2016 INFINITI QX50 Quick Reference Guide

2016 Infiniti QX50Quick Reference Guide
2128163_16b_QX50_US_pQRG_091515.indd 29/15/15 2:54 PM

*See your Owner’s Manual for information.
Behind
steering wheel Behind
steering wheel
On
steering column
Behind
steering wheel
1 INSTRUMENT BRIGHTNESS CONTROL SWITCH*
2
VEHICLE INFORMATION DISPLAY
3 TRIP COMPUTER SWITCHES
4 LOW TIRE PRESSURE WARNING LIGHT
5
HEADLIGHT AND TURN SIGNAL SWITCH
6 WIPER AND WASHER SWITCH
7 STEERING WHEEL SWITCHES FOR
AUDIO* / BLUETOOTH® / NAVIGATION
8 INTELLIGENT CRUISE CONTROL BUTTONS
9 PUSH-BUTTON IGNITION
10 WARNING SYSTEMS SWITCH*
11 INTELLIGENT BRAKE ASSIST (IBA)
OFF SWITCH*
12 DYNAMIC DRIVER ASSISTANCE SWITCH*
13 INTELLIGENT KEY PORT
14 TILT / TELESCOPIC STEERING
WHEEL SWITCH*
15 HOOD RELEASE*

16 VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH*
17 CONTROL PANEL DISPLAY SCREEN*
18 AUDIO SYSTEM
19 HEATER AND AIR CONDITIONER (automatic)
20 FRONT PASSENGER AIR BAG
STATUS LIGHT*
13
4
56
789
12
14
1516
17
18
1920
2
1011
13
2128163_16b_QX50_US_pQRG_091515.indd 39/15/15 2:54 PM

table of contents
new system features Around View ® Monitor (AVM) with Moving Object Detection (MOD)
(if so equipped) ................................................ 2
Snow Mode ................................................... 3
Blind Spot Warning (BSW) (if so equipped) ..........................4
essential information Tire Pressure Monitoring System (TPMS) ............................ 5
Loose Fuel Cap ................................................. 5
Fuel-filler Door ................................................. 6
Front Armrest/Center Console Storage Box .......................... 6
Clock Set/Adjustment ........................................... 6
first drive features INFINITI Intelligent Key System ................................... 7
Liftgate Release ................................................ 8
Power Seat Adjustments ......................................... 8
Heated Seats .................................................. 9
Automatic Drive Positioner (if so equipped) ......................... 9
Outside Mirror Control Switch .................................... 10
Headlight Control Switch ........................................ 10
Wiper and Washer Switch ....................................... 11
Starting/Stopping the Engine .................................... 12
Heater and Air Conditioner (automatic) ............................ 12
FM/AM/SiriusXM
® Satellite Radio with CD/DVD Player
(with Navigation System - if so equipped) ..........................14
USB (Universal Serial Bus) Connection Port and iPod
® Interface ........15
Conventional (Fixed Speed) Cruise Control ......................... 15
Intelligent Cruise Control (ICC) (if so equipped) .....................16
Power Outlets ................................................. 17
system guide Trip Computer ................................................. 18
Bluetooth® Hands-free Phone System ............................. 19
System Operating Tips ....................................... 19
Bluetooth
® System with Navigation (if so equipped) ................. 20
Bluetooth® System without Navigation (if so equipped) .............. 22
Bluetooth® Streaming Audio with Navigation (if so equipped) ..........23
Navigation System (if so equipped) ............................... 24
DVD Player ................................................... 25
HomeLink
® Universal Transceiver (if so equipped) ...................26
To view detailed instructional videos, go to
www.infinitiownersinfo.mobi/2016/qx50 or snap this barcode with an
appropriate barcode reader.
Please see your Owner’s Manual for important safety information
and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats, seat belts and supplemental
restraint system (section 1)”, the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” and the “Starting and driving (section 5)” of
your Owner’s Manual.
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
2128163_16b_QX50_US_pQRG_091515.indd 49/15/15 2:54 PM

2
new system features
When the shift lever is in the R (REVERSE) position and the CAMERA button 1 is pressed,
the following views will display in order:
Rear view & bird’s-eye view
Press
Press
Press Rear view & front-side view
Rear wide view
Around View® Monitor (AVM) with Moving Object Detection (MOD)
(if so equipped)
With the ignition switch in the ON position, the
AVM is activated by pressing the CAMERA button
1,
located on the control panel, or by moving the shift lever
to the R (REVERSE) position. The control panel displays
various views of the position of the vehicle.

When the shift lever is in the P (PARK), N (NEUTRAL) or D
(DRIVE) position and the CAMERA button
1 is pressed,
the following views will display in order:
Start from any Control Panel screen
Press
Press Press
Press
Front wide view Front view & bird’s-eye viewFront view & front-side view
1
2128163_16b_QX50_US_pQRG_091515.indd 29/15/15 2:54 PM

3


The colored guide lines on the display screen indicate vehicle width and\
approximate
distances to objects with reference to the vehicle body line.
• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft
(2 m) and 10 ft (3 m).

There are some areas where the system will not
show objects.
• When in the front or the rear view display, an
object below the bumper or on the ground may not
be viewed
2.
• When in the bird’s-eye view, a tall object near the
seam of the camera viewing areas
3 will not
appear in the monitor.

The distance between objects viewed on the AVM
differs from the actual distance.

Objects in the bird’s-eye view will appear further
than the actual distance.
MOVING OBJECT DETECTION

If the MOD system detects moving objects
surrounding the vehicle, a yellow frame
4 will
be displayed on the camera image and a chime
will sound.

In the bird’s-eye view, a yellow frame is displayed on
those camera images (front, rear, right, left) where
moving objects are detected.

When the following are displayed:
• Blue MOD icon
5 : the system is operative in this view.
• Gray MOD icon
6 : the system is not operative in this view.
• No MOD icon: the system is off.

To temporarily turn the system on or off, touch the MOD key 7 .
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
4
7
5
6
Snow Mode
When SNOW mode is activated, engine output
is controlled to avoid wheel spin when driving or
starting the vehicle on snowy roads or slippery areas.

To turn on SNOW mode, press the SNOW switch 1,
located on the center console, to the
ON position.

The indicator light 2 will illuminate when the
SNOW mode is on.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
2
3
1
2
2128163_16b_QX50_US_pQRG_091515.indd 39/15/15 2:54 PM

4
Blind Spot Warning (BSW) (if so equipped)
The BSW system alerts the driver when another
vehicle moves into the vehicle’s detection area.

An indicator light located near the outside mirrors 1
will illuminate if the radar sensors detect a vehicle in
the detection zone.

Push the warning system switch 2 to temporarily
turn the system off. When the system is off, the
indicator light
3 on the switch is off.

The indicator light 3 will also be off if all of the
warning systems are deactivated by pressing and
holding down the warning system switch
2 for
4 seconds.

The indicator light 3 will illuminate after the ignition
switch is ON and the BSW system is enabled.
For more information, refer to the “Instruments and controls (section 2)”
and the “Starting and driving (section 5)” of your Owner’s Manual.
new system features
1
2
3
2128163_16b_QX50_US_pQRG_091515.indd 49/15/15 2:54 PM

5
essential information
Tire Pressure Monitoring System (TPMS)
A CHECK TIRE PRESSURE warning message will
appear in the vehicle information display
1 and
the low tire pressure warning light
2 will illuminate
when one or more tires are low in pressure and air
is needed.
• The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.

After the tire pressures are adjusted, drive the
vehicle at speeds above 16 mph (25 km/h). The
CHECK TIRE PRESSURE warning message and the
low tire pressure warning light
2 will extinguish.

When the low tire pressure warning light 2 flashes for 1 minute and then remains on, the
TPMS is not functioning properly. Have the system checked by an INFINITI\
retailer.

Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and
the outside temperature. Low outside temperature can lower the temperatu\
re of the air
inside the tire, which can cause a lower tire inflation pressure. This m\
ay cause the low tire
pressure warning light
2 to illuminate. If the warning light illuminates, check the tire
pressure in your tires.
• Check the tire pressure (including the spare tire) often and always pr\
ior to long
distance trips.

The Tire and Loading Information label contains valuable information. Pl\
ease refer to the
“Technical and consumer information (section 9)” of your Owner’\
s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
1
2
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear
in the vehicle information display
1 when the
fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will extinguish when the
vehicle detects the fuel-filler cap is properly
tightened and the reset button
2 is pressed.

If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
2
2128163_16b_QX50_US_pQRG_091515.indd 59/15/15 2:55 PM

6
essential information
Front Armrest/Center Console Storage Box
To access the center console storage box, press
the button
1.
For more information, refer to the “Instruments and controls (section 2)”
of your Owner’s Manual.
1
Fuel-filler Door
Unlock the fuel-filler door using one of the following
operations then push and release the left side of the
door to open.

Push either door handle request switch or the liftgate
request switch while carrying the INFINITI Intelligent
Key with you (that is, in your pocket or purse).

Press the button on the Intelligent Key.

Push the power door lock switch to the position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Clock Set/Adjustment
DIGITAL CLOCK WITH NAVIGATION (IF SO EQUIPPED)


To adjust the time and the appearance of the clock
on the display:
1. Press the SETTING button on the control panel.
2. Select the “Others” key.
3. Select the “Clock” key.

The following settings can be adjusted:
• On-screen Clock: The clock in the upper right corner of the display can be turned
on or off.
• Clock Format (24h): The clock can be set to 12 hours or 24 hours.
• Offset (hour): The time can be adjusted by increasing or decreasing per hour.
• Offset (min): The time can be adjusted by increasing or decreasing per minute.
• Daylight Savings Time: The application of Daylight Savings Time can be turned on or off.
• Time Zone: Adjust the time zone. Choose a time zone from the available list.

Press the BACK button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
2128163_16b_QX50_US_pQRG_091515.indd 69/15/15 2:55 PM
