2016 Ram ProMaster City Owner's Manual

WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Some vehicles will not have a convex passenger side
mirror.
Manual Folding Door Mirrors
The door mirrors are hinged to allow the mirror to be
folded rearward to help avoid damage.CAUTION!
It is recommended to fold the mirrors into the full
rearward position to resist damage when entering a
car wash or a narrow location.
Folding Mirrors
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95

Manual Outside Mirror Adjustment — If Equipped
From the inside of the vehicle, use the control lever to
adjust the mirror.
Power Outside Mirrors — If Equipped
The power mirror controls are located on the mirror flag
trim above the driver ’s door trim panel. To adjust a
mirror, turn the control knob toward the left or right
mirror positions indicated. Tilt the control wand in the
direction you want the mirror to move. When you are
finished adjusting the mirror, turn the control to the
center (neutral) position to prevent accidentally moving a
mirror.
Manual Mirror Control Lever
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Sun Visors
The driver and passenger sun visors are located on the
headliner, near the front windshield. The sun visor can be
rotated downward or up against the door glass. Your
vehicle may be equipped with courtesy mirror located on
the passenger sun visor.
Power Mirror Controls
1 — Driver Mirror Select Position
2 — Neutral Position
3 — Passenger Mirror Select Position
4 — Four-Way Mirror Control Switch
Sun Visor (Passenger Side Shown)
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97

“Slide-On-Rod” Of Sun Visor
To use the “Slide-On-Rod” feature of the sun visor, rotate
the sun visor downward and swing the sun visor so it is
parallel to the side window, grabbing the sun visor with
your left hand pull rearwards until the sun visor is in the
desired position.
SEATS
Seats are a part of the Occupant Restraint System of the
vehicle.
WARNING!
•It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured
or killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
(Continued)
WARNING! (Continued)
belts. In a collision, people riding in these areas are
more likely to be seriously injured or killed.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Manual Seat Adjustments
The front driver and passenger seats can be adjusted
forward and rearward and if equipped may be reclined
and the height and lumbar can be adjusted.
WARNING!
• Adjusting a seat while driving may be dangerous.
Moving a seat while driving could result in loss of
control which could cause a collision and serious
injury or death.
(Continued)
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!(Continued)
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious
injury or death could result from a poorly adjusted
seat belt.
Seat Adjustments
1 — Forward/Rearward Adjusting Bar
2 — Height Adjustment Lever
3 — Recliner Knob
4 — Lumbar Knob
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99

Forward And Rearward Adjustment
The adjusting bar is at the front of the seat, near the floor.
Pull the bar upward to move the seat forward or rear-
ward. Release the bar once the seat is in the desired
position. Then, using body pressure, move forward and
rearward on the seat to be sure that the seat adjusters
have latched.
Height Adjustment — If Equipped
The height adjusting lever is located on the center
outboard side of the seat. Lift up or push down on the
front lever to adjust the front of the seat up or down.
Recliner Adjustment — If Equipped
The recliner knob is on the rear outboard side of the seat.
To recline the seatback, rotate the knob rearward without
leaning back. To return the seatback to its normal upright
position, lean forward, rotate the knob forward until the
seatback is in the upright position.Lumbar Support — If Equipped
This feature allows you to increase or decrease the
amount of lumbar support. The lumbar control knob is
located on the rear upper outboard side of the seatback.
Rotate the control forward to increase and rearward to
decrease the desired amount of lumbar support.
WARNING!
•
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
adjusted properly and you could be injured. Adjust
the seat only while the vehicle is parked.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your
chest. In a collision you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Folding Rear Seat — If Equipped
To provide additional storage area, each rear seat can be
folded flat to allow for extended cargo space.
1. Locate the release lever (upper outboard side of seat),and lift it upward until the seatback releases. 2. Slowly fold down the seatback.
3. Pull forward on the lower release lever located on the
lower outboard side of seat and lift the seat for
extended cargo space.
Seatback Release Lever
Seat Release Lever
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101

4. Reverse order for original setting.
Heated Seats — If Equipped
On some models, the front driver and passenger seats
may be equipped with heaters in both the seat cushionsand seatbacks. The controls for the front heated seats are
located on the lower outboard side of the seat.
Push the button once to turn on the heated seats. The
LED on the button turns on when the heated seat is on.
Push the button a second time to shut the heating
elements off.
Extended Cargo Space
Heated Seat Control Button
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
