apply glass coating agents to the area of the windshield in front of
the camera sensor.
Glass coating agents can be applied to the windshield in areas other than
in front of the camera sensor. However, it will still be necessary to use the
wipers if the area of the windshield in front of the camera sensor is cov-
ered with water droplets.
● If water droplets cannot be properly removed from the area of the wind-
shield in front of the camera sensor by the windshield wipers, replace the
wiper insert or wiper blade.
If the wiper inserts or wiper blades need to be replaced, contact your
Toyota dealer.
● Do not attach window tinting to the windshield.
● Replace the windshield if it is damaged or cracked.
If the windshield needs to be replaced, contact your Toyota dealer.
● Do not get the camera sensor wet.
● Do not allow bright lights to shine into the camera sensor.
● Do not dirty or damage the camera sensor.
When cleaning the inside of the windshield, do not allow glass cleaner to
contact the lens. Also, do not touch the lens.
If the lens is dirty or damaged, contact your Toyota dealer.
● Do not subject the camera sensor to a strong impact.
●Do not install an antenna or attach stick-
ers (including transparent stickers) or
other items to the area of the windshield
in front of the camera sensor (shaded
area in the illustration).

LC200_OM_OM60M88U_(U)
4456-2. Maintenance
6
Maintenance and care
Vehicle exterior
ItemsCheck points
Doors• Do the doors operate smoothly?
Engine hood• Does the engine hood lock system work prop-erly?
Fluid leaks• There should not be any signs of fluid leakageafter the vehicle has been parked.
Tires
• Is the tire inflation pressure correct?
• The tires should not be damaged or exces-sively worn.
• Have the tires been rotated according to the
maintenance schedule?
• The wheel nuts should not be loose.
Windshield wipers/rear
window wiper
• The wiper blades should not show any signs
of cracking, splitting, wear, contamination or
deformation.
• The wiper blades should clear the windshield/
rear window without streaking or skipping.
WARNING
■If the engine is running
Turn off the engine and ensure that there is adequate ventilation before per-
forming maintenance checks.

603Alphabetical index
LC200_OM_OM60M88U_(U)
Safety Connect ........................ 427
Scheduled maintenance ......... 440
Seat belts.................................... 30Adjusting the seat belt ............ 33
Automatic Locking Retractor............................... 34
Child restra int system
installation ............................ 63
Cleaning and maintaining the seat belt ........................ 438
Emergency Locking
Retractor............................... 34
How to wear your seat belt ..... 30
How your child should wear the seat belt ................. 34
Pregnant women, proper seat belt use ......................... 35
Reminder light and buzzer................................. 512
Seat belt extender................... 34
Seat belt pretensioners ........... 33
SRS warning light ................. 510
Seat heaters ............................. 390
Seat position memory ............. 136
Seat ventilators ........................ 390
Seating capacity ...................... 175 Seats ................................. 127, 129
Adjustment.................... 127, 129
Adjustment
precautions................. 128, 135
Armrest ................................. 420
Child seats/child restraint
system installation ................ 63
Cleaning ............................... 437
Driving position memory ....... 136
Folding up the third seats................................... 132
Front seats............................ 127
Head restraint ....................... 140
Heaters ................................. 389
Properly sitting in the seat ...... 28
Seat heaters ......................... 389
Seat position memory ........... 136
Seat ventilators ..................... 389
Second seats ........................ 129
Third seats ............................ 129
Tumbling the second seats................................... 130
Ventilators............................. 389
Sensor Automatic headlight system .......... ...................... 207
Automatic High Beam
system .......... ...................... 230
Inside rear view mirror .......... 146
Intuitive parking assist .......... 272
LDA (Lane Departure Alert)................................... 248
Radar sensor ........................ 228
Rain-sensing windshield
wipers ................................. 217
Service reminder indicators ..... 80
S
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

605Alphabetical index
LC200_OM_OM60M88U_(U)
Meter control switches ............ 91
Moon roof switches ............... 154
Outside rear view mirror switches.............................. 147
Personal light switch ............. 395
Power door lock switch ......... 108
Power window switch............ 150
Rear window wiper and
washer switch ..................... 219
Rear window and outside rear view mirror
defoggers switch ................ 380
Seat heater switches ............ 390
Seat ventilator switches ........ 390
“SOS” button ......................... 427
Talk switch
*
Telephone switches*
Tilt and telescopic steering control switch...................... 143
Tire pressure warning
reset switch ........................ 465
Vehicle-to-vehicle distance button ................................. 263
VSC OFF switch ................... 359
Window lock switch............... 150
Windshield wipers and washer switch ..................... 215
Wireless charger power supply switch ...................... 412 Tachometer ................................ 85
Tail lights.................................. 205
Light switch ........................... 205
Replacing light bulbs ............ 497
Talk switch
*
Telephone switches*
Theft deterrent system Alarm ...................................... 76
Immobilizer system .. ............... 74
Tire inflation pressure............. 472 Maintenance data ................. 558
Warning light......................... 512
Tire information ....................... 563 Glossary ............................... 569
Size....................................... 565
Tire identification number ..... 564
Uniform Tire Quality
Grading .............................. 567
Tire pressure warning system.................................... 464
Function ................................ 464
Initializing .............................. 464
Installing tire pressure warning valves and
transmitters ........................ 464
Registering ID codes ............ 465
Tire pressure warning reset switch ........................ 465
Warning light......................... 512
T
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

607Alphabetical index
LC200_OM_OM60M88U_(U)
Warning buzzers ...................... 510Approach warning ................. 264
Brake system ....... ................. 510
Downshifting ......................... 202
Driver’s seat belt reminder ............................. 512
Intuitive parking assist .......... 275
Lane departure ..................... 253
Master warning system ......... 512
Open back door .................... 512
Open door ............................. 512
Parking brake........................ 204
PCS ...................................... 511
Radar cruise control.............. 264
Seat belt reminder ................ 512
Warning lights.......................... 510 ABS....................................... 511
Brake system ....... ................. 510
Center differential lock .......... 514
Charging system ................... 510
Low fuel level ........................ 512
Low speed four-wheel drive.................................... 514
Malfunction indicator lamp .... 510
Master warning light.............. 512
Open door ............................. 512
Pre-collision system .............. 511
Seat belt reminder light ......... 512
Slip indicator ......................... 511
SRS ...................................... 510
Tire pressure......................... 512 Warning messages.................. 519
Warning reflector holder......... 404
Washer ............................. 215, 219
Checking............................... 462
Preparing and checking before winter ...................... 369
Switch ........................... 215, 219
Washing and waxing ............... 434
Weights
Cargo capacity...................... 175
Load limits ............................ 175
Weights................................. 552
What to do if... (Troubleshooting) ................. 588
Wheels ...................................... 475 Replacing wheels ................. 524
Size....................................... 558
Window glasses ...................... 150
Window lock switch ................ 150
Windows Power windows..................... 150
Rear window defogger.......... 380
Washer ......................... 215, 219
Windshield wiper de-icer ........ 380
Windshield wipers ................... 215 Intermittent windshield wipers ................................. 215
Rain-sensing windshield wipers ................................. 216
Winter driving tips ................... 369
Wireless charger ..................... 412
Wireless remote control key .......................................... 102
Battery-saving function ......... 122
Locking/Unlocking ................ 102
Panic mode........................... 103
Replacing the battery............ 479
WMA disc
*
W
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
