2016 SUBARU LEGACY Multimedia System Manual

BASIC OPERATION
207
NAVIGATION SYSTEM
8
ORIENTATION OF THE MAP
The orientation of the map can be changed between 2D
north-up, 2D heading-up and 3D.
1. Select or .
XNorth-up screen
XHeading-up screen
X3D screen

”: 2D north-up symbol
Regardless of the direction of vehicle travel, north is
always up.

”
: 2D heading-up and 3D symbol
The direction of vehicle travel is always up.

”The letter(s) indicate the vehicle’s heading direction
(e.g. N for north).

BASIC OPERATION
208
POSITION MARKER
SELECTED MAP LOCATION (CURSOR)
Use one of the following methods to mark a map location.

”Select the map during navigation.

”Select the map when the destination you want is
displayed in the search results.

”Select the map in “Find on Map (Find on Map)”.
You can use the cursor’s position as the route’s destination,
search for locations around the cursor, and save the position
in the destination list.

”After selecting a map location, a cursor is displayed
at the point selected on the map. The cursor is
displayed as a red point (
) and can be checked at
all zoom levels.
TRAFFIC INFORMATION
DISPLAYING TRAFFIC INFORMATION
5RDG VHFWLRQV DIIHFWHG E\ WUDI

DESTINATION SEARCH
209
NAVIGATION SYSTEM
8
DESTINATION SEARCH
DESTINATION SEARCH SCREEN
The “Destination (Destination)” screen enables to search
for a destination. To display the “Destination (Destination)”
screen, select
, or select and then select
MAP (MAP), and select Menu (Menu) on the “MAP
(MAP)” screen. Then select
Destination (Destination) on
the navigation menu screen.
No. Function Page
Select to search for a destination by address. 211
Select to search for a destination by point of
interest.214
Select to search for a destination by the map. 218
Select to search for a destination from
destination list.218
Select to search for a destination from
frequently used destination.219
Select to search for a destination from
previously set destinations.219
Select to search for a destination by
coordinates.219
Select to set a destination by home. 211

DESTINATION SEARCH
210
SEARCH OPERATION
1. Select , or select and then select MAP
(MAP).
2. Select Menu (Menu).
3. Select Destination (Destination).
4. Search for a destination.

”There are different kinds of methods to search for a
GHVWLQDWLRQ
:3

”The map is displayed in full-screen mode with the
selected point at the center.
”If necessary, you can touch another point on the map
to change the destination.

”The cursor (
) is displayed at the new position.
5. Select Next (Next) (when a route has been set) or
Select (Select) (when no route has been set) to set the
destination.
No. Function
Select to return to the previous location when the map
has been moved.
Displays the name and address of the spot.
Select to open another screen displaying information on
the selected map position.
Select to select another destination.
Select to display the additional functions list.

”After a summary of the route plan is displayed, the
entire route is displayed on the map.

DESTINATION SEARCH
211
NAVIGATION SYSTEM
8
SETTING HOME AS DESTINATION
To use this function, it is necessary to register a home
DGGUHVV
:3
1. Display the “Destination (Destination)” screen.

:3
2. Select Go Home (Go Home).
3. Select Next (Next) (when a route has been set) or
Go! (Go!) (when no route has been set).

”The navigation system performs a search for
the route and the entire route map is displayed.

:3
SEARCHING BY FIND ADDRESS
There are 4 methods to search for a destination by address.
1. Display the “Destination (Destination)” screen.

:3
2. Select Find Address (Find Address).
3. Select Country or State/Province (Country or State/
Province).

”By default, the country and district for your current
position are displayed.
4. Select the desired country or state (province).
5. Select the desired search method.
No. Function Page
Select to search by city. 212
Select to search by street. 212
Select to search by intersection. 213
Select to search by city/town center. 212

DESTINATION SEARCH
212
SEARCHING BY CITY
1. Select City (City).
2. Enter a city name or ZIP Code.

”Refer to “HINTS FOR QUICK ADDRESS ENTRY” for
LQIRUPDWLRQRQTXLFNHUVHDUFKLQJ
:3
3. Select the desired city name or ZIP Code.
4. Select Street (Street).
5. Enter a street name.

”Refer to “HINTS FOR QUICK ADDRESS ENTRY” for
LQIRUPDWLRQRQTXLFNHUVHDUFKLQJ
:3
6. Select the desired street name.
7. Select House Number (House Number).
8. Enter a house number.

”If the house number is not found, the center of the
street is selected as the destination.
9. Select Next (Next) (When a route has been set) or
Go! (Go!) (when no route has been set).
NOTE
OIf the destination is to be used frequently, it can be saved to the
destination list before selecting
Next (Next) (when a route
has been set) or
Go! (Go!) (when no route has been set).

:3
QSEARCHING BY CITY/TOWN CENTER
1. Select Select City (Select City) without entering the
street name.

”Set the city/town center displayed as the route’s
destination.
SEARCHING BY STREET
1. Select Street (Street).
2. Enter a street name.

”Refer to “HINTS FOR QUICK ADDRESS ENTRY” for
LQIRUPDWLRQRQTXLFNHUVHDUFKLQJ
:3
3. Select the desired street name.
4. Select Select Street (Select Street) without entering
an address.

”The center of the street is selected as the destination.

DESTINATION SEARCH
213
NAVIGATION SYSTEM
8
SEARCHING BY INTERSECTION
1. Select Intersecting Street (Intersecting Street).
2. Select from the list.

”If there are only a few roads at the intersection, the
list is displayed immediately.

”If the road is a long way off, the keyboard screen is
displayed. Use the keyboard to enter the start of the
intersection name. A list is automatically displayed
when the entered road name matches and can be
displayed on one screen.

”Refer to “HINTS FOR QUICK ADDRESS ENTRY” for
LQIRUPDWLRQRQTXLFNHUVHDUFKLQJ
:3
HINTS FOR QUICK ADDRESS ENTRY

”When entering a city/town name or a street name:
‡Only characters that can be displayed in the
search results are shown on the keyboard. Other
characters are grayed out.
‡While entering text, the most likely search result is
DOZD\VGLVSOD\HGLQWKHWH[WHQWU\

DESTINATION SEARCH
214
”You can search by road category as well as road
name. When the same word is included in names
such as the street, road, and main street, by entering
WKH
