Radio



QUESTION



ANSWER



SOLUTION


The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...). The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling. Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more power ful transmitter in
the geographical area.
The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode. This phenomenon is normal and does not
indicate a fault with the audio system.
The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park). Have the aerial checked by a CITROËN dealer.
I cannot find some radio
stations in the list of
stations received. The station is not received or its name has changed in the list. Press and hold the "List" button at the steering
mounted controls to update the list of stations
received or press on the system update function:
"Update list". Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.
The name of the radio
station changes.

QUESTION



ANSWER



SOLUTION


The CD player sound is
poor. The CD used is scratched or of poor quality. Insert good quality CDs and store them in
suitable conditions.
The audio equipment settings (bass, treble, ambiences) are
unsuitable. Set the treble or bass level to 0, without selecting
an ambience.
Some characters in the
media information are not
displayed correctly while
playing. The audio system does not display some types of characters. Use standard characters to name tracks and
folders.
Playing of streaming files
does not start. The peripheral device connected does not support automatic play. Star t the playback from the device.
The names of tracks and
the track length are not
displayed on the screen
when streaming audio. The Bluetooth profile does not allow the transfer of this information.

69 Audio and Telematics



QUESTION



ANSWER



SOLUTION


I cannot connect my
Bluetooth telephone. The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

- Check that your telephone's Bluetooth
function is switched on.

- Check in the telephone settings that it is
"visible to all".
The Bluetooth telephone is not compatible with the system. You can check the compatibility of your
telephone at www.citroen.co.uk (ser vices).
The volume of the
telephone connected
in Bluetooth mode is
inaudible. The volume depends both on the system and on the telephone. Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.
The ambient noise level has an influence on the quality of
telephone communication. Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).
Some contacts are
duplicated in the list. The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated. Select "Display SIM card contacts" or "Display
telephone contacts".
Contacts are not shown in
alphabetical order. Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order. Modify the display setting in the telephone
directory.
The system does not
receive SMS text messages. The Bluetooth mode does not permit sending SMS text messages
to the system.

Te l e p h o n e

1 Audio and Telematics







DS Connect Nav


GPS satellite navigation - Connectivity - Multimedia audio - Bluetooth ®
telephone


Contents
First steps 2
Steering mounted controls 4
Menus 5
Voice commands 6
Navigation 12
Connected navigation 28
Connectivity 38
Radio Media 50
Te l e p h o n e 6 2
Settings 74
Frequently asked questions 84

The system is protected in such a way that it will only operate in
your vehicle.

The link below gives access to OSS (Open Source Software)
codes for the system.
http://www.psa-peugeot-citroen.com/oss
As a safety measure and because it requires sustained attention
by the driver, the pairing of a Bluetooth mobile telephone with
the Bluetooth hands-free system of your audio system must be
done with the vehicle stationary
and the ignition on.
The display of the energy economy mode message signals that
a change to standby is imminent. Refer to the Energy economy
(mode) section of your vehicle's handbook.

First steps


With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

Use the buttons below the touch screen for
access to the menus, then press the virtual
buttons in the touch screen. All of the touch
areas of the screen are white.
Each menu is displayed in one or two pages
(primary page and secondary page).

Secondary page

Primary page
The touch screen is of the "capacitive"
type.
To clean the screen, use a soft,
non-abrasive cloth (spectacles cloth)
with no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

Steering mounted controls



Media
(short press): change the
multimedia source.

Te l e p h o n e
(short press): call.

Call in progress
(short press):
access to telephone menu.

Te l e p h o n e
(long press): reject an
incoming call, end call, access to
telephone menu.






Voice commands
:
Short press, system voice
commands.
Long press, smartphone voice
commands via the system.

Decrease volume.



Radio
(rotate): automatic search for
the previous / next station.

Media
(rotate): previous / next track,
move in a list.

Shor t press
: Confirm a selection.
Other than selection, access to
presets.

Radio
: display the list of stations.

Media
: display the list of tracks.

Radio, press and hold
: update the
list of stations received.

Increase volume.

5 Audio and Telematics

Menus






Settings
Radio Media




Connected navigation

Driving
Connectivity

Te l e p h o n e


Enter settings for a personal profile and/
or adjust the settings for sound (balance,
ambience, ...), colour schemes and the display
(language, units, date, time, ...).

Select an audio source, a radio station, display
photographs.

Enter navigation settings and choose a
destination.
Use ser vices available in real time, depending
on equipment.


Access the trip computer.
Activate, deactivate, set certain vehicle
functions.



Operate certain applications on a smartphone
connected via MirrorLink
TM or CarPlay ®
.
Check the state of Bluetooth and Wi-Fi
connections.


Connect a telephone by Bluetooth
®
, read
messages and emails and send quick
messages.

Voice commands






First steps





Steering mounted controls





Information - Using the system


Press the Push To Talk
button and tell me what you'd
like after the tone.
Remember you can interrupt
me at any time by pressing this button.
If you press it again while I'm waiting for
you to speak, it'll end the conversation.
If you need to start over, say "cancel".
If you want to undo something, say
"undo".
And to get information and tips at
any time, just say "help". If you ask to
me do something and there's some
information missing that I need, I'll
give you some examples or take you
through it step by step.
There's more information available
in "novice" mode. You can set the
dialogue mode to "expert" when you
feel comfortable.

To ensure that voice commands are
always recognised by the system,
please obser ve the following
recommendations:


- speak in a normal tone without
breaking up words or raising your
voice.

- always wait for the "beep" (audible
signal) before speaking,

- for best operation, it is
recommended that the windows
and opening roof (if fitted) be
closed to avoid inter ference from
extraneous noises.

- before makking a voice command,
ask other passengers to not speak.


The voice commands, with a choice
of 12 languages (English, French,
Italian, Spanish, German, Dutch,
Portuguese, Polish, Turkish, Russian,
Arabic, Brazilian), are made using the
language previously chosen and set in
the system.

The voice commands in Arabic for:
"Navigate to address" and "Display POI
in the city", are not available.

Example of a "voice command" for
navigation:

"Navigate to address, 11 Regent
Street, London"
.

Example of a "voice command" for
the radio and media:

"Play ar tist" "Madonna"
.

Example of a "voice command" for
the telephone:

"Call David Miller"
.
Pressing the end of the lighting
control stalk activates the voice
commands function.
