Page 9 of 20
FEATURES AND CONTROLS
SANTA FE
15 14
HYUNDAI
Warning and indicator lights
Engine temperature gauge
Tachometer Gear indicator
Speedometer Outside temperature guageFuel gauge Odometer / Trip computer
Type B
INSTRUMENT PANEL ILLUMINATION
Move the control knob left or right to
adjust the brightness.
WARNINGS AND INDICATORS
Seat belt
warning light
Charging system
warning light
Airbag warning light
Electronic Brake force Distribution (EBD)
System warning light
ABS warning light
Front fog light indicator
Light ON indicator
Liftgate open
warning light
Electric Power Steering
(EPS) warning lightHigh beam indicator
Parking brake & Brake
fluid warning light
Engine oil pressure
warning lightMalfunction Indicator
Lamp (MIL)
Low fuel level
light
Electronic Stability Control
(ESC )
indicator
Electronic Stability Control
(ESC ) OFF indicator
Door open warning
light
Turn signal indicator
ECO indicator
Immobilizer indicator
Downhill Brake Control
(DBC)
indicator
AWD LOCK indicatorAWD warning lightEngine coolant
temperature warning light
Cruise indicator
Cruise SET indicator
TRIP COMPUTER
Select "Trip Computer" mode by
pressing the MODE button
.
To change the trip mode as
follows, press the MOVE button
.
Tripmeter A
Tripmeter B
Fuel Economy
Low Tire Pressure Warning Light
TPMS system malfunction light
Page 10 of 20
FEATURES AND CONTROLS
SANTA FE
17 16
HYUNDAI
AIR INTAKE CONTROL DEFROSTING / DEFOGGING
2. Set the temperature
control towards
warmer setting.3. Set the fan speed to
the highest setting.1. Press the front
windshield defrost
button.
Press to activate/deactivate the
rear window and side mirrors
defroster.REAR WINDOW AND SIDE
MIRRORS DEFROSTER
Changing the direction of
the air flow as follows:MODE SELECTION
Face levelBi-LevelFloor levelFloor/Defrost LevelDefrost Level
MAX A/C (Max air conditioning) button
A/C (Air conditioning) button
Mode selection buttons
Fan speed control knob
Rear window defrost button Front windshield defrost button Temperature control button Air intake control button
NOTETo reduce tendency of the glass
fogging and also to improve visibility,
keep the interior surface of the
windshield clean by wiping it with
a clean cloth and glass cleaner.
In addition, select air intake control
to the outside (fresh) air position
whenever possible while operating
the vehicle.
Outside (fresh) air positionRecirculated air position
Manual Climate Control
Page 11 of 20
FEATURES AND CONTROLS
SANTA FE
19 18
HYUNDAI
Press the DUAL button to
operate the driver and passenger
side temperature individually.DUAL BUTTON
DEFROSTING / DEFOGGING
3. Set the fan speed to
the highest setting. 2. Set the temperature
control towards
warmer setting.1. Press the front
windshield defrost
button.
SYSTEM OFF MODEPressing the OFF button will place the system in the off mode. r Front blower will turn off. r Outside (fresh) air position
selected. r Vented air at last set temperature.
Press to activate /
deactivate
the rear defroster.
REAR WINDOW DEFROSTER AUTOMATIC HEATING
AND COOLING
2. Set the driver's
temperature control
to the desired setting. 1. Press the AUTO
button.
The modes, fan speeds, air
intake, and air-conditioning will be
controlled automatically according
to the temperature setting.
Changing the
direction of the
air flow as follows:
MODE SELECTION
Floor &
Defrost
Face
Level
Bi-
Level
Floor
Level
Automatic Climate Control
Type AAutomatic Climate Control
Type B
AIR INTAKE CONTROL
Recirculated air positionOutside (fresh) air position
% 6 " -
% 6 " -
Type B Type B Type A Type A
Air conditioning button Driver’s temperature
control button Mode selection button
Air intake control buttons Front windshield defrost button Fan speed control knob AUTO (automatic control) button
OFF button Rear window defrost button
Dual temperature control
selection button
Passenger’s temperature
control button Climate control information
screen selection button
NOTETo reduce tendency of the glass
fogging and also improve visibility,
keep the interior surface of the
windshield clean by wiping it with
a clean cloth and glass cleaner.
In addition, select air intake control
to the outside (fresh) air position
whenever possible while operating
the vehicle.
The auto deffogging system automatically controls moisture
of inside the windshield. To enable or disable the system,
press the front defroster button 4 times within 2 seconds
while pressing the AUTO button.
AUTO DEFOGGING SYSTEM
Page 12 of 20
FEATURES AND CONTROLS
SANTA FE
21 20
HYUNDAI
Audio control Cruise control
VOLUME
Raises or lowers speaker volume.
SEEK / PRESET
Press to change presets. Press and hold to seek stations.
MODE
Change the audio source. Hold to turn Audio power on/off.
MUTE
Mute the sound.
Bluetooth control
VOLUME
Raises or lowers speaker volume.
MUTE
Mute the microphone during a call.
TALK
Activates voice recognition.
CALL
Places and transfers calls.
END
Ends calls or cancels functions.
STEERING WHEEL FUNCTIONS
Cruise indicator
Cruise set indicator
To Set a Cruising Speed
1. Press CRUISE button
and the CRUISE indicator will illuminate in the
instrument cluster. Accelerate to desired cruising speed (above 25 mph).
2. Move the lever down (to SET-)
and remove your foot from the
accelerator pedal.
To Accelerate or DecelerateMove the lever up (to RES+)
to increase set cruising speed.
Move the lever down (to SET-) to decrease set cruising speed.
To Cancel Cruising SpeedPress CANCEL button
, depress brake pedal, or press CRUISE button
.
Page 13 of 20
MULTIMEDIA
SANTA FE
23 22
HYUNDAI
To Answer a Call: r 1 S F T T
button on the steering wheel.
To Reject a Call: r 1 S F T T
button on the steering wheel.
To Adjust Ring Volume: r 6 T F U I F 7 0 - 6 . & C V U U P O T P O U I F T U F F S J O H X I F F M To Transfer a Call to the Phone
(Private Call): r 1 S F T T B O E I P M E
button on the steering wheel until the
audio system transfers a call to the phone.
To Finish a Call: r 1 S F T T
button on the steering wheel.
BLUETOOTH OPERATIONAL TIPSIn the following situations you or the other party may have difficulty
hearing each other:
1. Keep the Bluetooth volume to a low level. High level volume may result
in distortion and echo.
2. When driving on a rough road, high speeds and/or with the window open.
3. When the air conditioning vents are facing the microphone and/or when
the air conditioning fan is at the max speed.
To redial previously dialed number,
press and hold .Steering wheel bluetooth control
VOLUME
Raises or lowers speaker volume.MUTEMute the microphone during a call.TALKActivates voice recognition.CALL
Places and transfers calls.ENDEnds calls or cancels functions.
Making a call using voice recognition: The menu tree identifies available voice recognition Bluetooth
® functions.
Calling by Name:1. P
ress
button.
2. Say the following command:
r i $ B M M + P I O u $ P O O F D U T U I F D B M M U P + P I O
r i $ B M M + P I O P O . P C J M F ) P N F 0 G G J D F $ P O O F D U T U I F D B M M
to John’s Mobile, Home, or Office phone number.
Dialing by Number:1.
Press
button.
2. Say “Call”.
3. Say “By number” when prompted.
4. Say desired phone numbers.
5. Say “Dial” to complete the number and make a call.
For complete list of commands, refer to your Owner’s Manual.VOICE RECOGNITION TIPSYour vehicle is equipped with Voice Recognition technology which allows
drivers to operate their phones without having to take their eyes off the road
to minimize distractions.
Voice recognition performance may be affected if driving with windows
and sun roof open; when the heating-cooling system is on; when passing in
a tunnel or when driving on rugged and uneven roads.
Quick reference on using voice commands
To start voice command. Press the
key, the following commands are available:
Command FunctionMore Help Provides guidance on commands that can be used anywhere in the system
Help Provides guidance on commands that can be used within the current mode.
Calls Calls saved in Contacts. Ex) Call “John”
Dial Call can be made by dialing the spoken numbers. Ex) Call “123”
Phone Provides guidance on Phone related commands. After saying this command,
say “Call History”, “Contacts” to execute corresponding functions.
Call History Displays the Call History screen.
Contacts
(Call by NameDisplays the Contacts screen. After saying this command, say the name of a
contact saved in the Contacts to automatically connect the cell.
Dial Number Display the Dial number screen. After saying this command, you can say the
number what you want to call.
Page 14 of 20
MULTIMEDIA
SANTA FE
25 24
HYUNDAI
BLUETOOTH PHONE OPERATION1. Press the SETUP
button.
2. Select “Phone” by turning and pressing the TUNE/ENTER
knob.
3. Select “Pair Phone” by turning and pressing the TUNE/ENTER knob.
4. Search for the device name as displayed on your mobile phone
and connect.
5. Input the passkey displayed on the Audio screen.
Venicle must be in Park to complete the pairing process.
Phone setup (pairing phone) with AudioType A Type BType A Type B
6. Pairing completion is displayed.Pairing tutorials, phone compatibility and
Operational tips can be found through the
Smart QR code using the QR reader
application on your Smartphone.BLUETOOTH PHONE PAIRING
NOTEAfter pairing is completed, transfer of the contact list to the audio system
will begin (ir your phone is supported). 1. Press the call
button on the
steering wheel remote controller
or press the PHONE button.
2. Press Yes button on the screen.4. Input the passkey.
(The initial passkey is 0000.)
5. Bluetooth
® becomes connected. 3. Search for the car name
and pair the device.
Phone setup (Pairing phone) with Navigation
Page 15 of 20
MULTIMEDIA
SANTA FE
27 26
HYUNDAI
Blue Link feature availability is dependent upon your Blue Link subscription package(s).BLUE LINK TELEMATICS SYSTEMPress the
button for access to the voice-response menu of services.
You have two options:
- You can say, “Main Menu” for a listing of main menu choices.
- You can directly select any of the listed menu items by saying its name.
- Press the button for navigation-related services.
- Press the button for SOS Emergency Assistance.
- Refer to your Blue Link User’s Manual for detailed information on system
operation.
- For immediate assistance with subscription services, please call
1-855-2BLUELINK (1-855-225-8354).
- Please register your Blue Link at www.myhyundai.com.
In-Car Voice Response Commands
New Destination
Service Link
Roadside Assistance
Valet Alert
Help
Cancel r 4 0 4 r / B W J H B U J P O r # M V F - J O L
You can download the Blue Link mobile app to your
compatible smart phone from the following sites:
t J 1 I P O F
® — Apple
® App Store
t " O E S P J E
® — Google Play
With this feature, you can lock or unlock your vehicle doors from
virtually anywhere by using the Blue Link mobile phone app, by dialing
the toll-free number, or by using the Blue Link owner’s website.
t 5 P V T F U I J T G F B U V S F
Z P V N V T U I B W F B # M V F - J O L 1 F S T P O B M
Identification Number (PIN). To create or change your PIN,
log on to www.MyHyundai.com.
t # Z # M V F - J O L . P C J M F " Q Q 4 F M F D U % 0 0 3 6 / - 0 $ , P S % 0 0 3
LOCK, as desired.
- Enter your Blue Link PIN.
- The command to lock or unlock your doors will be sent to
your vehicle.
t # Z Q I P O F % J B M U P M M G S F F BLUELINK (1-855-225-8354).
t # Z X F C T J U F - P H P O U P X X X . Z ) Z V O E B J D P N
T F M F D U # M V F - J O L
- Select Remote Services, then Remote Door Unlock/Lock.
- Input your Blue Link PIN. (If you need time to get to your
vehicle, specify a time delay before your vehicle will be
unlocked.)
Blue Link Mobile App
To Activate Remote Door Unlock/LockRemote Door Unlock/Lock
Page 16 of 20
MULTIMEDIA
SANTA FE
29 28
HYUNDAI
AUDIO Press POWER button
to turn radio on.
r TUNING / LISTENING TO CHANNELS
1. Press the Radio
button.
2 . Turn the TUNE/ENTER
knob to select the desired channel and press the knob.
NOTE
A clear view of the southern sky helps ensure XM
® radio reception.
r SETTING PRESET MEMORY BUTTONS (FM/AM/XM
®)
Press and hold any preset button (1-6)
until an audible beep is heard to
store current channel.
r ADJUSTING THE SOUND CONTROL
1. Press the SETUP
button.
4 F M F D U i 4 P V O E 4 F U U J O H T u C Z U V S O J O H B O E Q S F T T J O H U I F 5 6 / & & / 5 & 3
knob.
4 F M F D U i # B T T
u i . J E E M F
u i 5 S F C M F
u i ' B E F S
u P S i # B M B O D F u C Z U V S O J O H B O E
pressing the TUNE/ENTER
knob.
4. Adjust the sound by turning and pressing the TUNE/ENTER
knob.
Please refer to your Owner’s Manual for more detailed information on how to use your audio system.
Complimentary XM subscription ends three months following the vehicle date of sale.
Please contact XM Radio at 1-800-XM-RADIO (1-800-967-2346) to renew your XM subscription.Type A Type B
Audio mode Press POWER button
to turn radio on.
t TUNING/LISTENING TO CHANNELS
1. Press FM/AM
or SAT
button of XM
®.
2. Press the TUNE
button to desired channel.
NOTE A clear view of the southern sky helps ensure XM
® radio reception.
t
SETTING PRESET MEMORY BUTTONS (FM/AM/XM
® )
Press and hold any preset button (1-6)
on the screen until
an audible beep is heard to store current channel.
t
ADJUSTING THE SOUND CONTROL
1. Press the SETUP
button and press the SOUND
button to display the Sound Settings screen.
2. Touch on-screen arrows to adjust desired setting.
t
SELECTING TRACK THROUGH SEARCH (CD MODE)
Press the TUNE
button to search tracks.
Once the desired track name is displayed, press the ENTER button.
NAVIGATION
AUX, USB, AND iPod
® PORT
Use the jack to
connect an external
audio device and listen
to it through the audio
system speakers in
your vehicle.
