2016 Ram ProMaster Diesel Supplement

TOW/HAUL Indicator Light
Yellow TelltaleLight What It Means
TOW/HAUL Indicator Light
This light will illuminate when TOW HAUL mode is selected.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 39

Anti-Lock Brake (ABS) Indicator Light
Yellow TelltaleLight What It Means
Anti-Lock Brake (ABS) Indicator Light
This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the igni-
tion switch is placed in the ON/RUN position and may stay on for as long as four seconds.
If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the
brake system is not functioning and service is required. However, the conventional brake
system will continue to operate normally if the BRAKE warning light is not on.
If the ABS light is on, the brake system should be serviced as soon as possible to restore the
benefits of Anti-Lock Brakes. If the ABS light does not turn on when the ignition switch is
placed in the ON/RUN position, have the light inspected by an authorized dealer.
40 UNDERSTANDING YOUR INSTRUMENT PANEL

Generic Warning Indicator Light
Yellow TelltaleLight What It Means
Generic Warning Indicator Light
The Generic Warning Light will illuminate if any of the following conditions occur: Oil
Change Request, Engine Oil Pressure Sensor Failure, External Light Failure, Fuel Cut-Off
Not Available, Parking Sensor Failure, DST System Failure.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 41

Glow Plug Indicator Light — If Equipped
Yellow TelltaleLight What It Means
Glow Plug Indicator Light
This vehicle will inhibit engine cranking when the transmission oil temperature is less than
–22° F (–30° C) and the oil temperature sensor reading indicates an engine block heater has
not been used. The Glow Plug light will flash during in cold weather for up to 10 seconds.
An externally powered electric engine block heater is available as optional equipment or
from your authorized dealer.
Turning the ignition key to the ON/RUN position illuminates the Glow Plug Light, the light
will turn off when glow plugs reach the established temperature. You can start the engine
immediately after the light turns off.
A blinking Glow Plug Light (together with a display message) indicates a failure on glow
plugs. Please see your authorized dealer as soon as possible.
42 UNDERSTANDING YOUR INSTRUMENT PANEL

Low Diesel Exhaust Fluid (DEF) Indicator Light — If Equipped
Yellow TelltaleLight What It Means
Low Diesel Exhaust Fluid (DEF) Indicator Light
The Low Diesel Exhaust Fluid (DEF) Indicator will illuminate if the vehicle is low on Diesel
Exhaust Fluid (DEF). Refer to “Starting And Operating” for further information.
Diesel Particulate Filter (DPF) Indicator Light
Yellow Telltale
Light What It Means
Diesel Particulate Filter (DPF) Indicator Light
When the light illuminates solid, the filter loading is above the specified range.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 43

Green Telltale Indicator Lights
Turn Signal Indicator Lights
Green Tell-tale Light What It Means
Turn Signal Indicator Lights
The instrument cluster arrow will flash independently for the LEFT or RIGHT turn signal as se-
lected, as well as the exterior turn signal lamp(s) (front and rear) as selected when the multi-
function lever is moved down (LEFT) or up (RIGHT).
NOTE:
•A continuous chime will sound if the vehicle is driven more than 1 mile (1.6 km) with either
turn signal on.
•Check for an inoperative outside light bulb if either indicator flashes at a rapid rate.
44 UNDERSTANDING YOUR INSTRUMENT PANEL

Front Fog Indicator Light — If Equipped
Green TelltaleLight What It Means
Front Fog Indicator Light
This indicator will illuminate when the front fog lights are on.
Park/Headlight ON Indicator Light
Green Telltale
Light What It Means
Park/Headlight ON Indicator Light
This indicator will illuminate when the park lights or headlights are turned on.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 45

Electronic Speed Control Set Indicator Light
Green TelltaleLight What It Means
Electronic Speed Control Set Indicator Light
This light will turn on when the electronic speed control has been set.
Blue Telltale Indicator Light
High Beam Indicator Light
Blue Telltale
Light What It Means
High Beam Indicator Light
This indicator shows that the high beam headlights are on. Push the multifunction control lever
away from you to switch the headlights to high beam. Pull the lever toward you to switch the
headlights back to low beam. If the driver’s door is open, and the headlights or park lights are
left on, the high beam indicator light will remain illuminated, and a chime will sound.
46 UNDERSTANDING YOUR INSTRUMENT PANEL
