2016 CADILLAC CT6 engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Technical Data 357
Technical Data Vehicle Identification Vehicle Identification
Number (VIN) . . . . . . . . . . . . . . . 357
Service Parts Identification
Label . . . . . . . . . . . . . . . . . . . . . . . . 357
Vehicle Data Capacities and
Specifications . . . . . . . . . . . . . . . 358
Engine Drive Belt Routing . . . . 360
Vehicle Identification Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the left side of the vehicle. It can be
seen through the windshield from
outside. The VIN also appears on
the Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement
parts. See “ Engine Specifications ”
under Capacities and Specifications
0 358 for the vehicle's engine code. Service Parts
Identification Label This label, behind the access panel
in the trunk on the passenger side,
has the following information:
.
Vehicle Identification
Number (VIN).
.
Model designation.
.
Paint information.
.
Production options and special
equipment.
Do not remove this label from the
vehicle.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
358 Technical Data
Vehicle Data Capacities and Specifications The following approximate capacities are given in metric and English conversions. See Recommended Fluids and
Lubricants 0 353 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and
charge amount, see the refrigerant label under the
hood. See your dealer for more information.
Cooling System – Engine
2.0L L4 Engine 8.6 L 9.1 qt
2.0L L4 Engine with Rear A/C 10.3 L 10.9 qt
3.0L V6 Twin Turbo Engine 10.6 L 11.2 qt
3.0L V6 Twin Turbo Engine with Rear A/C 12.3 L 13.0 qt
3.0L V6 Twin Turbo Engine with Rear A/C and Auxiliary
Radiator 13.2 L 13.9 qt
3.6L V6 Engine 9.8 L 10.4 qt
3.6L V6 Engine with Rear A/C 11.4 L 12.0 qt
Cooling System – Twin Turbo
3.0L V6 Engine Intercoolers 3.2 L 3.4 qt

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Technical Data 359Application Capacities
Metric English
Engine Oil with Filter
2.0L L4 Engine 4.7 L 5.0 qt
3.0L V6 Twin Turbo Engine 5.7 L 6.0 qt
3.6L V6 Engine 6.15 L 6.5 qt
Fuel Tank 72.7 L 19.2 gal
Transfer Case – AWD 0.8 L 0.85 qt
Wheel Nut Torque 150 Y 110 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
Engine SpecificationsEngine VIN Code Transmission Spark Plug Gap
2.0L L4 Engine X Automatic 0.75 – 0.90 mm (0.030 –
0.035 in)
3.0L V6 Twin Turbo Engine 6 Automatic 0.65 – 0.75 mm (0.26 –
0.030 in)
3.6L V6 Engine S Automatic 0.80 – 0.90 mm (0.031 –
0.035 in)

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
360 Technical Data
Engine Drive Belt Routing
2.0L L4 Engine
3.0L V6 Twin Turbo Engine 3.6L V6 Engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
370 Customer Information If the airbag has inflated, see What
Will You See after an Airbag
Inflates? 0 81 .
Managing the Vehicle Damage
Repair Process In the event that the vehicle requires
damage repairs, GM recommends
that you take an active role in its
repair. If you have a pre-determined
repair facility of choice, take the
vehicle there, or have it towed there.
Specify to the facility that any
required replacement collision parts
be original equipment parts, either
new Genuine GM parts or recycled
original GM parts. Remember,
recycled parts will not be covered by
the GM vehicle warranty.
Insurance pays the bill for the repair,
but you must live with the repair.
Depending on your policy limits,
your insurance company may
initially value the repair using
aftermarket parts. Discuss this with
the repair professional, and insist on
Genuine GM parts. Remember,
if the vehicle is leased, you may be
obligated to have the vehicle repaired with Genuine GM parts,
even if your insurance coverage
does not pay the full cost.
If another party's insurance
company is paying for the repairs,
you are not obligated to accept a
repair valuation based on that
insurance company's collision policy
repair limits, as you have no
contractual limits with that company.
In such cases, you can have control
of the repair and parts choices as
long as the cost stays within
reasonable limits.
Service Publications
Ordering Information Service Manuals Service Manuals have the diagnosis
and repair information on the
engines, transmission, axle,
suspension, brakes, electrical,
steering, body, etc.
Service Bulletins
Service Bulletins give additional
technical service information
needed to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions
to assist in the diagnosis and
service of the vehicle.
Owner Information Owner publications are written
specifically for owners and intended
to provide basic operational
information about the vehicle. The
Owner Manual includes the
Maintenance Schedule for all
models.
In-Portfolio: Includes a Portfolio,
Owner Manual, and Warranty
Manual.
RETAIL SELL PRICE: $35.00 –
$40.00 (U.S.) plus handling and
shipping fees.
Without Pouch: Owner Manual only.
RETAIL SELL PRICE:
$25.00 (U.S.) plus handling and
shipping fees.
Current and Past Models
Technical Service Bulletins and
Manuals are available for current
and past model GM vehicles.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
372 Customer Information To contact NHTSA, you may call
the Vehicle Safety Hotline
toll-free at 1-888-327-4236 (TTY:
1-800-424-9153); go to http://
www.safercar.gov; or write to:
Administrator, NHTSA
1200 New Jersey Avenue, S.E.
Washington, D.C. 20590
You can also obtain other
information about motor vehicle
safety from http://
www.safercar.gov .
Reporting Safety Defects
to the Canadian
Government If you live in Canada, and you
believe that the vehicle has a safety
defect, notify Transport Canada
immediately, and notify General
Motors of Canada Company. Call
Transport Canada at
1-800-333-0510 or write to:
Transport Canada
Road Safety Branch
80 rue Noel
Gatineau, QC J8Z 0A1 Reporting Safety Defects
to General Motors In addition to notifying NHTSA (or
Transport Canada) in a situation like
this, notify General Motors.
Call 1-800-458-8006, or write:
Cadillac Customer Assistance
Center
Cadillac Motor Car Division
P.O. Box 33169
Detroit, MI 48232-5169
In Canada, call 1-888-446-2000,
or write:
Canadian Cadillac Customer Care
Centre, Mail Code: CA1-163-005
General Motors of Canada
Company
1908 Colonel Sam Drive
Oshawa, Ontario L1H 8P7 Vehicle Data
Recording and
Privacy The vehicle has a number of
computers that record information
about the vehicle ’ s performance and
how it is driven. For example, the
vehicle uses computer modules to
monitor and control engine and
transmission performance, to
monitor the conditions for airbag
deployment and deploy them in a
crash, and, if equipped, to provide
antilock braking to help the driver
control the vehicle. These modules
may store data to help the dealer
technician service the vehicle.
Some modules may also store data
about how the vehicle is operated,
such as rate of fuel consumption or
average speed. These modules may
retain personal preferences, such as
radio presets, seat positions, and
temperature settings.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
376 OnStar .
Obtain the Wi-Fi ®
hotspot name
or SSID and password,
if equipped.
Press
Q to connect to an
Advisor to:
.
Verify account information or
update contact information.
.
Get driving directions.
.
Receive a Diagnostic check of
the vehicle's key operating
systems.
.
Receive Roadside Assistance.
.
Manage Wi-Fi Settings,
if equipped.
Press
> to get a priority connection
to an OnStar Advisor available 24/
7 to:
.
Get help for an emergency.
.
Be a Good Samaritan or
respond to an AMBER Alert.
.
Get assistance in severe
weather or other crisis situations
and find evacuation routes. OnStar Services Emergency Emergency Services require an
active, OnStar subscription plan
(excludes Basic Plan). With
Automatic Crash Response, built-in
sensors can automatically alert a
specially trained OnStar Advisor
who is immediately connected in to
the vehicle to help.
Press
> for a priority connection to
an OnStar Advisor who can contact
emergency service providers, direct
them to your exact location, and
relay important information.
With OnStar Crisis Assist, specially
trained Advisors are available
24 hours a day, 7 days a week, to
provide a central point of contact,
assistance, and information during a
crisis.
With Roadside Assistance, Advisors
can locate a nearby service provider
to help with a flat tire, a battery
jump, or an empty gas tank. Security If equipped, OnStar provides these
services:
.
With Stolen Vehicle Assistance,
OnStar Advisors can use GPS to
pinpoint the vehicle and help
authorities quickly recover it.
.
With Remote Ignition Block,
if equipped, OnStar can block
the engine from being restarted.
.
With Stolen Vehicle Slowdown,
if equipped, OnStar can work
with law enforcement to
gradually slow the vehicle down.
Navigation OnStar navigation requires a
specific OnStar subscription plan.
Press
Q to receive Turn-by-Turn
directions or have them sent to the
vehicle ’ s navigation screen,
if equipped.
Turn-by-Turn Navigation
1. Press
Q to connect to an
Advisor.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Index 385
Index A Accessories and
Modifications . . . . . . . . . . . . . . . . . . 262
Accessory Power . . . . . . . . . . . . . . . 206
Adaptive Cruise Control . . . . . . . . 223
Add-On Electrical Equipment . . . 260
Additional Information
OnStar ®
. . . . . . . . . . . . . . . . . . . . . . 379
Additional Maintenance
and Care . . . . . . . . . . . . . . . . . . . . . . 350
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . 60
Lumbar, Rear Seats . . . . . . . . . . . . 68
Thigh Support . . . . . . . . . . . . . . . . . . 61
Air Cleaner/Filter, Engine . . . . . . . 273
Air Conditioning . . . . . . . . . . . 178, 185
Air Filter, Passenger
Compartment . . . . . . . . . . . . . . . . . 190
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 189
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . 87
How Does an Airbag
Restrain? . . . . . . . . . . . . . . . . . . . . . 80
Passenger Sensing System . . . . 82
What Makes an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 80
What Will You See after an
Airbag Inflates? . . . . . . . . . . . . . . . 81 Airbag System (cont'd)
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 79
Where Are the Airbags? . . . . . . . . 78
Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 86
Passenger Status Indicator . . . 130
Readiness Light . . . . . . . . . . . . . . 130
Servicing Airbag-Equipped
Vehicles . . . . . . . . . . . . . . . . . . . . . . . 86
System Check . . . . . . . . . . . . . . . . . . 76
Alarm
Vehicle Security . . . . . . . . . . . . . . . . 44
Alert
Lane Change . . . . . . . . . . . . . . . . . 246
Side Blind Zone (SBZA) . . . . . . 246
All-Season Tires . . . . . . . . . . . . . . . . 300
All-Wheel Drive . . . . . . . . . . . . 213, 284
Antilock Brake System (ABS) . . . 214
Warning Light . . . . . . . . . . . . . . . . . 135
Appearance Care
Exterior . . . . . . . . . . . . . . . . . . . . . . . 333
Interior . . . . . . . . . . . . . . . . . . . . . . . . 338
Armrest
Rear Seat . . . . . . . . . . . . . . . . . . . . . . 68
Armrest Storage . . . . . . . . . . . . . . . . 107
