11
3RD ROW SEATS
To recline the seatback, pull up on the latch 1
located on the outside corner of each seatback.
Lean back until the desired angle is obtained.
To bring the seatback forward again, pull up on the latch
1 and move your body forward. The
seatback will move forward.
For more information, refer to the “Safety—Seats, seat belts and supplemental restraint system (section \
1) ” of
your Owner’s Manual.
1
AUTOMATIC DRIVE POSITIONER (if so equipped)
Two positions for the driver’s seat, steering column (if so equipped) and outside mirrors can
be stored in the automatic drive positioner memory.
Follow this procedure to set the memory positions:
1. Push the ignition switc
h to the ON or ACC position. (The vehicle should be stopped
while setting the memory.)
2.
Adjust the driver
’s seat, steering column (if
so equipped) and outside mirrors to the
desired positions using the adjusting switches
for each feature.
3.
Push the
SET switch
1, and within 5
seconds, push the memory switch (1 or 2).
4.
T
he indicator light for the selected memory
switch will illuminate for approximately 5 seconds, and a chime will sound when the
memory is stored.
5.
T
he driver’s seat, steering column (if so equipped) and outside mirror positions \
are
now set to your preferences.
6.
T
hese memorized positions can also be linked to your Nissan Intelligent Key
®. To
link a memorized position to your Nissan Intelligent Key®, press the unlock button on
the key fob after completing the previous step.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
MULTI-MODE
To enter the 3rd row from outside the vehicle, lift up fully on the seatback release
lever
3. This will release the back of the seat and fold up the seat cushion.
For access to the rear seat, slide the entire seat forward by pushing on \
the upper seatback area.
To return the seat to a locked position, push the upper seatback rearward until the seatback and track are locked. Push the seat cushion down. Locking the seatback will
also lock the track.
For more information, refer to the “Safety—Seats, seat belts and supplemental restraint system (section \
1) ” of
your Owner’s Manual.
2009259_16b_Pathfinder_US_pQRG_121715.indd 1112/17/15 5:01 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
