☐ BLUETOOTH – page 20-21
- Show phone compatibility website:
www.hyundaiusa.com/bluetooth
- Make a test call using customer’s paired phone
- Demonstrate Voice Recognition (VR)
☐ BLUE LINK – page 24-26 (if applicable) - Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button☐ WINDSHIELD WIPER/WASHER – page 09
- Explain wiper function
(int speed, front & rear wipers)
and how it may differ from
customer’s previous vehicle
☐ CLOCK – page 31
- Demonstrate how to set clock (including daylight savings
setting for Navigation equipped vehicles)
☐ UNLOCKING VEHICLE – page 02
- Demonstrate dual state unlock with key and remote keyless
entry
Scheduled Maintenance Normal Usage Severe Usage*Engine Oil And Filter* Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Fuel Additives Add Every 7,500 or 12 mos.
Tire Rotation Perform 7,500 Perform 7,500
Air Cleaner FilterInspect
Replace7,500
30,000Inspect
ReplaceSame As Normal
More Frequently
Battery Condition Inspect 7,500 Inspect Same As Normal
Vacuum Hose Inspect 7,500 Inspect Same As Normal
Climate Control Air Filter
(For Evaporator And Blower Unit)Replace 15,000 Replace More Frequently
Air Conditioning Refrigerant Inspect 15,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 15,000 Inspect Same As Normal
Drive Shafts & Boots Inspect 15,000 Inspect 7,500 or 6 mos.
Electronic Throttle Control Inspect 15,000 Inspect Same As Normal
Exhaust Pipe & Muffler Inspect 15,000 Inspect Same As Normal
Front Brake Disc / Pads, Calipers Inspect 15,000 Inspect More Frequently
Rear Brake Drums / Linings
Rear Brake Disc / PadsInspect 15,000 Inspect More Frequently
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball JointInspect 15,000 Inspect More Frequently
Suspension Mounting Bolts Inspect 15,000 Inspect Same As Normal
Brake/Clutch Fluid Inspect 30,000 Inspect Same As Normal
Fuel Filter Inspect 30,000 Inspect Same As Normal
Fuel Lines, Fuel Hoses And Connections Inspect 30,000 Inspect Same As Normal
Fuel Tank Air Filter Inspect 30,000 Inspect Same As Normal
Parking Brake Inspect 30,000 Inspect More Frequently
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 30,000 Inspect Same As Normal
Manual Transmission Fluid Inspect 37,500 Replace 75,000
Drive Belt (Alt, A/C)1st Inspect 60,000 or 72mos.
Add. Inspect 15,000 or 24mos.Inspect Same As Normal
Spark Plugs (Iridium Coated) Replace 100,000 or 10yrs. Replace More Frequently
Coolant1st Replace 120,000 or 10yrs.
Add Replace 30,000 or 24mos.Replace Same As Normal
Automatic Transmission Fluid No check, No service required Replace 60,000
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner’s Manual for details.Looking For more detailed information? This Quick Reference Guide does not replace your vehicle’s Owner’s Manual,
If you require additional information or are unsure of a specific issue. you should always refer to the vehicle’s Owner’s
Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing, however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference Guide,
and Hyundai reserves the right to change product specifications and equipment at any time without incoming
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.MAINTENANCE
NP150-82016-A
(Rev 01/21/15)
Printing 01/24/15
www.hyundai.com
Roadside Assistance:
1-800-243-7766
Consumer Affairs:
1-800-633-5151
XM®Radio:
1-800-967-2346
Blue Link:
1-855-2BLUELINK
(1-855-225-8354)
HYUNDAI
ELANTRA GTQuick Reference Guide
Page 14–15
Page 16–17
Automatic climate control Manual climate control
WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES☐ DEFROST- page 14-17
1 Press the front defrost button.
2 Set to warmest temperature setting.
3 Set to highest fan speed.
1
1
2
2
3
3
Page 5 of 20
GETTING STARTED
ELANTRA GT
07 06
HYUNDAI
DRIVER'S MAIN CONTROLSDOOR LOCK SWITCH
Window Auto down/up
(driver’s side only)Press past detent to fully
open/close window.Power Window Lock
SwitchDisables the power
window switches on the
passenger doors.Outside Rearview
MirrorsPress L (left) or R (right) on
the switch. Then adjust the
mirror by using the
directional switch.All doors will lock.
All doors will unlock.
FEATURES AND CONTROLS
Tilt
Telescopic
SEAT BELT ADJUSTMENT (Front seat)
Pull up to raise.
Press button and
push down to lower.
STEERING WHEEL ADJUSTMENTS
1. Pull the lever
down .
2. Set the angle and distance
.
3. Pull the lever
up.
NOTE* After adding fuel, always reinstall the
fuel cap onto the filler neck by
rotating it clockwise until it clicks one
time. Failure to do this may result in the
Check Engine Light illuminating.
* The fuel filler lid will open and close
only when the driver’s door is unlocked.
* Check the engine oil regularly
between recommended oil changes.
FUEL FILLER LID
Push on rear edge
of fuel door to open
Page 15 of 20
ELANTRA GT
27 26
) : 6 / % " *
STANDARD AUDIO Press POWER button
to turn radio on.
t TUNING / LISTENING TO CHANNELS
1. Press the Radio
button.
2. Turn the TUNE/ENTER
knob to select the desired channel and press the knob.
NOTE
A clear view of the southern sky is recommended to ensure XM
® radio reception.
t SETTING PRESET MEMORY BUTTONS (FM/AM/XM
® )
Press and hold any preset button (1-6)
until audible beep is heard
to store current channel.
t ADJUSTING THE SOUND CONTROL
1. Press the SETUP/CLOCK
button.
2. Select “Sound Settings” by turning and pressing the TUNE/ENTER
knob.
3. Select “Bass”, “Middle”, “Treble”, “Fader”, or “Balance” by turning and
pressing the TUNE/ENTER
knob.
4. Adjust the sound by turning and pressing the TUNE/ENTER
knob.
Blue Link Telematics SystemYour audio display will change during Blue Link system use. Please refer
to the Blue Link User’s Manual for detailed information on system use.Please refer to your Owner’s Manual for more detailed information on how to use your audio
system.
Complimentary XM
® subscription ends three months following the vehicle date of sale.
Please contact XM® Radio at 1-800-XM-RADIO (1-800-967-2346) to renew your XM
®
subscription.
Audio mode
Preconditions: t * H O J U J P O J T 0 ' '
t " M B S N J T B S N F E J F
W F I J D M F M P D L F E C Z L F Z G P C 3 F N P U F % P P S - P D L
t ( F B S T I J G U M F W F M J T J O U I F 1 1 B S L
Q P T J U J P O
t # S B L F Q F E B M J T O P U E F Q S F T T F E
t & O H J O F I P P E J T T F D V S F M Z D M P T F E
t " M M U I F E P P S T B S F D M P T F E B O E M P D L F E
t 5 I F U B J M H B U F P S U S V O L M J E J T D M P T F E
t 5 I F T F D V S J U Z Q B O J D T Z T U F N J T O P U B D U J W B U F E
t 5 I F Q S P Y J N J U Z L F Z J T O P U J O T J E F U I F W F I J D M F
t 5 I F C B U U F S Z Q P X F S J T O P U M P X
t 7 F I J D M F J T M P D B U F E J O B O P Q F O B S F B
t * U I B T C F F O M F T T U I B O E B Z T T J O D F M B T U W F I J D M F J H O J U J P O P G G
t 7 F I J D M F M P D B U F E J O B S F B X J U I H P P E D F M M S F D F Q U J P ORemote Start will terminate: t " G U F S N J O V U F T P S B G U F S T F M F D U F E F O H J O F U J N F S S V O T P V U J O O B W J H B U J P O
vehicles
t # S B L F J T Q S F T T F E X J U I P V U Q S P Y J N J U Z L F Z J O T J E F W F I J D M F
t " M B S N J T U S J H H F S F E X J U I P V U Q S P Y J N J U Z L F Z J O T J E F W F I J D M F
t % P P S U S V O L J T P Q F O F E G S P N J O T J E F U I F W F I J D M FNotice: Laws in some communities may restrict the use of the
features that remotely start the engine. For example, some laws may
require a person using the remote start feature to have the vehicle in
view when doing so or limit the length of time a vehicle engine may
idle. Please check local and state regulations for any requirements
and restrictions on remote starting of vehicles and engine idling time.
WARNING!
Do not remote start vehicle in an enclosed environment (i.e., closed garage). Prolonged operation of a
motor vehicle in an enclosed environment can cause a harmful build-up of carbon monoxide. Carbon
monoxide is harmful to your health. Exposure to high levels of carbon monoxide can cause headaches,
dizziness or in extreme cases unconsciousness and/or death. Do not leave children or animals
unattended in a vehicle while using the remote start function.
CAUTION!
If the vehicle’s windshield wipers are left on when the vehicle was last driven, then the wipers will turn
on if the remote start function is activated. To avoid damage to the wiper blades (i.e., due to heavy ice
or snow accumulated on the windshield), please always turn the vehicle’s windshield wipers off when
parking the vehicle.
Page 19 of 20
FEATURES AND CONTROLS
ELANTRA GT
35 34
HYUNDAI
TIRE PRESSURE MONITORING SYSTEM (TPMS)LOW TIRE PRESSURE INDICATOR
Illuminates if one or more of your tires is significantly under-inflated.
TPMS MALFUNCTION INDICATOR
Blinks for approximately one minute then remains illuminated when there
is a malfunction with the TPMS system. Have
the system checked by an
authorized Hyundai dealer.
NOTE: Tire pressure may vary in colder temperatures causing the low tire
pressure light
to illuminate.Low Tire Pressure Indicator /
TPMS Malfunction Indicator
ELECTRONIC STABILITY CONTROL (ESC)
The ESC system is an electronic
system designed to help the driver
maintain vehicle control under
adverse conditions.
To turn off Engine Controlpress the ESC OFF button shortly.To turn off Engine and Traction
Controlpress the ESC OFF button for more
than 3 seconds.
Shifting into Reverse
1. Depress the clutch pedal fully.
2. Ensure shifter is in Neutral.
3. Press the reverse lock-out button and shift left and forward to Reverse.
4. Release Clutch slowly for smooth acceleration.
MANUAL TRANSMISSION
