2016 TOYOTA LAND CRUISER service indicator

427
LC200_OM_OM60M88U_(U)
5-4. Using the other interior features
5
Interior features
Safety Connect
Microphone
LED light indicators
“SOS” button
: If equipped
Safety Connect is a subscription-based telematics service that
uses Global Positioning System (GPS) data and embedded cel-
lular technology to provide safety and security features to sub-
scribers. Safety Connect is supported by Toyota’s designated
response center, which operates 24 hours per day, 7 days per
week.
Safety Connect service is avai lable by subscription on select,
telematics hardware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be
bound by the Telematics Subscription Service Agreement and
its Terms and Conditions, as in ef fect and amended from time to
time, a current copy of which is available at Toyota.com. All use
of the Safety Connect service is subject to such then-applicable
Terms and Conditions.
System components
1
2
3

LC200_OM_OM60M88U_(U)
4295-4. Using the other interior features
5
Interior features
■Languages
The Safety Connect response center will offer support in multiple languages.
The Safety Connect system will offer voice prompts in English and Spanish.
Please indicate your language of choice when enrolling.
■ When contacting th e response center
You may be unable to contact the response center if the network is busy.
■ Safety Connect backup battery depletion
An exclusive backup battery is built in to assist the Automatic Collision Notifi-
cation, which is activated when impact above a certain level is applied to the
vehicle, or when the airbags operate. This battery is a primary battery, and
cannot be recharged. The red LED indicator will flash to indicate that the bat-
tery should be replaced.
The backup battery will need to be replaced if the Automatic Collision Notifi-
cation operates for 60 seconds or more. For replacement, consult your Toy-
ota dealer.
When the engine switch is turned to IGNITION ON mode, the red indi-
cator light comes on for 2 seconds then turns off. Afterward, the green
indicator light comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage
conditions:
● Green indicator light on = Active service
● Green indicator light flashing = Sa fety Connect call in process
● Red indicator light (except at vehi cle start-up) = System malfunction
(contact your Toyota dealer)
● No indicator light (off) = Safety Connect service not active
Safety Connect LE D light Indicators

446
LC200_OM_OM60M88U_(U)
6-2. Maintenance
Emission inspection and maintenance (I/M)
programs
The OBD system determines that a problem exists somewhere in the
emission control system. Your vehicl e may not pass the I/M test and
may need to be repaired. Contact your Toyota dealer to service the
vehicle.
● When the battery is disconnected or discharged
Readiness codes that are set duri ng ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may
not be completely set.
● When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary
malfunction and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehi-
cle is driven 40 or more times.
Contact your Toyota dealer to prepare the vehicle for re-testing.
Some states have vehicle emission inspection programs which
include OBD (On Board Diagnos tics) checks. The OBD system
monitors the operation of the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M test in the following situations:
When the malfunction indicator lamp still remains on after sev-
eral driving trips
If your vehicle does not pass the I/M test

LC200_OM_OM60M88U_(U)
5618-1. Specifications
8
Vehicle specifications
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure that it has an octane rating no
lower than 87.
● Toyota does not recommend the use of gasoline containing methanol.
■ Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy
clopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of gasoline that contains MMT. If fuel
containing MMT is used, your emission control system may be adversely
affected.
The malfunction indicator lamp on the instrument cluster may come on. If this
happens, contact your Toyota dealer for service.
■ If your engine knocks
●Consult your Toyota dealer.
● You may occasionally notice light knocking for a short time while accelerat-
ing or driving uphill. This is normal and there is no need for concern.
●
Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from any pump labeled
E30, E50, E85 (which are only some
examples of fuel containing more than
15% ethanol).
DO NOT use gasoline
containing more than 15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

603Alphabetical index
LC200_OM_OM60M88U_(U)
Safety Connect ........................ 427
Scheduled maintenance ......... 440
Seat belts.................................... 30Adjusting the seat belt ............ 33
Automatic Locking Retractor............................... 34
Child restra int system
installation ............................ 63
Cleaning and maintaining the seat belt ........................ 438
Emergency Locking
Retractor............................... 34
How to wear your seat belt ..... 30
How your child should wear the seat belt ................. 34
Pregnant women, proper seat belt use ......................... 35
Reminder light and buzzer................................. 512
Seat belt extender................... 34
Seat belt pretensioners ........... 33
SRS warning light ................. 510
Seat heaters ............................. 390
Seat position memory ............. 136
Seat ventilators ........................ 390
Seating capacity ...................... 175 Seats ................................. 127, 129
Adjustment.................... 127, 129
Adjustment
precautions................. 128, 135
Armrest ................................. 420
Child seats/child restraint
system installation ................ 63
Cleaning ............................... 437
Driving position memory ....... 136
Folding up the third seats................................... 132
Front seats............................ 127
Head restraint ....................... 140
Heaters ................................. 389
Properly sitting in the seat ...... 28
Seat heaters ......................... 389
Seat position memory ........... 136
Seat ventilators ..................... 389
Second seats ........................ 129
Third seats ............................ 129
Tumbling the second seats................................... 130
Ventilators............................. 389
Sensor Automatic headlight system .......... ...................... 207
Automatic High Beam
system .......... ...................... 230
Inside rear view mirror .......... 146
Intuitive parking assist .......... 272
LDA (Lane Departure Alert)................................... 248
Radar sensor ........................ 228
Rain-sensing windshield
wipers ................................. 217
Service reminder indicators ..... 80
S
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
