2016 CITROEN RELAY display

217Level 1Level 2 Level 3co mment
Settings
Safety /Help
re

versing camera On
Display the reversing camera in reverse.
Off
ca

mera delay On
Maintain the display in the screen of the image
from the reversing camera for a maximum of
10
seconds or up to 8 mph (18 km/h).
Off
Settings Lamps
da

ytime lighting On
Activate or deactivate the automatic illumination
of headlamps when starting.
Off
Settings
d

oors and
locking Autoclose On
Activate or deactivate the automatic locking of
doors when the vehicle is moving.
Off
Touch Screen Audio - Telematic System
AUDIO and TELEMATICS
10

222Voice commands
Steering mounted controls
Information - using the system
Instead of touching the screen, you can
use your voice to issue commands to
the system. Voice interaction can be quickly used
if these buttons are pressed during
a voice message from the system; It
allows a voice command to be issued
di r e c t l y.
For example, if the system is speaking
a voice help message and if you want
to know the command to give the
system, by pressing these buttons, the
voice message is interrupted and the
desired voice command can be spoken
directly (so avoiding the need to listed
to the complete voice help message).
When the system is waiting for a voice
command from the user, pressing these
buttons closes the voice session.
To ensure that your voice commands
are always recognised by the system,
we recommend that you follow the
advice below:
-

s
peak with a normal tone of voice,
-

b
efore speaking, always wait for
the "beep" (audible signal),
-

t
he system is able to recognise
the voice commands delivered,
independent off gender, tone and
inflexion of the voice of the person
speaking,
-

k
eep the noise level inside the
vehicle as low as possible,
-

b
efore speaking a voice command,
ask other passengers not to speak.
As the system recognizes voice
commands whatever is said, when
more than one person speaks
at the same time, it is possible
that the system will recognise
commands different or additional to
the one intended, Every time a button is pressed, a
"beep" (audible signal) is produced
and the screen displays a page of
suggestions asking the user to speak a
command.
-
f or best operation, it is
recommended that the windows
and opening roof (for versions/
markets where it is available) be
closed to avoid inter ference from
extraneous noises.
This button switches on the
"Telephone" voice recognition mode,
which makes it possible to start calls,
view the log of recent /received/made,
display contacts, etc.
This button switches on the "Radio/
Media" voice recognition mode,
which makes it possible to tune to a
specific radio station radio or specific
AM/FM radio frequency, play a track
or an album on a USB memory stick /
iPod/MP3 CD.
Touch Screen Audio - Telematic System

224
Level 1Level 2Level 3co mment
c

all * Henri
d
u
pont Dials the telephone number associated with contact
Henri Dupont.
c

all* Henri
d
u
pontMobile phone Dials the telephone number labelled mobile phone
associated with contact Henri Dupont.
ca

ll number 0123456789 Calls the telephone number 0123456789.
ca

ll again Calls the number or contact of the last call made.
ca

ll back Calls the number or contact of the last call received.
re

cent calls* Displays the list of recent calls: outgoing, missed
and incoming.
ca

lls made* Displays the list of outgoing calls.
Missed calls* Displays the list of missed calls.
*

T

his function is available only if the telephone connected to the system supports downloading of contacts and recent calls and if the
download has been done.
"telephone" voice commands
If a telephone is connected to the system, these voice commands can be issued from any main screen page after pressing the telephone
button on the steering wheel, as long as there is no telephone call in progress.
If there is no telephone connected, a voice message announces: "No telephone connected. Connect a telephone and try again" and the voice
session will be closed.
Touch Screen Audio - Telematic System

225"telephone" voice commands
It is possible to replace the "Mobile phone" label by one of the three other labels available: "Home"; " Work"; "Other".Level 1 Level 2Level 3
co

mment
Incoming calls * Displays the list of calls received.
co

ntacts*
Displays the list of contacts on the telephone connected.
Search* Henri du pont Displays the contact Henri Dupont in the list of
contacts will all of the numbers saved.
Search* Henri
d
u
pontMobile phone Calls the telephone number labelled mobile phone
associated with contact Henri Dupont.
d

isplay messages** Displays the list of text messages received by the
telephone connected.
If the telephone allows the "first name"
(Henri) and "surname" (Dupont) to be entered in two separate fields, issue the following voice
commands:
-

"
Call"; "Henri"; "Dupont" or "call"; "Dupont"; "Henri".
-

"
Search"; "Henri"; "Dupont" or "Search"; "Dupont"; "Henri".
*

T
his function is only available if the telephone connected to the system supports downloading of contacts and recent calls and if the
download has been done.
** This function is only available if the telephone connected to the system supports the speaking text messages.
Touch Screen Audio - Telematic System
AUDIO and TELEMATICS
10

227"Media" voice commands
These voice commands can be issued from any main screen page after pressing the voice recognition button on the steering wheel, as long as
there is no telephone call in progress.Level 1 Level 2Level 3
co

mment
Play track "
ti

tle 1" Plays the track "Title 1".
Play album "Album 1 " Plays the songs in album "Album 1".
Play ar tist "Ar tist 1 " Plays the songs by "Artist 1".
Play musical genre "
j

azz" Plays the songs of the "Jazz" musical genre.
Play playlist "Playlist 1 " Plays the songs in the playlist "Playlist 1".
Play podcast "
ra

dio 1" Plays the podcast "Podcast 1".
Play audio book "Book 1 " Plays the audio book "Book 1".
Play track number "5 " Plays track number "5".
Select "
u

SB" Selects the USB media as the active audio source.
Scan "Album " Displays the list of albums available.
Touch Screen Audio - Telematic System
AUDIO and TELEMATICS
10

228"navigation" voice commands
These voice commands can be issued from any main screen page after pressing the voice recognition button on the steering wheel, as long as
there is no telephone call in progress.Level 1 Level 2Level 3
co

mment
Go home Displays the route home.
2
d

mode Changes to 2D mode.
3
d

mode Changes to 3D mode.
de

lete route Deletes the route displayed.
Add a favourite Displays the favourites screen page.
rep

eat instruction Repeats the last voice message spoken.
Touch Screen Audio - Telematic System

229"test message" voice commands
These voice commands can be issued from any main screen page after pressing the telephone button on the steering wheel, as long as there
is no telephone call in progress.Level 1 Level 2Level 3
co

mment
Send a text to 0123456789
Starts the voice procedure for sending
a
pre-defined text message using the system.
Send a text to Henri
d
u
pontMobile phone
d

isplay text Henri
d
u
pontMobile phone Displays the message box downloaded from
the


telephone.
Touch Screen Audio - Telematic System
AUDIO and TELEMATICS
10

232First steps
On/off, volume setting.
Select FM and AM wavebands.
Display the list of connected
telephones.Rotate: scroll through a list or adjust
radio station.
Press: confirm the option displayed in
the screen.
Select USB or AUX source. Information on the current radio
station or media.Repeat play.
Select preset stations.
FM-A, FM-B, FM- C, AM-A, AM-B,
AM-C. Mute / restore sound. Radio buttons 1 to 6:
Select a pre-set radio station.
Long press: pre-set a station.
Random (shuffle) play
Automatic frequency search up.
Select the next USB track.
Press and hold: fast for ward.
Display the menu and adjust options. Automatic frequency search down.
Select the previous USB track.
Press and hold: fast back.
Abandon the current operation.
Go up one level (menu or folder).
Audio System
