2016 DODGE JOURNEY load capacity

you may have on tire specifications or capability. Failure
to use equivalent replacement tires may adversely affect
the safety, handling, and ride of your vehicle.
WARNING!
•Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combinations
of unapproved tires and wheels may change sus-
pension dimensions and performance characteris-
tics, resulting in changes to steering, handling, and
braking of your vehicle. This can cause unpredict-
able handling and stress to steering and suspen-
sion components. You could lose control and have
a collision resulting in serious injury or death. Use
only the tire and wheel sizes with load ratings
approved for your vehicle.
(Continued)
WARNING! (Continued)
•Never use a tire with a smaller load index or
capacity, other than what was originally equipped
on your vehicle. Using a tire with a smaller load
index could result in tire overloading and failure.
You could lose control and have a collision.
• Failure to equip your vehicle with tires having
adequate speed capability can result in sudden tire
failure and loss of vehicle control.
CAUTION!
Replacing original tires with tires of a different size
may result in false speedometer and odometer read-
ings.
5
STARTING AND OPERATING 487

VEHICLE LOADING
The load carrying capacity of your vehicle is shown on
the “Vehicle Certification Label”. This information
should be used for passenger and luggage loading as
indicated.
Do not exceed the specified Gross Vehicle Weight Rating
(GVWR) or the Gross Axle Weight Rating (GAWR).
Vehicle Certification Label
Your vehicle has a Vehicle Certification Label affixed to
the drivers side B-Pillar or the rear of the driver ’s door.
The label contains the following information:
•Name of manufacturer
• Month and year of manufacture
• Gross Vehicle Weight Rating (GVWR)
• Gross Axle Weight Rating (GAWR) front •
Gross Axle Weight Rating (GAWR) rear
• Vehicle Identification Number (VIN)
• Type of Vehicle
• Month Day and Hour of Manufacture (MDH)
The bar code allows a computer scanner to read the VIN.
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total allowable weight of your vehicle.
This includes driver, passengers, and cargo. The total
load must be limited so that you do not exceed the
GVWR.
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear
axles. Distribute the load over the front and rear axles
evenly. Make sure that you do not exceed either front or
rear GAWR.
508 STARTING AND OPERATING

Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear
axles. Distribute the load over the front and rear axles
evenly. Make sure that you do not exceed either front or
rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica-
tion Label” in “Starting And Operating” for further
information.
WARNING!
It is important that you do not exceed the maximum
front or rear GAWR. A dangerous driving condition
can result if either rating is exceeded. You could lose
control of the vehicle and have a collision.
Tongue Weight (TW)
The tongue weight is the downward force exerted on the
hitch ball by the trailer. The recommended tongue weightis 10% to 15% of the vehicle’s GTW for a conventional
hitch. You must consider this as part of the load on your
vehicle.
Frontal Area
The frontal area is the maximum height multiplied by the
maximum width of the front of a trailer.
Trailer Sway Control — Electronic
Refer to “Electronic Brake Control System/Trailer Sway
Control (TSC)” in “Starting And Operating” for further
information.
Trailer Sway Control — Mechanical
The trailer sway control is a telescoping link that can be
installed between the hitch receiver and the trailer tongue
that typically provides adjustable friction associated with
the telescoping motion to dampen any unwanted trailer
swaying motions while traveling.
5
STARTING AND OPERATING 511

WARNING!(Continued)
•Total weight must be distributed between the tow
vehicle and the trailer such that the following four
ratings are not exceeded:
1. GVWR
2. GTW
3. GAWR
4. Tongue weight rating for the trailer hitch uti-
lized.
Towing Requirements — Tires
• Do not attempt to tow a trailer while using a compact
spare tire.
• Proper tire inflation pressures are essential to the safe
and satisfactory operation of your vehicle. Refer to “Tires – General Information” in “Starting And Oper-
ating” for proper tire inflation procedures.
• Check the trailer tires for proper tire inflation pres-
sures before trailer usage.
• Check for signs of tire wear or visible tire damage
before towing a trailer. Refer to “Tires – General
Information” in “Starting And Operating” for the
proper inspection procedure.
• When replacing tires, refer to “Tires – General Infor-
mation” in “Starting And Operating” for information
on replacement tires and for the proper tire replace-
ment procedures. Replacing tires with a higher load
carrying capacity will not increase the vehicle’s GVWR
and GAWR limits.
518 STARTING AND OPERATING

Towing Requirements — Trailer Brakes
•Do not interconnect the hydraulic brake system or
vacuum system of your vehicle with that of the trailer.
This could cause inadequate braking and possible
personal injury.
• An electronically actuated trailer brake controller is
required when towing a trailer with electronically
actuated brakes. When towing a trailer equipped with
a hydraulic surge actuated brake system, an electronic
brake controller is not required.
• Trailer brakes are recommended for trailers over
1,000 lbs (454 kg) and required for trailers in excess of
2,000 lbs (907 kg).
WARNING!
• Do not connect trailer brakes to your vehicle’s
hydraulic brake lines. It can overload your brake
system and cause it to fail. You might not have
brakes when you need them and could have a
collision.
• Towing any trailer will increase your stopping
distance. When towing you should allow for addi-
tional space between your vehicle and the vehicle
in front of you. Failure to do so could result in a
collision.
CAUTION!
If the trailer weighs more than 1,000 lbs (454 kg)
loaded, it should have its own brakes and they
should be of adequate capacity. Failure to do this
(Continued)
5
STARTING AND OPERATING 519

Oil, Engine......................... .565, 616
Capacity ............................ .614
Change Interval .....................331, 566
Checking ............................ .565
Dipstick ............................. .565
Disposal ............................. .568
Filter ............................ .568, 616
Filter Disposal ........................ .568
Identification Logo ..................... .566
Materials Added To ..................... .568
Pressure Warning Light ...................310
Recommendation ....................566, 614
Synthetic ............................ .568
Viscosity ......................... .567, 614
Oil Filter, Change ........................ .568
Oil Filter, Selection ....................... .568
Oil Pressure Light ........................ .310
Onboard Diagnostic System ..................561
Opener, Garage Door (HomeLink) .............255Operating Precautions
..................... .561
Operator Manual (Owner’s Manual) .............4
Outside Rearview Mirrors ...................121
Overhead Console ........................ .252
Overheating, Engine ...................... .529
Owner’s Manual (Operator Manual) ..........4,634
Paint Care ............................. .592
Panic Alarm ..............................23
Parking Brake ........................... .446
ParkSense System, Rear .....................242
Passenger Seat Back Tilt (Easy Entry System) ......218
Passing Light ........................... .229
Pets .................................. .106
Phone (Pairing) .......................... .155
Phone (Uconnect) ..................... .124, 148
Placard, Tire And Loading Information ..........471
Power Brakes .............................. .449
10
INDEX 651

SteeringColumn Controls ...................... .228
Column Lock ......................... .236
Power ........................... .444, 445
Tilt Column .......................... .236
Wheel, Heated ........................ .237
Wheel, Tilt ........................... .236
Steering Wheel Audio Controls ............385, 386
Steering Wheel Mounted Sound System Controls . . .385
Storage, Vehicle .......................... .416
Stuck, Freeing ........................... .550
Sunglasses Storage ....................... .254
Sun Roof .............................. .264
Sun Visor Extension ...................... .124
Supplemental Restraint System - Air Bag .........64
Sway Control, Trailer ...................462, 511
Synthetic Engine Oil ...................... .568
System, Remote Starting .....................26 Taillights
.............................. .610
Telescoping Steering Column .................236
Tie Down Hooks, Cargo ....................284
Tilt Steering Column ...................... .236
Time Delay, Headlight ..................... .226
Tire And Loading Information Placard .......470, 471
Tire Markings ........................... .463
Tires .....................111, 475, 481, 482, 635
Aging (Life Of Tires) .....................485
Air Pressure .......................... .475
Chains .............................. .488
Changing ............................ .532
Compact Spare ........................ .482
General Information ...............475, 481, 482
High Speed .......................... .478
Inflation Pressures ...................... .476
Jacking .............................. .532
Life Of Tires .......................... .485
Load Capacity ..................... .470,
472
656 INDEX
