1. Phone operation
(Hands-free system
for cellular phones)
Quick reference....................... 212
Some basics ........................... 212
Registering/connecting a
Bluetooth® phone.................... 213
Using the phone switch/
microphone ............................. 213
Voice command system ............ 214
About the contacts in the
contact list ............................... 214
When selling or disposing of the
vehicle ..................................... 214
Calling on the Bluetooth®
phone .................................... 215
By favorites list .......................... 216
By call history ............................ 216
By contacts list .......................... 217
By dial pad................................. 218
By off hook switch ..................... 219
Receiving on the Bluetooth®
phone .................................... 219
Incoming calls ........................... 219
Talking on the Bluetooth®
phone .................................... 220
Incoming call waiting ................. 221
Bluetooth® phone message
function ................................. 222
Receiving a message................ 222
Checking messages.................. 223
Replying to a message
(Quick reply) ........................... 224
Calling the message sender ..... 225
2. Setup
Phone/message settings ......... 226
Phone/message settings
screen .................................... 226
“Sound Settings” screen .......... 227
“Contact/Call History Settings”
screen..................................... 228
“Messaging Settings” screen .... 235
“Phone Display Settings”
screen..................................... 236
3. What to do if...
Troubleshooting....................... 237
Phone

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2121. Phone operation (Hands-free system for cellular phones)
Quick reference
The phone top screen can be used to
make a phone call. To display the
hands-free operation screen, press the
button or the switch on the
steering wheel.
Several functions are available to op-
erate on each screen that is displayed
by selecting the 4 tabs.
FunctionPage
Phone operation
Registering/connecting
Bluetooth® device32
Calling on the Bluetooth® phone215
Receiving on the Bluetooth®
phone219
Talking on the Bluetooth® phone220
Message function
Using the Bluetooth® phone mes-
sage function222
Setting up a phone
Phone settings226
Bluetooth® settings36
Some basics
The hands-free system enables calls
to be made and received without hav-
ing to take your hands off the steering
wheel.
This system supports Bluetooth
®.
Bluetooth
® is a wireless data system
that enables cellular phones to be used
without being connected by a cable or
placed in a cradle.
The operating procedure of the phone
is explained here.
WA R N I N G
●While driving, do not use a cellular
phone or connect the Bluetooth® phone.
●Your audio unit is fitted with Bluetooth
®
antennas. People with implantable car-
diac pacemakers, cardiac resynchroni-
zation therapy-pacemakers or
implantable cardioverter defibrillators
should maintain a reasonable distance
between themselves and the Bluetooth
®
antennas. The radio waves may affect
the operation of such devices.
●Before using Bluetooth
® devices, users
of any electrical medical device other
than implantable cardiac pacemakers,
cardiac resynchronization therapy-pace-
makers or implantable cardioverter
defibrillators should consult the manu-
facturer of the device for information
about its operation under the influence
of radio waves. Radio waves could have
unexpected effects on the operation of
such medical devices.
NOTICE
●Do not leave your cellular phone in the
vehicle. The temperature inside may rise
to a level that could damage the phone.

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2131. Phone operation (Hands-free system for cellular phones)
Phone
7
Steering switch
Volume control switch
Press the “+” side to increase the volume.
Press the “-” side to decrease the vol-
ume.
Off hook switch
On hook switch
Microphone
INFORMATION
●If your cellular phone does not support
Bluetooth®, this system cannot function.
●In the following conditions, the system
may not function:
• The cellular phone is turned off.
• The current position is outside the
communication area.
• The cellular phone is not connected.
• The cellular phone has a low battery.
●When using Bluetooth
® audio and
hands-free system at the same time, the
following problems may occur:
• The Bluetooth
® connection may be
cut.
• Noise may be heard on the Bluetooth
®
audio playback.
Registering/connecting a
Bluetooth® phone
To use the hands-free system for cellu-
lar phones, it is necessary to register a
cellular phone with the system.
(P.32)
Bluetooth® phone condition
display
The condition of the Bluetooth
® phone
appears on the upper right side of the
screen. (P.11)
Using the phone switch/
microphone
By pressing the phone switch, a call
can be received or ended without tak-
ing your hands off the steering wheel.
The microphone is used when talking
on the phone.

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2151. Phone operation (Hands-free system for cellular phones)
Phone
7
1Press the button.
2Select the desired tab to call from.
The phone top screen can be displayed by
pressing the
switch on the steering
wheel.Calling on the Bluetooth®
phone
After a Bluetooth® phone has been
registered, a call can be made using
the hands-free system. There are sev-
eral methods by which a call can be
made, as described below.How to make a callPage
By favorites list216
By call history216
By contacts list*217
By dial pad*218
By e-mail/SMS/MMS225
By POI call63
By off hook switch219
By Entune App Suite*253
By voice command system197
*: The operation cannot be performed
while driving.

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2171. Phone operation (Hands-free system for cellular phones)
Phone
7
1Display the phone top screen.
(P.215)
2Select the “Contacts” tab and select
the desired contact.
3Select the desired number.
4Check that the “Call” screen is dis-
played.
■For PBAP compatible Bluetooth®
phones
When “Automatic Contact/History
Transfer” is set to on (P.228)
1Select the “Contacts” tab.
Contacts are transferred automatically.
2Check that a confirmation screen is
displayed when the operation is com-
plete.
When “Automatic Contact/History
Transfer” is set to off (P.228)
1Select the “Contacts” tab.
2Select the desired item.
INFORMATION
●When making a call to the same number
continuously, only the most recent call is
listed in call history.
●When a phone number registered in the
contact list is received, the name is dis-
played.
●Number-withheld calls are also memo-
rized in the system.
●International phone calls may not be
made depending on the type of cellular
phone you have.
●The list should group together consecu-
tive entries with the same phone number
and same call type. For example, two
calls from John’s mobile would be dis-
played as follows: John (2)
●By pressing the
switch on the
steering wheel, a call to the latest history
item can be made.
By contacts list
Calls can be made by using contact
data which is transferred from a regis-
tered cellular phone. (P.217)
Up to 2500 contacts (maximum of 4
phone numbers and e-mail addresses
per contact) can be registered in the
contact list.
When the contact is empty
No.Function
Select to always transfer all the con-
tacts from a connected cellular
phone automatically.
Select to transfer all the contacts
from a connected cellular phone
only once.
Select to cancel transferring.

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2181. Phone operation (Hands-free system for cellular phones)
3Check that a confirmation screen is
displayed when the operation is com-
plete.
■For PBAP incompatible but OPP
compatible Bluetooth
® phones
1Select the “Contacts” tab.
2Select the desired item.
When “Transfer” is selected
3Follow the steps in “For PBAP
incompatible but OPP compatible
Bluetooth
® phones” from step 3.
(P.229)
When “Add” is selected
3Follow the steps in “Registering a new
contact to the contact list” from step 2.
(P.230)
1Display the phone top screen.
(P.215)
2Select the “Dial Pad” tab and enter the
phone number.
3Select or press the switch
on the steering wheel.
4Check that the “Call” screen is dis-
played.
No.Function
Select to transfer the contacts from
the connected cellular phone.
Select to add a new contact manual-
ly.
Select to cancel transferring.
INFORMATION
●Manual transfer operation cannot be
performed while driving.
●If your cellular phone is neither PBAP
nor OPP compatible, the contacts can-
not be transferred.
●Depending on the type of Bluetooth
®
phone:
• It may be necessary to perform addi-
tional steps on the phone when trans-
ferring contact data.
• The registered image in the contact list
may not transfer depending on the
type of Bluetooth
® phone connected.
By dial pad
INFORMATION
●Depending on the type of Bluetooth®
phone being connected, it may be nec-
essary to perform additional steps on
the phone.

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2191. Phone operation (Hands-free system for cellular phones)
Phone
7
1Press the switch on the steering
wheel to display the phone top screen.
2Press the switch on the steering
wheel to display the “Call History”
screen.
3Press the switch on the steering
wheel to call the latest history item.
4Check that the “Call” screen is dis-
played.
1Select or press the switch
on the steering wheel to talk on the
phone.
To refuse to receive the call: Select
or press the switch on the
steering wheel.
To adjust the volume of a received call:
Turn the “PWR·VOL” knob, or use the vol-
ume control switch on the steering wheel.
By off hook switch
Calls can be made using the latest call
history item.Receiving on the
Bluetooth® phone
Incoming calls
When a call is received, this screen is
displayed with a sound.
INFORMATION
●During international phone calls, the
other party’s name or number may not
be displayed correctly depending on the
type of cellular phone you have.
●The incoming call display mode can be
set. (P.236)
●The ringtone that has been set in the
“Sound Settings” screen sounds when
there is an incoming call. Depending on
the type of Bluetooth
® phone, both the
navigation system and Bluetooth®
phone may sound simultaneously when
there is an incoming call. (P.227)

LC200_Navi_OM60N15U_(U)
15.07.15 16:32
2201. Phone operation (Hands-free system for cellular phones)
■By dial pad
1Select “0-9”.
2Enter the desired number.
■By selecting “Release Tones”
1Select “Release Tones”.
Talking on the Bluetooth®
phone
While talking on the phone, this screen
is displayed. The operations outlined
below can be performed on this
screen.
No.FunctionPage
Select to display the dial
pad to send tones.220
Select to mute your voice
to the other party.
Select to change handset
modes between hands-
free and cellular phone.
Select to adjust your voice
volume that the other party
hears from their speaker.
221
Select to send tones. This
button only appears when
a number that contains a
(w) is dialed in hands-free
mode.
220
Select to hang up the
phone.
Select “+” or “-” to adjust
the volume of the other par-
ty’s voice.

Select to start talking with
the other party.221
INFORMATION
●Changing from hands-free call to cellular
phone call is not possible while driving.
●When cellular phone call is changed to
hands-free call, the hands-free screen
will be displayed and its functions can be
operated on the screen.
●Changing between cellular phone call
and hands-free call can be performed by
operating the cellular phone directly.
●Transferring methods and operations
will be different depending on the type of
cellular phone you have.
●For the operation of the cellular phone,
see the manual that comes with it.
Sending tones
This operation cannot be performed
while driving.
“Release Tones” appear when a con-
tinuous tone signal(s) containing a (w)
is registered in the contact list.
This operation can be performed while
driving.
