2016 KIA Sorento Owner's Manual

88
Specifications & Consumer information
Recommended SAE viscosity
number
Always be sure to clean the area
around any filler plug, drain plug, or
dipstick before checking or draining
any lubricant. This is especially
important in dusty or sandy areas
and when the vehicle is used on
unpaved roads. Cleaning the plug
and dipstick areas will prevent dirt
and grit from entering the engine and
other mechanisms that could be
damaged. Engine oil viscosity (thick-
ness) has an effect on fuel economy
and cold weather operating (engine
start and engine oil flowability).
Lower viscosity engine oils can pro-
vide better fuel economy and cold
weather performance, however,
higher viscosity engine oils are
required for satisfactory lubrication in
hot weather. Using oils of any viscos-
ity other than those recommended
could result in engine damage. When
choosing an oil, consider the range
of temperature your vehicle will be
operated in before the next oil
change. Proceed to select the rec-
ommended oil viscosity from the
chart.
Temperature Range for SAE Viscosity Numbers
Temperature°C
(°F)-30 -20 -10 0 10 20 30 40 50 -10 0 20 40 60 80 100 120
Gasoline Engine Oil
(Theta II 2.0 T-GDI) *1
20W-50
10W-30
15W-40
5W-30, 5W-40
*1: For better fuel economy, it is recommended to use the engine oil of
a viscosity grade SAE 5W-30 (ACEA A5). However, if the engine oil
is not available in your country, select the proper engine oil using
the engine oil viscosity chart.
*
2: For better fuel economy, it is recommended to use the engine oil of
a viscosity grade SAE 5W-20 (API SM / ILSAC GF-4 / ACEA A5).
However, if the engine oil is not available in your country, select the
proper engine oil using the engine oil viscosity chart.
*
3: For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE 5W-30 (ACEA A5). However, if the engine oil
is not available in your country, select the proper engine oil using
the engine oil viscosity chart.
Gasoline Engine Oil(
Theta II 2.4 GDI) *210W-30
5W-20, 5W-30
Gasoline Engine Oil
(
Lambda II 3.3 GDI) *3
10W-30
5W-30
UM CAN (ENG) 8.qxp 12/1/2014 1:13 PM Page 8

89
Specifications & Consumer information
VEHICLE IDENTIFICATION NUMBER (VIN)
The vehicle identification number
(VIN) is the number used in register-
ing your vehicle and in all legal mat-
ters pertaining to its ownership, etc.
The number is punched on the floor
under the front passenger seat.The VIN is also on a plate attached
to the top of the dashboard. The
number on the plate can easily be
seen through the windshield from
outside.
The vehicle certification label
attached on the driver’s side center
pillar gives the vehicle identification
number (VIN).
VEHICLE CERTIFICATION
LABEL
OUM084001
■
Frame number
OUM084005
■VIN label
OUM084004
UM CAN (ENG) 8.qxp 12/1/2014 1:14 PM Page 9

10
8
Specifications & Consumer information
The tires supplied on your new vehi-
cle are chosen to provide the best
performance for normal driving.
The tire label located on the driver's
side center pillar gives the tire pres-
sures recommended for your vehicle.
The engine number is stamped on the
engine block as shown in the drawing.
ENGINE NUMBER
TIRE SPECIFICATION AND
PRESSURE LABEL
OUM084002
OYF081013N
OUM084007
OYP084003K
■ Gasoline engine (THETA 2.4L GDI)
■Gasoline engine (THETA 2.0L T-GDI)
■Gasoline engine (Lambda 3.3L GDI)
UM CAN (ENG) 8.qxp 12/1/2014 1:14 PM Page 10

Index
I
UM CAN (ENG) INDEX.qxp 12/1/2014 11:55 AM Page 1

Index
2I
Advanced smart cruise control system (ASCC) . . . . . . 5-53Limitations of the system . . . . . . . . . . . . . . . . . . . . . 5-63
Speed setting (ASCC) . . . . . . . . . . . . . . . . . . . . . . . 5-54
To adjust the sensitivity of advanced smartcruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-62
To convert to cruise control mode . . . . . . . . . . . . . . 5-63
Vehicle to vehicle distance setting (ASCC) . . . . . . . 5-58
Air bag - advanced supplemental restraint system . . . 3-43 Air bag warning label. . . . . . . . . . . . . . . . . . . . . . . . 3-67
Air bag warning light . . . . . . . . . . . . . . . . . . . . . . . . 3-46
Curtain air bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
Do not install a child restraint on the frontpassenger’s seat . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
Driver's and passenger's front air bag . . . . . . . . . . . 3-56
How does the air bag system operate . . . . . . . . . . . 3-44
Inflation and non-inflation conditions of the air bag . . 3-61
Occupant Detection System (ODS) . . . . . . . . . . . . . 3-50
Side air bag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
SRS Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
SRS components and functions . . . . . . . . . . . . . . . . 3-47
Air cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-40\
Filter replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-40
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
All wheel drive (AWD). . . . . . . . . . . . . . . . . . . . . . . . . 5-19 All wheel drive (AWD) transfer mode selection . . . 5-21
For safe all wheel drive operation . . . . . . . . . . . . . . 5-22 Tight corner brake effect . . . . . . . . . . . . . . . . . . . . . 5-20
Appearance care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-91 Exterior care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-91
Interior care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-96
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-171 Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-171
Aux, USB and iPod
®port . . . . . . . . . . . . . . . . . . . 4-173
Basic method of use . . . . . . . . . . . . . . . . . . . . . . . . 4-195
Bluetooth
®Wireless Technology . . . . . . . . . . . . . . 4-180
Bluetooth®wireless technology audio . . . . . . . . . . 4-202
Clock settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-188
How vehicle audio works . . . . . . . . . . . . . . . . . . . . 4-174
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
204
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
190
Set up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
186
SIRIUS™ Satellite Radio information . . . . . . . . . 4-192
SIRIUS™ radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-193
Sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-187
Standard audio system . . . . . . . . . . . . . . . . . . . . . . 4-183
Steering wheel remote controller . . . . . . . . . . . . . . 4-172
System controllers and functions . . . . . . . . . . . . . . 4-184
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-189
Using iPod
®device . . . . . . . . . . . . . . . . . . . . . . . . 4-179
Using the USB device . . . . . . . . . . . . . . . . . . . . . . 4-178
Voice command list . . . . . . . . . . . . . . . . . . . . . . . . 4-221
Voice recognition . . . . . . . . . . . . . . . . . . . . . . . . . . 4-182
Voice recognition . . . . . . . . . . . . . . . . . . . . . . . . . . 4-218
Automatic climate control system . . . . . . . . . . . . . . . 4-139
A
UM CAN (ENG) INDEX.qxp 12/1/2014 11:55 AM Page 2

I3
Index
3rd row air conditioning. . . . . . . . . . . . . . . . . . . . . 4-147
Automatic heating and air conditioning. . . . . . . . . 4-141
Checking the amount of air conditionerrefrigerant and compressor lubricant . . . . . . . . . . 4-151
Climate control air filter. . . . . . . . . . . . . . . . . . . . . 4-150
Manual heating and air conditioning . . . . . . . . . . . 4-142
System operation . . . . . . . . . . . . . . . . . . . . . . . . . . 4-148
Automatic transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13 Automatic transaxle operation . . . . . . . . . . . . . . . . . 5-13
Good driving practices . . . . . . . . . . . . . . . . . . . . . . . 5-18
Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . 7-47 Battery recharging . . . . . . . . . . . . . . . . . . . . . . . . . . 7-48
For best battery service . . . . . . . . . . . . . . . . . . . . . . 7-47
Recharging battery . . . . . . . . . . . . . . . . . . . . . . . . . . 7-49
Reset items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-49
Before driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4 Before entering vehicle . . . . . . . . . . . . . . . . . . . . . . . 5-4
Before starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Necessary inspections . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Blind spot detection system (BSD) . . . . . . . . . . . . . . . 5-72 BSD (Blind Spot Detection) /LCA (Lane Change Assist) . . . . . . . . . . . . . . . . . . 5-73
Non-operating condition . . . . . . . . . . . . . . . . . . . . . 5-78
RCTA (Rear Cross Traffic Alert) . . . . . . . . . . . . . . . 5-76
Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38\
Checking the brake fluid level . . . . . . . . . . . . . . . . . 7-38
Brake system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26 Anti-lock brake system (ABS) . . . . . . . . . . . . . . . . . 5-39
AUTO HOLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
Electric parking brake (EPB) . . . . . . . . . . . . . . . . . . 5-29
Electronic stability control (ESC) . . . . . . . . . . . . . . 5-41
Good braking practices . . . . . . . . . . . . . . . . . . . . . . 5-47
Hill-start assist control (HAC) . . . . . . . . . . . . . . . . . 5-46
Parking brake – Foot type . . . . . . . . . . . . . . . . . . . . 5-28
Power brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
Vehicle stability management (VSM) . . . . . . . . . . . 5-45
Bulb wattage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Child restraint system . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35 Child restraint system. . . . . . . . . . . . . . . . . . . . . . . . 3-36
Lower anchor system . . . . . . . . . . . . . . . . . . . . . . . . 3-41
Tether anchor system . . . . . . . . . . . . . . . . . . . . . . . . 3-40
Clean air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
156
Climate control air filter . . . . . . . . . . . . . . . . . . . . . . . . 7-42 Filter inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-42
Cruise control system . . . . . . . . . . . . . . . . . . . . . . . . . . 5-49 To cancel cruise control . . . . . . . . . . . . . . . . . . . . . . 5-51
To decrease the cruising speed . . . . . . . . . . . . . . . . . 5-51
To increase cruise control set speed . . . . . . . . . . . . . 5-50
To resume cruising speed . . . . . . . . . . . . . . . . . . . . . 5-52
To set cruise control speed . . . . . . . . . . . . . . . . . . . . 5-50
B
C
UM CAN (ENG) INDEX.qxp 12/1/2014 11:55 AM Page 3

Index
4I
To temporarily accelerate with the cruise control on5-51
To turn cruise control off . . . . . . . . . . . . . . . . . . . . . 5-52
Defroster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12\
7 Rear window defroster . . . . . . . . . . . . . . . . . . . . . . 4-127
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-\
2
Door locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22\
Child-protector rear door lock . . . . . . . . . . . . . . . . . 4-25
Impact sensing door unlock system . . . . . . . . . . . . . 4-24
Operating door locks from inside the vehicle . . . . . 4-23
Operating door locks from outside the vehicle . . . . 4-22
Drive mode integrated control system . . . . . . . . . . . . . 5-69 Drive mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-69
Economical operation . . . . . . . . . . . . . . . . . . . . . . . . . . 5-88
Emergency starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5 Jump starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Push-starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Emission control system . . . . . . . . . . . . . . . . . . . . . . . . 7-98 Crankcase emission control system . . . . . . . . . . . . . 7-98
Evaporative emission control (including ORVR:Onboard refueling vapor recovery) system . . . . . . 7-98
Exhaust emission control system . . . . . . . . . . . . . . . 7-99
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . 8-2 Engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Engine compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-35
Changing the coolant . . . . . . . . . . . . . . . . . . . . . . . . 7-37
Checking the coolant level . . . . . . . . . . . . . . . . . . . . 7-35
Engine number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-\
33 Changing the engine oil and filter . . . . . . . . . . . . . . 7-34
Checking the engine oil level . . . . . . . . . . . . . . . . . . 7-33
ENGINE START/STOP button . . . . . . . . . . . . . . . . . . . 5-9 ENGINE START/STOP button position . . . . . . . . . . 5-9
Illuminated ENGINE START/STOP button . . . . . . . 5-9
Starting the engine with a smart key . . . . . . . . . . . . 5-11
Explanation of scheduled maintenance items . . . . . . . 7-29
Exterior features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-170 Roof rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-170
Exterior overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Folding key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
5 Battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Immobilizer system . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Key operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Record your key number . . . . . . . . . . . . . . . . . . . . . . 4-5
Transmitter precautions . . . . . . . . . . . . . . . . . . . . . . . 4-7
Forward collision warning system (FCWS) . . . . . . . . . 5-84 FCWS Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-84
F
D
E
UM CAN (ENG) INDEX.qxp 12/1/2014 11:55 AM Page 4

I5
Index
Limitations of the System . . . . . . . . . . . . . . . . . . . . 5-86
Fuel filler lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46 Closing the fuel filler lid . . . . . . . . . . . . . . . . . . . . . 4-46
Emergency fuel filler lid release . . . . . . . . . . . . . . . 4-49
Opening the fuel filler lid. . . . . . . . . . . . . . . . . . . . . 4-46
Fuel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Do not use methanol . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Gasoline containing alcohol and methanol . . . . . . . . 1-3
Operation in foreign countries . . . . . . . . . . . . . . . . . . 1-5
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . 7-64 Engine compartment fuse replacement . . . . . . . . . . 7-67
Fuse/relay panel description. . . . . . . . . . . . . . . . . . . 7-69
Inner panel fuse replacement . . . . . . . . . . . . . . . . . . 7-65
Gross vehicle weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . 4-44 Closing the hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
Opening the hood . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 If the engine overheats . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
If the engine will not start . . . . . . . . . . . . . . . . . . . . . . . 6-4
If engine doesn't turn over or turns over slowly . . . . 6-4
If engine turns over normally but does not start . . . . 6-4
If you have a flat tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8 Changing tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Jack and tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Removing and storing the spare tire . . . . . . . . . . . . . 6-9
In case of an emergency while driving . . . . . . . . . . . . . . 6-3 If the engine stalls at a crossroad or crossing . . . . . . 6-3
If the engine stalls while driving . . . . . . . . . . . . . . . . 6-3
If you have a flat tire while driving . . . . . . . . . . . . . . 6-3
Instrument cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-72 Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-\
74
Icy Road Warning Indicator . . . . . . . . . . . . . . . . . . . 4-77
Instrument cluster control . . . . . . . . . . . . . . . . . . . . 4-73
LCD display control . . . . . . . . . . . . . . . . . . . . . . . . . 4-73
Transaxle shift indicator . . . . . . . . . . . . . . . . . . . . . . 4-77
Instrument panel overview . . . . . . . . . . . . . . . . . . . . . . . 2-5
Interior features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-160 AC inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-164
Bottle holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-161
Clothes hanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-167
Cup holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-160
Floor mat anchor (s) . . . . . . . . . . . . . . . . . . . . . . . . 4-167
Luggage net holder. . . . . . . . . . . . . . . . . . . . . . . . . 4-168I
G
H
UM CAN (ENG) INDEX.qxp 12/1/2014 11:55 AM Page 5
