Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
344 Service and Maintenance
Cadillac Premium
Care Maintenance Your vehicle comes with the
Cadillac Premium Care
Maintenance. It is a maintenance
program that covers select
maintenance services during the
first 4 years or 80 000 km
(50,000 mi), whichever comes first.
Cadillac Premium Care
Maintenance covers routine
maintenance services, when
scheduled in accordance with the
owner manual, including:
.
Oil changes based on the
vehicle's oil life monitor system.
.
Tire rotation every 12 000 km
(7,500 mi). .
Engine air cleaner filter
replacement.
.
Passenger compartment air filter
replacement.
.
Multi ‐ point vehicle inspection
(MPVI) performed by a qualified
technician.
Cadillac requires that all Cadillac
Premium Care Maintenance
services be performed by a Cadillac
authorized service dealer.
Maintenance
Schedule Owner Checks and Services At Each Fuel Stop
.
Check the engine oil level. See
Engine Oil 0 270 .
Once a Month
.
Check the tire inflation
pressures. See Tire
Pressure 0 306 .
.
Inspect the tires for wear. See
Tire Inspection 0 312 .
.
Check the windshield washer
fluid level. See Washer
Fluid 0 281 .
Engine Oil Change When the CHANGE ENGINE OIL
SOON message displays, have the
engine oil and filter changed within
the next 1 000 km/600 mi. If driven
under the best conditions, the
engine oil life system may not
indicate the need for vehicle service
for up to a year. The engine oil and
filter must be changed at least once

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Service and Maintenance 345a year and the oil life system must
be reset. Your trained dealer
technician can perform this work.
If the engine oil life system is reset
accidentally, service the vehicle
within 5 000 km/3,000 mi since the
last service. Reset the oil life
system when the oil is changed.
See Engine Oil Life System 0 272 .
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi Rotate the tires, if recommended for
the vehicle, and perform the
following services. See Tire
Rotation 0 313 .
.
Check engine oil level and oil
life percentage. If needed,
change engine oil and filter, and
reset oil life system. See Engine
Oil 0 270 and Engine Oil Life
System 0 272 .
.
Check engine coolant level. See
Engine Coolant 0 277 .
.
Check windshield washer fluid
level. See Washer Fluid 0 281 . .
Visually inspect windshield wiper
blades for wear, cracking,
or contamination. See Exterior
Care 0 333 . Replace worn or
damaged wiper blades. See
Wiper Blade
Replacement 0 286 .
.
Check tire inflation pressures.
See Tire Pressure 0 306 .
.
Inspect tire wear. See Tire
Inspection 0 312 .
.
Visually check for fluid leaks.
.
Inspect engine air cleaner filter.
See Engine Air Cleaner/
Filter 0 273 .
.
Inspect brake system. See
Exterior Care 0 333 .
.
Visually inspect steering,
suspension, and chassis
components for damaged, loose,
or missing parts or signs of
wear. See Exterior Care 0 333 .
.
Check restraint system
components. See Safety System
Check 0 75 .
.
Visually inspect fuel system for
damage or leaks. .
Visually inspect exhaust system
and nearby heat shields for
loose or damaged parts.
.
Lubricate body components. See
Exterior Care 0 333 .
.
Check starter switch. See Starter
Switch Check 0 285 .
.
Check automatic transmission
shift lock control function. See
Automatic Transmission Shift
Lock Control Function
Check 0 285 .
.
Check parking brake and
automatic transmission park
mechanism. See Park Brake and
P (Park) Mechanism
Check 0 286 .
.
Check accelerator pedal for
damage, high effort, or binding.
Replace if needed.
.
Visually inspect gas strut for
signs of wear, cracks, or other
damage. Check the hold open
ability of the strut. See your
dealer if service is required.
.
Inspect sunroof track and seal,
if equipped. See Sunroof 0 55 .

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
346 Service and Maintenance Maintenance Schedule
Additional Required
Services - Normal
12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 miRotate tires, if recommended for the vehicle, and
perform Required Services. Check engine oil level
and oil life percentage. Change engine oil and
filter, if needed. (1)
@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @Replace passenger compartment air filter. (2)
@ @ @ @ @ @Inspect evaporative control system. (3)
@ @ @Replace engine air cleaner filter. (4)
@ @ @Replace spark plugs. Inspect spark plug wires.
(2.0L and 3.0L Twin Turbo Engines)
@ @Replace spark plugs. Inspect spark plug wires.
(3.6L Engine Only)
@Drain and fill engine cooling system. (5)
@Change transfer case fluid, if equipped with
AWD. (6)
@Visually inspect accessory drive belts. (7)
@Replace brake fluid. (8)
Footnotes — Maintenance
Schedule Additional Required
Services - Normal
(1) Vehicles with different size front
and rear tires do not have tire
rotation. See Tire Rotation 0 313 . (2) Or every two years, whichever
comes first. More frequent
passenger compartment air filter
replacement may be needed if
driving in areas with heavy traffic,
poor air quality, high dust levels,
or environmental allergens. Passenger compartment air filter
replacement may also be needed if
there is reduced airflow, window
fogging, or odors. Your GM dealer
can help determine when to replace
the filter.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
348 Service and Maintenance Maintenance Schedule
Additional Required
Services - Severe
12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 miRotate tires, if recommended for the vehicle, and
perform Required Services. Check engine oil level
and oil life percentage. Change engine oil and
filter, if needed. (1)
@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @Replace passenger compartment air filter. (2)
@ @ @ @ @ @Inspect evaporative control system. (3)
@ @ @Replace engine air cleaner filter. (4)
@ @ @Replace spark plugs. Inspect spark plug wires.
(2.0L and 3.0L Twin Turbo Engines)
@ @Replace spark plugs. Inspect spark plug wires.
(3.6L Engine Only)
@Change automatic transmission fluid and filter.
@ @ @Change transfer case fluid, if equipped with
AWD. (5)
@ @ @Change rear axle fluid.
@ @ @Change front axle fluid, if equipped with AWD.
@ @ @Drain and fill engine cooling system. (6)
@Visually inspect accessory drive belts. (7)
@Replace brake fluid. (8)

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
350 Service and Maintenance
Additional
Maintenance and Care Your vehicle is an important
investment and caring for it properly
may help to avoid future costly
repairs. To maintain vehicle
performance, additional
maintenance services may be
required.
It is recommended that your dealer
perform these services — their
trained dealer technicians know
your vehicle best. Your dealer can
also perform a thorough
assessment with a multi-point
inspection to recommend when your
vehicle may need attention.
The following list is intended to
explain the services and conditions
to look for that may indicate
services are required.
Battery
The 12-volt battery supplies power
to start the engine and operate any
additional electrical accessories. .
To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
.
Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
.
Belts may need replacing if they
squeak or show signs of
cracking or splitting.
.
Trained dealer technicians have
access to tools and equipment
to inspect the belts and
recommend adjustment or
replacement when necessary.
Brakes
Brakes stop the vehicle and are
crucial to safe driving.
.
Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping. .
Trained dealer technicians have
access to tools and equipment
to inspect the brakes and
recommend quality parts
engineered for the vehicle.
Fluids
Proper fluid levels and approved
fluids protect the vehicle ’ s systems
and components. See
Recommended Fluids and
Lubricants 0 353 for GM approved
fluids.
.
Engine oil and windshield
washer fluid levels should be
checked at every fuel fill.
.
Instrument cluster lights may
come on to indicate that fluids
may be low and need to be
filled.
Hoses
Hoses transport fluids and should
be regularly inspected to ensure
that there are no cracks or leaks.
With a multi-point inspection, your
dealer can inspect the hoses and
advise if replacement is needed.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Service and Maintenance 353
Recommended Fluids, Lubricants, and Parts Recommended Fluids and Lubricants Usage Fluid/Lubricant
Engine Oil Engine oil meeting the dexos1 ™ specification of the proper SAE viscosity
grade. AC Delco dexos1 Synthetic Blend is recommended. See Engine
Oil 0 270 .
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL ®
Coolant.
See Engine Coolant 0 277 .
Hydraulic Brake System DOT 3 Hydraulic Brake Fluid (GM Part No. 19299818, in
Canada 19299819).
Windshield Washer Automotive windshield washer fluid that meets regional freeze protection
requirements.
Automatic Transmission DEXRON ®
-HP Automatic Transmission Fluid (GM Part No. 19300536, in
Canada 19300537).
Transfer Case (All-Wheel Drive) Transfer Case Fluid (GM Part No. 19331044, in Canada 19331045).
Rear Axle SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88863089, in
Canada 88863090) meeting GM Specification 9986285.
Rear Axle/Front Axle (All-Wheel
Drive) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88863089, in
Canada 88863090).
Hood Latch Assembly, Pivots, Spring
Anchor, and Release Pawl Lubriplate Lubricant Aerosol (GM Part No. 89021668, in
Canada 89021674) or lubricant meeting requirements of NLGI #2,
Category LB or GC-LB.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
354 Service and Maintenance Usage Fluid/Lubricant
Key Lock Cylinders, Hood and Door
Hinges Multi-Purpose Lubricant, Superlube (GM Part No. 12346241, in
Canada 10953474).
Weatherstrip Conditioning Weatherstrip Lubricant (GM Part No. 3634770, in Canada 10953518) or
Dielectric Silicone Grease (GM Part No. 12345579, in Canada 10953481).
Maintenance Replacement Parts Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part GM Part Number ACDelco Part Number
Engine Air Cleaner/Filter
2.0L L4 Engine 23184137 A3205C
3.0L V6 Twin Turbo Engine (Driver Side) 23441383 A3207C
3.0L V6 Twin Turbo Engine (Passenger Side) 23450879 A3206C
3.6L V6 Engine 23458700 A3204C
Engine Oil Filter
2.0L L4 Engine 12640445 PF64
3.0L V6 Twin Turbo Engine 19330000 PF63E
3.6L V6 Engine 19330000 PF63E
Passenger Compartment Air Filter 13356916 CF185

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Service and Maintenance 355Part GM Part Number ACDelco Part Number
Spark Plugs
2.0L L4 Engine 12647827 41-125
3.0L V6 Twin Turbo Engine 12650283 41-131
3.6L V6 Engine 12646780 41-130
Wiper Blades
Driver Side – 60 cm (23.62 in) 13227404 —
Passenger Side – 45 cm (17.72 in) 25882578 —
