Test Value and Test LimitINFOID:0000000012741280
The following is the information specified in Service $06 of SAE J1979/ISO 15031-5.
The test value is a parameter used to determine whether a system/circuit diagnostic test is OK or NG while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
These data (test value and test limit) are specified by On Board Monitor ID (OBDMID), Test ID (TID), Unit and
Scaling ID and can be displayed on the GST screen.
The items of the test value and test limit will be di splayed with GST screen which items are provided by the
ECM. (e.g., if bank 2 is not applied on this v ehicle, only the items of bank 1 are displayed)
P2122 2122 APP SEN 1/CIRC — 1×BEC-413
P2123 2123 APP SEN 1/CIRC — 1×BEC-413
P2127 2127 APP SEN 2/CIRC — 1×BEC-416
P2128 2128 APP SEN 2/CIRC — 1×BEC-416
P2135 2135 TP SENSOR-B1 — 1×BEC-419
P2138 2138 APP SENSOR — 1×BEC-422
P219A 219A AIR FUEL RATIO IMBALANCE B1 — 2×AEC-426
P219C 219C CYLINDER 1 AIR-FUEL RATIO ×2 × AEC-431
P219D 219D CYLINDER 2 AIR-FUEL RATIO ×2 × AEC-431
P219E 219E CYLINDER 3 AIR-FUEL RATIO ×2 × AEC-431
P219F 219F CYLINDER 4 AIR-FUEL RATIO ×2 × AEC-431
DTC*1
Items
(CONSULT screen terms) SRT
code Trip MIL Permanent
DTC group*4Reference page
CONSULT
GST*
2ECM*3
Revision: August 2015 2016 Versa Note

cardiagn.com

ECM
EC-91
< ECU DIAGNOSIS INFORMATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Item
OBD-
MID Self-diagnostic test item
DTCTest value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
HO2S 01H Air fuel ratio (A/F) sensor 1
(Bank 1) P0131 83H 0BH
Minimum sensor output voltage for test
cycle
P0131 84H 0BH Maximum sensor output voltage for
test cycle
P0130 85H 0BH Minimum sensor output voltage for test
cycle
P0130 86H 0BH Maximum sensor output voltage for
test cycle
P0133 87H 04H Response rate: Response ratio (lean
to rich)
P0133 88H 04H Response rate: Response ratio (rich to
lean)
P2A00 or P2096 89H 84H The amount of shift in air fuel ratio (too
lean)
P2A00 or P2097 8AH 84H The amount of shift in air fuel ratio (too
rich)
P0130 8BH 0BH Difference in sensor output voltage
P0133 8CH 83H Response gain at the limited frequency
P014C 8DH 04H O2 sensor slow response - Rich to
lean bank 1 sensor 1
P014C 8EH 04H O2 sensor slow response - Rich to
lean bank 1 sensor 1
P014D 8FH 84H O2 sensor slow response - Lean to rich
bank 1 sensor 1
P014D 90H 84H O2 sensor slow response - Lean to rich
bank 1 sensor 1
P015A 91H 01H O2 sensor delayed response - Rich to
lean bank 1 sensor 1
P015A 92H 01H O2 sensor delayed response - Rich to
lean bank 1 sensor 1
P015B 93H 01H O2 sensor delayed response - Lean to
rich bank 1 sensor 1
P015B 94H 01H O2 sensor delayed response - Lean to
rich bank 1 sensor 1
P0133 95H 04H Response rate: Response ratio (lean
to rich)
P0133 96H 84H Response rate: Response ratio (rich to
lean)
Revision: August 2015
2016 Versa Note

cardiagn.com

EC-92
< ECU DIAGNOSIS INFORMATION >[HR16DE]
ECM
HO2S02H
Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for
test cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
P0139 82H 11H Rear O2 sensor delay response diag-
nosis
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for
test cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
05H Air fuel ratio (A/F) sensor 1
(Bank 2) P0151 83H 0BH
Minimum sensor output voltage for test
cycle
P0151 84H 0BH Maximum sensor output voltage for
test cycle
P0150 85H 0BH Minimum sensor output voltage for test
cycle
P0150 86H 0BH Maximum sensor output voltage for
test cycle
P0153 87H 04H Response rate: Response ratio (lean
to rich)
P0153 88H 04H Response rate: Respon
se ratio (rich to
lean)
P2A03 or P2098 89H 84H The amount of shift in air fuel ratio (too
lean)
P2A03 or P2099 8AH 84H The amount of shift in air fuel ratio (too
rich)
P0150 8BH 0BH Difference in sensor output voltage
P0153 8CH 83H Response gain at the limited frequency
P014E 8DH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014E 8EH 04H O2 sensor slow response - Rich to
lean bank 2 sensor 1
P014F 8FH 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P014F 90H 84H O2 sensor slow response - Lean to rich
bank 2 sensor 1
P015C 91H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015C 92H 01H O2 sensor delayed response - Rich to
lean bank 2 sensor 1
P015D 93H 01H O2 sensor delayed response - Lean to
rich bank 2 sensor 1
Item
OBD-
MID Self-diagnostic test item
DTCTest value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: August 2015 2016 Versa Note

cardiagn.com

ECM
EC-93
< ECU DIAGNOSIS INFORMATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
HO2S 05H
Air fuel ratio (A/F) sensor 1
(Bank 2) P015D 94H 01H
O2 sensor delayed response - Lean to
rich bank 2 sensor 1
P0153 95H 04H Response rate: Response ratio (lean
to rich)
P0153 96H 84H Response rate: Response ratio (rich to
lean)
06H Heated oxygen sensor 2
(Bank 2) P0158 07H 0CH
Minimum sensor output voltage for test
cycle
P0157 08H 0CH Maximum sensor output voltage for
test cycle
P0158 80H 0CH Sensor output voltage
P0159 81H 0CH Difference in sensor output voltage
P0159 82H 11H Rear O2 sensor delay response diag-
nosis
07H Heated oxygen sensor 3
(Bank2) P0163 07H 0CH
Minimum sensor output voltage for test
cycle
P0164 08H 0CH Maximum sensor output voltage for
test cycle
P0166 80H 0CH Sensor output voltage
P0165 81H 0CH Difference in sensor output voltage
CATA-
LY S T 21H
Three way catalyst function
(Bank1) P0420 80H 01H O2 storage index
P0420 82H 01H
Switching time lag engine exhaust in-
dex value
P2423 83H 0CH Difference in 3rd O2 sensor output
voltage
P2423 84H 84H O2 storage index in HC trap catalyst
22H Three way catalyst function
(Bank2) P0430 80H 01H O2 storage index
P0430 82H 01H
Switching time lag engine exhaust in-
dex value
P2424 83H 0CH Difference in 3rd O2 sensor output
voltage
P2424 84H 84H O2 storage index in HC trap catalyst
EGR
SYSTEM 31H EGR function P0400 80H 96H
Low flow faults: EGR temp change rate
(short term)
P0400 81H 96H Low flow faults: EGR temp change rate
(long term)
P0400 82H 96H Low flow faults: Difference between
max EGR temp and EGR temp under
idling condition
P0400 83H 96H Low flow faults: Max EGR temp
P1402 84H 96H High Flow Faults: EGR temp increase
rate
P0402 85H FCH EGR differential pressure high flow
P0401 86H 37H EGR differential pressure low flow
P2457 87H 96H EGR temperature
Item
OBD-
MID Self-diagnostic test item
DTCTest value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-94
< ECU DIAGNOSIS INFORMATION >[HR16DE]
ECM
VVT
SYSTEM35H VVT Monitor (Bank1)
P0011 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0014 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0011 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0014 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100A 84H 10H VEL slow response diagnosis P1090 85H 10H VEL servo system diagnosis
P0011 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052A Retarded: P052B 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
36H VVT Monitor (Bank2) P0021 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0024 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0021 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0024 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100B 84H 10H VEL slow response diagnosis P1093 85H 10H VEL servo system diagnosis
P0021 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052C Retarded: P052D 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
EVAP
SYSTEM 39H
EVAP control system leak
(Cap Off)
P0455 80H 0CHDifference in pressure sensor output
voltage before and after pull down
3BH EVAP control system leak
(Small leak) P0442 80H 05H
Leak area index (for more than 0.04
inch)
3CH EVAP control system leak
(Very small leak) P0456 80H 05H
Leak area index (for more than 0.02
inch)
P0456 81H FDH Maximum internal pressure of EVAP
system during monitoring
P0456 82H FDH Internal pressure of EVAP system at
the end of monitoring
3DH Purge flow system P0441 83H 0CHDifference in pressure sensor output
voltage before and after vent control
valve close
Item
OBD-
MID Self-diagnostic test item
DTCTest value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: August 2015 2016 Versa Note

cardiagn.com

ECM
EC-95
< ECU DIAGNOSIS INFORMATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
O2 SEN-
SOR
HEATER 41H A/F sensor 1 heater (Bank 1)
Low Input: P0031
High Input: P0032 81H 0BHConverted value of heater electric cur-
rent to voltage
P0030 83H 0BH A/F sensor heater circuit malfunction
42H Heated oxygen sensor 2 heat-
er (Bank 1) Low Input: P0037
High Input: P0038 80H 0CH
Converted value of heater electric cur-
rent to voltage
P0141 81H 14H Rear O2 sensor internal impedance
43H Heated oxygen sensor 3 heat-
er (Bank 1) P0043 80H 0CHConverted value of heater electric cur-
rent to voltage
45H A/F sensor 1 heater (Bank 2) Low Input: P0051
High Input: P0052 81H 0BHConverted value of heater electric cur-
rent to voltage
P0036 83H 0BH A/F sensor heater circuit malfunction
46H Heated oxygen sensor 2 heat-
er (Bank 2) Low Input: P0057
High Input: P0058 80H 0CH
Converted value of heater electric cur-
rent to voltage
P0161 81H 14CH Rear O2 sensor internal impedance
47H Heated oxygen sensor 3 heat-
er (Bank 2) P0063 80H 0CHConverted value of heater electric cur-
rent to voltage
SEC-
OND-
ARY AIR 71H Secondary air system P0411 80H 01H
Secondary air injection system incor-
rect flow detected
Bank1: P0491
Bank2: P0492 81H 01H
Secondary air injection system insuffi-
cient flow
P2445 82H 01H Secondary air injection system pump
stuck off
P2448 83H 01H Secondary air injection system high
airflow
Bank1: P2440
Bank2: P2442 84H 01H
Secondary air injection system switch-
ing valve stuck open
P2440 85H 01H Secondary air injection system switch-
ing valve stuck open
P2444 86H 01H Secondary air injection system pump
stuck on
Item
OBD-
MID Self-diagnostic test item
DTCTest value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-122
< BASIC INSPECTION >[HR16DE]
DIAGNOSIS AND REPAIR WORKFLOW
NO >> Check according to
GI-42, "Intermittent Incident".
6.PERFORM BASIC INSPECTION
Perform EC-133, "
Work Procedure".
Do you have CONSULT?
YES >> GO TO 7.
NO >> GO TO 9.
7.PERFORM “SPEC” IN DATA MONITOR MODE
With CONSULT
Make sure that “MAS A/F SE-B1”, “B/FUEL SCHDL” and “A/F ALPHA-B1” are within the SP value in “SPEC”
of “DATA MONITOR” mode with CONSULT. Refer to EC-151, "
Component Function Check".
Is the measurement value within the SP value?
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART BY TROUBL E DIAGNOSIS - SPECIFICATION VALUE
Detect malfunctioning part according to EC-152, "
Diagnosis Procedure".
Is malfunctioning part detected?
YES >> GO TO 11.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING SYSTEM BY SYMPTOM TABLE
Detect malfunctioning system according to EC-464, "
Symptom Table" based on the confirmed symptom in
step 4, and determine the trouble diagnosis order based on possible causes and symptom.
>> GO TO 10.
10.DETECT MALFUNCTIONING PA RT BY DIAGNOSIS PROCEDURE
Inspect according to Diagnos is Procedure of the system.
NOTE:
The Diagnosis Procedure in EC section described based on open circuit inspection. A short circuit inspection
is also required for the circuit check in the Diagnosis Procedure. For details, refer to GI-44, "
Circuit Inspec-
tion".
Is malfunctioning part detected?
YES >> GO TO 11.
NO >> Monitor input data from related sensors or check the voltage of related ECM terminals using CON- SULT. Refer to EC-71, "
Reference Value".
11 .REPAIR OR REPLACE THE MALFUNCTIONING PART
1. Repair or replace the malfunctioning part.
2. Reconnect parts or connectors disconnected during Diagnosis Procedure again after repair and replace- ment.
3. Check DTC. If DTC is displayed, erase it.
With CONSULT: “How to Erase DTC and 1st Trip DTC” in EC-60, "
CONSULT Function".
Without CONSULT: “How to Erase Self-diagnostic Results” in EC-57, "
On Board Diagnosis Function".
>> GO TO 12.
12.FINAL CHECK
When DTC was detected in step 2, perform DTC CO NFIRMATION PROCEDURE or Component Function
Check again, and then make sure that the malfunction have been repaired securely.
When symptom was described from the customer, refer to confirmed symptom in step 3 or 4, and make sure
that the symptom is not detected.
Is DTC detected and does symptom remain?
YES-1 >> DTC is detected: GO TO 10.
YES-2 >> Symptom remains: GO TO 6.
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-128
< BASIC INSPECTION >[HR16DE]
ACCELERATOR PEDAL RELEASED POSITION LEARNING
ACCELERATOR PEDAL REL
EASED POSITION LEARNING
DescriptionINFOID:0000000012431354
Accelerator Pedal Released Position Learning is a function of ECM to learn the fully released position of the
accelerator pedal by monitoring the accelerator pedal position sensor output signal. It must be performed each
time harness connector of accelerator pedal positi on sensor or ECM is disconnected. Refer to EC-128, "
Work
Procedure".
Work ProcedureINFOID:0000000012431355
1.START
1. Make sure that accelerator pedal is fully released.
2. Turn ignition switch ON and wait at least 2 seconds.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON and wait at least 2 seconds.
5. Turn ignition switch OFF and wait at least 10 seconds.
>> END
Revision: August 2015 2016 Versa Note

cardiagn.com
