2016 TOYOTA COROLLA Specifications

5779-2. Customization
9
Vehicle specifications
COROLLA_TMMMS_TMMC_U (OM12J84U)
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.
Settings that can be changed us ing the multimedia system/naviga-
tion system
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, —=Not available
n
Door lock ( P. 101, 110, 541)
Customizable features
1
2
FunctionDefault settingCustomized set-
ting
Unlocking using a key
Driver’s door
unlocked in one
step, all doors
unlocked in two steps
All doors unlocked in one step—O
Speed-detecting auto-
matic door lock function
(vehicles with a smart key
system)
OffOn
OO
Opening driver's door
unlocks all doorsOffOn
Shifting gears to P unlocks
all doors. (except vehicles
with a manual transmis-
sion)
OnOff
OOShifting gears to position
other than P locks all
doors. (except vehicles
with a manual transmis-
sion)
OnOff
Locking/unlocking of the
trunk when all doors are
locked/unlocked
OnOff—O
12

5799-2. Customization
9
Vehicle specifications
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Smart key system* (
 P. 101, 110, 115)
*: If equipped
n
Wireless remote control* (  P. 96, 101, 110)
*: If equipped
FunctionDefault settingCustomized set-
ting
Smart key systemOnOff—O
Number of permissible
times of continuous smart
lock Twice Unlimited — O
12
FunctionDefault settingCustomized set-
ting
Wireless remote controlOnOff—O
Unlocking operation
Driver’s door
unlocked in one
step, all doors
unlocked in two steps
All doors unlocked in one stepOO
Trunk unlocking operationPress and hold (short)
One short press
—O
Push twice
Press and hold (long)
Off
Alarm (panic mode)OnOff—O
12

5819-2. Customization
9
Vehicle specifications
COROLLA_TMMMS_TMMC_U (OM12J84U)n
Lights (
P. 188)
*: U.S.A. only
n
Automatic air conditioning system* (  P. 392)
*: If equipped
n
Illumination ( P. 401)
*: Vehicles with a smart key system
FunctionDefault settingCustomized set-
ting
Daytime running light sys-
tem
*OnOffOO
12
FunctionDefault settingCustomized set-ting
Air conditioning auto
switch operationOnOffOO
12
FunctionDefault settingCustomized set-
ting
Time elapsed before the
interior lights turn off15 seconds7.5 secondsOO30 seconds
Operation after the engine
switch is turned offOnOff—O
Operation when the doors
are unlockedOnOff—O
Operation when you
approach the vehicle with
the electronic key on your
person
*
OnOff—O
12

583
9
Vehicle specifications
COROLLA_TMMMS_TMMC_U (OM12J84U)
9-3. Items to initialize
Items to initialize
The following items must be initialized for normal system opera-
tion after such cases as maintenance being performed on the
vehicle:
ItemWhen to initializeReference
Maintenance required
reminder light (vehicles with
a drive monitor display) or
message indicating mainte-
nance is required (vehicles
with a multi-information dis-
play)
(U.S.A. only)
• After the maintenance is per- formedP. 427
Tire pressure warning sys-
tem (if equipped)
• When rotating the tires
• When changing the tireinflation pressure by
changing traveling speed
or load weight, etc.
P. 4 5 6

616Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
Shift lever ......... 176, 178, 180, 184Automatic transmission......... 176
Continuously variable
transmission ............... 178, 180
If the shift lever cannot
be shifted from P ................ 534
Manual transmission ............. 184
Shift lock system ..................... 534
Side airbags ............................... 34
Side marker lights ................... 188 Light switch ........................... 188
Replacing light bulbs..... 480, 482
Wattage ................................ 559
Side mirrors ............................. 135
Adjusting and folding ............ 135
Side turn signal lights ............. 186 Replacing light bulbs............. 485
Turn signal lever ................... 186
Wattage ................................ 559
Smart key system .................... 115
Antenna location ................... 115
Entry functions .............. 101, 110
Starting the engine................ 168
Snow tires ................................ 223
Spare tire .................................. 520 Inflation pressure .................. 558
Storage location .................... 521
Spark plug ................................ 554
Specifications .......................... 550
Speech command system
*.... 381
Speedometer ........................ 77, 82
Steering lock Column lock release ..... 166, 173
Steering lock system warning
message ............................. 516
Steering wheel ......................... 131
Adjustment ............................ 131
Audio switches
*............ 233, 292
Stop lights
Replacing light bulbs............. 482 Storage feature ........................ 404
Stuck
If the vehicle becomes stuck ................................... 547
Sun shade
Roof ...................................... 142
Sun visors ................................ 409
Switches Audio remote control switches
*................... 233, 292
Compass switch ................... 413
Cruise control switch ............ 201
“DISP” switch .................... 79, 84
Door lock switches................ 104
“ECO MODE” switch............. 179
Emergency flashers switch ................................. 488
Engine switch ............... 165, 168
Fog light switch ..................... 195
Ignition switch ............... 165, 168
Light switches ....................... 188
Moon roof switches............... 141
Outside rear view mirror switches ............................. 135
Paddle shift switches .... 181, 182
Power door lock switch ......... 104
Power window switches........ 137
Rear window and outside rear view mirror
defoggers switch ........ 387, 395
Seat heater switches ............ 417
Sport mode switch ................ 181
Talk switch
*.......................... 381
Telephone switches
*.... 267, 359
Tire pressure warning reset switch ................................. 456
VSC OFF switch ................... 216
Window lock switch .............. 137
Windshield wiper and washer switch..................... 196
