2016 Ram 2500 Diesel Supplement

Vehicles Not Equipped With Passive Entry
1. Without pushing the brake pedal, cycle the ignition tothe ON/RUN position (do not start the engine.)
2. Push and release the DOWNarrow button to scroll
downward through the main menu to “ Vehicle Info”.
3. Push and release the RIGHTarrow button to access
the ” Oil Life” screen.
4. Push and hold the RIGHTarrow button for one
second to access the ” Oil Life Reset” screen. 5. Push and release the
DOWNarrow button to select
“Yes”, then push and release the Rightarrow button to
select reset of the Oil Life.
6. Push and release the Uparrow button to exit the DID
screen.
NOTE: If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 255

STARTING AND OPERATING
CONTENTS
STARTING PROCEDURES ................260
▫ Manual Transmission — If Equipped .......261
▫ Automatic Transmission — If Equipped .....261
▫ Keyless Enter-N-Go — If Equipped ........261
▫ Extreme Cold Weather ..................265
▫ Normal Starting Procedure — Engine Manifold
Air Temperature Above 66° F (19° C) ........266
▫ Starting Procedure — Engine Manifold Air
Temperature 0°F To 66°F (–18°C to 19°C) .....267
▫ Starting Procedure — Engine Manifold Air
Temperature Below 0°F (-18°C) ............269▫
Starting Fluids ....................... .271
 NORMAL OPERATION — DIESEL ENGINE . . .272
▫ Cold Weather Precautions ................273
▫ Engine Idling ....................... .275
▫ Stopping The Engine ...................277
▫ Idle Shutdown ....................... .278
▫ Programmable Maximum Vehicle Speed
(Chassis Cab Only) ....................278
▫ Operating Precautions ..................279
5

▫Cooling System Tips — Automatic
Transmission ........................ .279
 ENGINE BLOCK HEATER — IF EQUIPPED . . .280
▫ Block Heater Usage ....................281
 DIESEL EXHAUST BRAKE
(ENGINE BRAKING) ....................281
 AUTOMATIC TRANSMISSION — IF
EQUIPPED .......................... .284
▫ Key Ignition Park Interlock ...............286
▫ Brake/Transmission Shift Interlock System . . .286
▫ Six-Speed Automatic Transmission — If
Equipped .......................... .286
 MANUAL TRANSMISSION — IF EQUIPPED . .298
▫ Shifting ............................ .299▫
Downshifting ....................... .300
▫ Reverse Shifting ..................... .302
 AUXILIARY SWITCHES — IF EQUIPPED .....302
 POWER TAKE OFF OPERATION — IF EQUIPPED
(CHASSIS CAB ONLY) ..................303
▫ Stationary Mode ..................... .304
▫ Mobile Mode ........................ .305
 ENGINE RUNAWAY ....................306
 FUEL REQUIREMENTS ..................307
▫ Fuel Specifications ....................308
▫ Bio-Diesel Fuel Requirements .............309
 ADDING FUEL — 2500/3500 DIESEL
MODELS ........................... .312
 ADDING FUEL — CHASSIS CAB MODELS . . .315
258 STARTING AND OPERATING

▫Fuel Filler Cap ...................... .316
▫ Avoid Using Contaminated Fuel ...........316
▫ Bulk Fuel Storage — Diesel Fuel ..........316
▫ Diesel Exhaust Fluid Storage ..............317▫
Adding Diesel Exhaust Fluid .............318
 DIESEL EXHAUST FLUID .................322
▫ System Overview ..................... .322
5
STARTING AND OPERATING 259

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
The starter should not be operated for more than 15-
second intervals. Waiting a few minutes between such
intervals will protect the starter from overheating.
WARNING!
•Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
•
When leaving the vehicle, always remove the key fob
from the ignition and lock your vehicle. If equipped
with Keyless Enter-N-Go, always make sure the key-
less ignition node is in “OFF” mode, remove the Key
Fob from the vehicle and lock the vehicle.
(Continued)
WARNING! (Continued)
•Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Allowing children to
be in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Children should be
warned not to touch the parking brake, brake pedal
or the gear selector.
• Do not leave the key fob in or near the vehicle (or
in a location accessible to children), and do not
leave the ignition (of a vehicle equipped with
Keyless Enter-N-Go) in the ACC or ON/RUN
mode. A child could operate power windows, other
controls, or move the vehicle.
260 STARTING AND OPERATING

Manual Transmission — If Equipped
Apply the parking brake, place the shift lever in NEU-
TRAL and press the clutch pedal to the floor before
starting the vehicle. This vehicle is equipped with a
clutch interlocking ignition system. It will not start unless
the clutch is fully pressed.
Automatic Transmission — If Equipped
Start the engine with the transmission in the NEUTRAL
or PARK position. Apply the brake before shifting to any
driving range.
Tip Start Feature
Do notpress the accelerator. Turn the ignition switch
briefly to the START position and release it. The starter
motor will continue to run but will automatically disen-
gage when the engine is running.
Keyless Enter-N-Go — If Equipped
This feature allows the driver to oper-
ate the ignition switch with the push
of a button, as long as the Remote
Start/Keyless Enter-N-Go Key Fob is
in the passenger compartment.
Normal Starting
Using The ENGINE START/STOP Button
1. The transmission must be in PARK or NEUTRAL.
2. Press and hold the brake pedal while pushing the ENGINE START/STOP button once.
3. The system takes over and attempts to start the vehicle. If the vehicle fails to start, the starter will
disengage automatically after 25 seconds.
5
STARTING AND OPERATING 261

4. If you wish to stop the cranking of the engine prior tothe engine starting, remove your foot from the brake
pedal and push the button again.
NOTE:
• Normal starting of either a cold or a warm engine is
obtained without pumping or pressing the accelerator
pedal.
• Under cold weather conditions, the engine may not
immediately crank if the Wait To Starttelltale is
illuminated. This is normal operation. For vehicles
equipped with Keyless Enter-N-Go, the vehicle will
automatically crank when the Wait To Starttime has
elapsed. See the section Starting Procedure Engine
Manifold Air Temperature 0°F to 66°F (18° C to 19°C)
for more information. To Turn Off The Engine Using ENGINE START/STOP
Button
1. Place the shift lever/gear selector in PARK, then push
and release the ENGINE START/STOP button.
2. The ignition switch will return to the OFF position.
3. If the shift lever/gear selector is not in PARK, the ENGINE START/STOP button must be held for two
seconds or three short pushes in a row with the vehicle
speed above 5 mph (8 km/h) before the engine will
shut off. The ignition switch position will remain in
the ACC position until the shift lever/gear selector is
in PARK and the button is pushed twice to the OFF
position. If the shift lever/gear selector is not in PARK
and the ENGINE START/STOP button is pushed
once, the EVIC/DID will display a “Vehicle Not In
Park” message and the engine will remain running.
Never leave a vehicle out of the PARK position, or it
could roll.
262 STARTING AND OPERATING
