☐ BLUETOOTH – page 20-21
- Show phone compatibility website:
www.hyundaiusa.com/bluetooth
- Make a test call using customer’s paired phone
- Demonstrate Voice Recognition (VR)
☐ BLUE LINK – page 24-26 (if applicable) - Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button☐ WINDSHIELD WIPER/WASHER – page 09
- Explain wiper function
(int speed, front & rear wipers)
and how it may differ from
customer’s previous vehicle
☐ CLOCK – page 31
- Demonstrate how to set clock (including daylight savings
setting for Navigation equipped vehicles)
☐ UNLOCKING VEHICLE – page 02
- Demonstrate dual state unlock with key and remote keyless
entry
Scheduled Maintenance Normal Usage Severe Usage*Engine Oil And Filter* Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Fuel Additives Add Every 7,500 or 12 mos.
Tire Rotation Perform 7,500 Perform 7,500
Air Cleaner FilterInspect
Replace7,500
30,000Inspect
ReplaceSame As Normal
More Frequently
Battery Condition Inspect 7,500 Inspect Same As Normal
Vacuum Hose Inspect 7,500 Inspect Same As Normal
Climate Control Air Filter
(For Evaporator And Blower Unit)Replace 15,000 Replace More Frequently
Air Conditioning Refrigerant Inspect 15,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 15,000 Inspect Same As Normal
Drive Shafts & Boots Inspect 15,000 Inspect 7,500 or 6 mos.
Electronic Throttle Control Inspect 15,000 Inspect Same As Normal
Exhaust Pipe & Muffler Inspect 15,000 Inspect Same As Normal
Front Brake Disc / Pads, Calipers Inspect 15,000 Inspect More Frequently
Rear Brake Drums / Linings
Rear Brake Disc / PadsInspect 15,000 Inspect More Frequently
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball JointInspect 15,000 Inspect More Frequently
Suspension Mounting Bolts Inspect 15,000 Inspect Same As Normal
Brake/Clutch Fluid Inspect 30,000 Inspect Same As Normal
Fuel Filter Inspect 30,000 Inspect Same As Normal
Fuel Lines, Fuel Hoses And Connections Inspect 30,000 Inspect Same As Normal
Fuel Tank Air Filter Inspect 30,000 Inspect Same As Normal
Parking Brake Inspect 30,000 Inspect More Frequently
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 30,000 Inspect Same As Normal
Manual Transmission Fluid Inspect 37,500 Replace 75,000
Drive Belt (Alt, A/C)1st Inspect 60,000 or 72mos.
Add. Inspect 15,000 or 24mos.Inspect Same As Normal
Spark Plugs (Iridium Coated) Replace 100,000 or 10yrs. Replace More Frequently
Coolant1st Replace 120,000 or 10yrs.
Add Replace 30,000 or 24mos.Replace Same As Normal
Automatic Transmission Fluid No check, No service required Replace 60,000
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner’s Manual for details.Looking For more detailed information? This Quick Reference Guide does not replace your vehicle’s Owner’s Manual,
If you require additional information or are unsure of a specific issue. you should always refer to the vehicle’s Owner’s
Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing, however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference Guide,
and Hyundai reserves the right to change product specifications and equipment at any time without incoming
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.MAINTENANCE
NP150-82016-A
(Rev 01/21/15)
Printing 01/24/15
www.hyundai.com
Roadside Assistance:
1-800-243-7766
Consumer Affairs:
1-800-633-5151
XM®Radio:
1-800-967-2346
Blue Link:
1-855-2BLUELINK
(1-855-225-8354)
HYUNDAI
ELANTRA GTQuick Reference Guide
Page 14–15
Page 16–17
Automatic climate control Manual climate control
WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES☐ DEFROST- page 14-17
1 Press the front defrost button.
2 Set to warmest temperature setting.
3 Set to highest fan speed.
1
1
2
2
3
3
Wiper and
WasherPage 09
Audio/NavigationPage 27-30
Climate
ControlPage 14-17
TransmissionPage 33-34
Tr i p
ComputerPage 13Driver's Selectable
Steering ModePage 19
WARNING!
To reduce the risk of serious injury to yourself and others,
read and understand the important SAFETY INFORMATION
in your Owner’s Manual. How to: Pair phone to your vehicle. Refer to page 22.
Standard Audio
ManualNavigation Audio
Automatic
Table of contentsGETTING STARTED
Engine start/stop button 03
Front seat adjustment 04
Fuel filler lid 06
Headrest adjustment 05
Rear seat folding 05
Remote keyless entry 02
Seat belt adjustments 06
Steering wheel adjustments 06
FEATURES AND CONTROLS
Active ECO system 36
Child-protector rear door lock 32
Climate control–manual 14-15
Climate control–automatic 16-17
Cruise control system 18Door lock switch 07Driver's Selectable Steering Mode (DSSM) 19
Driver's main controls 07
Electronic Stability Control (ESC) 35
Headlights and fog lights 08
Instrument cluster 12-13
Instrument panel illumination 13
Interior lights 11
Rearview camera 37
Seat warmer and ventilation seats 32
Steering wheel controls 18-19
Sunroof 10
Tire pressure monitoring system (TPMS) 35
Transmission 33-34
Trip computer 13
Wiper and washer 09
MULTIMEDIAAUX, USB, and iPod
® Port 31
Blue Link Telematics System 24-26
Bluetooth operational tips 20
Bluetooth phone pairing 22
Clock adjustment 31
Navigation 28-30
Standard Audio 27
* Some vehicles may not be equipped with
all the listed features.
Headlights
and Fog lightsPage 08
Instrument
ClusterPage 12-13
Steering
Wheel
AdjustmentPage 06
Driver's Main
ControlsPage 07Use this Quick Reference Guide to
learn about the features that will
enhance your enjoyment of your
Hyundai. More detailed information
about these features are available in
your Owner’s Manual.Headlights Fog lights
GETTING STARTED
ELANTRA GT
03 02
HYUNDAI
ENGINE START / STOP BUTTONTo start the engine, depress the brake pedal and press start/stop
button. To shut engine OFF, stop the vehicle, shift to P (Park) and
press the start / stop button. With the engine
OFF, press the engine start / stop button
without depressing the brake pedal:
r
Once for ACC (Accessory) mode.
r
Twice for ON mode.
r
Three times for OFF.
Emergency situations Shut off engine while driving:
- Press engine start/stop button for more than 2 seconds or
press it 3 times consecutively within 3 seconds.
Restart engine while driving:
- Press engine start/stop button with shift lever in N (Neutral).
Download QR Code ReaderYou can download a QR reader app to your smart phone to take advantage
of the QR codes throughout this Quick Reference Guide.
iPhone
® - Apple
® App Store
Android
® - Google Play
BlackBerry® - BlackBerry
® App World
REMOTE KEYLESS ENTRY
Driver’s door Lock/UnlockSmart key must be within range.Press:Once – Unlock driver door
Twice – Unlock all doors
Third – Lock all doorsRemove mechanical keyPress and hold the release
A button and remove
the key.
Reinstall mechanical keyPut the key into the hole and push it until a click
sound is heard.
A
LockUnlockTrunk unlockPanic
Remote Key Smart Key
GETTING STARTED
ELANTRA GT
05 04
HYUNDAI
HEADREST ADJUSTMENT
Height adjustmentLock knob
To raise headrest height, pull up on headrest.To lower headrest, press lock knob while pushing
down on headrest.
REAR SEAT FOLDING
WARNING!
When folding the rear seat, never allow the rear seat components to
contact the front passenger seat as this may affect the proper
operation of the SRS Occupant Classification System (see Owner's
Manual for additional details).
FRONT SEAT ADJUSTMENT (MANUAL) FRONT SEAT ADJUSTMENT (POWER)
Lumbar supportForward and backward
Forward and backwardSeat cushion height
(for driver’s seat)
Seat cushion height
(for driver’s seat)
Seatback angle
Seatback angle
FEATURES AND CONTROLS
ELANTRA GT
11 10
HYUNDAI
INTERIOR LIGHTS
Push the lens
to turn
the map lamp on or off.
/OFF The lights stay off at all times,
except when individually turned on. /DOOR Map lamp and room lamp will turn on
when any door is open except trunk. /ON Map lamp and room lamp will turn on.Non sunroof:To turn the room lamp ON or OFF,
push the switch.With sunroof:Press the switch to turn on the
room lamp.
Press the switch to turn off the
room lamp.
Map lampRoom lampNon sunroof
Non sunroof With sunroof
With sunroof
SUNROOFSliding the sunroof
To Open
Press switch rearward.
Press switch rearward past
the detent to open completely.To ClosePress switch forward past the detent
to close completely.To TiltPress the switch up.To closePush the switch forward or pull the
switch down.
Tilting the sunroofNOTE
To slide the sunshade, press
open or close button.
Sunshade open button
Sunshade close button
