2016 NISSAN MAXIMA display


> (GLW    0RGHO 1&*1-1 @
*6<>:
Push + or - to adjust the volume.
INFO:
Steering wheel switches are mainly for the
vehicle information display control and may not
be able to operate the touch screen display
depending on the conditions. Follow the pop-up
guide messages and labels shown on the vehicle
information display.
Some of the information displayed on the vehicle
information display are linked with the touch
screen display.
For other details of the vehicle information
display, refer to the vehicle Owner's Manual.
DISPLAY COMMANDER (if so
equipped)
GUID-EA578DD1-511A-4657-9194-0E1CAE4CD87FWith this system, the same operations as those
for the control panel are possible using the
Display Commander.
5GH0305X
*1


> (GLW    0RGHO 1&*1-1 @
2. Getting started
corresponding menu screens.
The following menus are available on the Launch
Bar.. [Audio]
. [Phone]
. [Info]
. [MENU]
. [Map]
. [Navi]
. [Settings] Launch Bar operation with Display Com-
mander (if so equipped):
5GH0345X
Sliding the slide switch backwards will enable
the center dial operation of the Launch Bar. Slide
the switch forward to return to operate Shortcuts
with the center dial.
AudioGUID-649C8501-BB6A-4900-9AEA-0E10ACEA7886Touching [Audio] on the Launch Bar will display
the audio screen. When [Audio] is touched while
the audio screen is displayed, the audio source
menu screen will be displayed.
ªSelecting audio sourceº (page 3-12)
INFO:
Pushing


> (GLW    0RGHO 1&*1-1 @
INFO:
Pushing


> (GLW    0RGHO 1&*1-1 @
2. Getting started
MAIN SCREEN OPERATIONSNCGNJN1402-B2704A91-F2DB-44B4-827A-4CF2E650F379.Displaying previous screen
5GH0266X
*1Touch [] to return to the screen dis-
played previously. .
Horizontal scrolling
5GH0239X
*1Touch [<] to scroll to the previous page.
*2Touch [>] to scroll to the next page.
*3Indicates the position of the currently
displayed page. Page scrolling with Display Comman-
der (if so equipped):
5GH0346X
Slide the slide switch leftward to scroll to the
previous page. Slide the slide switch right-
ward to scroll to the next page.
&RQGLWLRQ
2-12


> (GLW    0RGHO 1&*1-1 @
.Vertical scrolling
5GH0240X
*1Touch [] or [] to scroll the message or
list one item at a time.
Touch [
] or [] to skip to the next page.
*2Indicates the total number of items in the list
and the entry number of the selected item. .
Scrolling list by selecting alphabet
5GH0267X
*1Touch one of the alphabetical keys to scroll
the list to the section of the list that begins
with the letter selected.
Alphabetical scrolling with Display
Commander (if so equipped):
5GH0346X
To operate the alphabetical keys for alpha- betical scrolling with the Display Comman-
der, slide the slide switch to the left so that
the alphabetical keys can be selected by
rotating the center dial. Slide the slide switch
rightward to return to operate the list.
INFO:
Depending on the screens, swiping on the touch
screen can scroll pages vertically or horizontally.
ADJUSTING SETTINGSNCGNJN1402-120906-7511E082-9116-41D3-90B0-85329BDCEE4D
5GH0241X
Touch adjustment keys, such as [-]/[+], etc., to
adjust each item. Each time a key is touched, the
indicator moves along the bar.
For items with [ON] indicator, touch the menu
item to turn on/off the setting. The indicator light
will turn on when the setting is turned on.
2. Getting started
&RQGLWLRQ
2-13


> (GLW    0RGHO 1&*1-1 @
2. Getting started
HOW TO INPUT LETTERS AND
NUMBERS
NCGNJN1402-120906-95CCE032-178B-4697-8BFB-8BB9856AFD9CBasic operations to enter letters and numbers
are explained here.
Character and number input screens vary
depending on the conditions.
Alphabet input screenNCGNJN1402-9244CA6E-8CE8-4E92-9F93-3F3D3E32096E
5GH0242X
*1Entered characters are displayed.
*2Touch to delete the last character entered.
Touch and hold to delete all the characters
entered.
*3Touch to change the type of keyboard.
[A-Z]: Displays alphabet input screen.
[
]: Displays symbol input screen.
[123]: Displays number input screen.
*4Touch to switch between the uppercase
and lowercase character input screen.
*5Touch to enter a space.
*6Touch to enter a character.
*7Touch to confirm the entry.
INFO:
. Push briefly to delete the last
character entered. Push and hold the button
to delete all the characters entered.
. For Mexico:
Searching with two or more words is
possible by touching [AND] between key-
words.
Number input screenGUID-BCECD62B-4D09-48C9-997D-360243F5586E
5GH0243X
*1Entered characters are displayed.
*2Touch to delete the last number entered.
Touch and hold to delete all the characters
entered.
*3Touch to enter a number.
*4Touch to confirm the entry.
HOW TO VIEW AND OPERATE
HOME MENU SCREEN
GUID-CA23AE87-F50B-4970-A7BD-D9932C5241ABPush


> (GLW    0RGHO 1&*1-1 @
5GH0252X
*1Shortcut icons:
Icons for frequently used menu items can be
placed on the HOME MENU screens as
Shortcuts. Shortcuts of navigation, informa-
tion, phone, audio and setting menus are
available.
*2Widget:
Useful information such as audio, weather,
clock, etc. can be displayed as Widgets.
Depending on the contents, keys in the box
can be touched for operations.
INFO:
The HOME MENU screen can be edited.
ªCustomizing HOME MENU screenº
(page 2-15)
Default menus:
The following Shortcuts and Widgets are set to
be displayed as default on the HOME MENU
screen.
For U.S. and Canada
Shortcuts/Widgets Content
[Home] Page 6-20
[NissanConnect Apps] Page 5-6
[Previous Destinations] Page 6-21
[Call History] Page 4-4
[Audio Information] Page 3-1
[SXM Traffic] Page 5-2
[SXM Fuel Prices] Page 5-2
[SXM Sports] Page 5-2
[SXM Stocks] Page 5-2
[SXM Weather] Page 5-2
[Edit Menu] Page 2-15
[Digital Clock] Digital clock is dis-
played.
For Mexico
Shortcuts/Widgets Content
[Home]Page 6-20
[NissanConnect Apps] Page 5-6
[Previous Destinations] Page 6-21
[Call History] Page 4-4
[Audio Information] Page 3-1
[Edit Menu] Page 2-15
[Digital Clock] Digital clock is dis-
played.
INFO:
. Default menus on the HOME MENU screen
are subject to change without notice.
. A SiriusXM Travel Link or SiriusXM Traffic
subscription is necessary to receive SXM
information services (for U.S. and Canada) .
Customizing HOME MENU screenGUID-6891DABF-54F5-4264-BFFC-F75F8C5E4B9BThe HOME MENU screen can be personalized
by selecting which Shortcuts and Widgets to be
displayed and where to place them on the
screen.
2. Getting started
&RQGLWLRQ
2-15


> (GLW    0RGHO 1&*1-1 @
2. Getting started
5GH0257X
1. Push and hold
