2015 VOLKSWAGEN PASSAT Owners Manual

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Pedals

Fig. 155 Pedals in vehicles with manual transmission: 1 Accelerator pedal, 2 Brake pedal, 3 Clutch pedal.

Fig. 156 Pedals in vehicles with automatic transmission: 1 Accelerator pedal, 2 Brake pedal.

WARNING
Objects in the driver footwell can prevent the pedals from moving freely. This can cause loss of vehicle control and increase the risk of serious personal injuries.
x Always make sure that nothing can interfere with the pedals.
x Always fasten floor mats securely to the floor.
x Never put floor mats or other floor coverings on top of already installed floor mats.
x Always make sure that nothing can fall into the driver footwell while the vehicle is moving.
NOTICE
Always make sure that the pedals are able to move freely and that nothing can interfere with them. If a brake circuit fails, more brake pedal travel will be needed to bring the vehicle to a stop. The brake pedal must be pressed farther and harder than normal.
Manual transmission: Gearshift lever

Fig. 157 Gearshift pattern of a 5-speed manual transmission.

Fig. 158 Gearshift pattern of a 6-speed manual transmission.

The positions of the individual gears are shown on the gearshift lever ⇒ fig. 157 or ⇒ fig. 158.
x Depress the clutch pedal all the way and hold.
x Move the gearshift lever into the desired position.
x Release the clutch pedal to engage the gear.
The clutch pedal must be fully depressed to start the engine.
Shifting into reverse
x Only shift to the reverse gear when the vehicle is not moving.
x Depress the clutch pedal fully and hold ⇒ .
x Move the gearshift lever to neutral and press down.
x Move the shift lever to the left and then push forward into the reverse gear position ⇒ fig. 157 (R)
or ⇒ fig. 158 (R).
x Release the clutch pedal to engage the gear.
Downshifting
You should always downshift gear by gear when driving, meaning always into the next lowest gear. Do
not downshift when the engine rpm (revolutions per minute) is too high ⇒ . At fast speeds or high engine rpms, skipping over one or more gears when downshifting can cause damage to the clutch and
transmission, even if a gear is not engaged ⇒ .
WARNING
Downshifting to a lower gear incorrectly can result in loss of vehicle control and can cause accidents and serious personal injuries.
WARNING
When the engine is running and a gear is engaged, the vehicle will start to move as soon as the clutch pedal is released, even when the parking brake is applied. This also applies when the parking brake is engaged.
x Never shift into reverse when the vehicle is moving.
NOTICE
Shifting down to a gear that is too low when driving at fast speeds or high engine rpms can cause extensive damage to the clutch and transmission. That is true even if the clutch pedal is pressed so that the clutch is not engaged.
NOTICE
To help prevent damage and premature wear:
x Do not rest your hand on the gearshift lever while driving. Over time, the pressure will cause premature wear in the transmission.
x Make sure that the vehicle has come to a complete stop before shifting into reverse.
x Always depress the clutch pedal all the way when changing gears.
x Do not hold the vehicle on a hill using engine power with the clutch pedal partially engaged and the engine running.

Automatic transmission: Selector lever

Fig. 159 Automatic transmission selector lever with shift lever release button (arrow).

Automatic Shift Lock (ASL)
The Automatic Shift Lock (ASL) in Park (P) and Neutral (N) prevents drive positions from being en-gaged inadvertently, which would cause the vehicle to move.
To release the ASL, depress and hold the brake pedal with the ignition switched on. Press the release button on the selector lever at the same time.
The ASL is not engaged if the selector lever is moved quickly through Neutral (N) (e.g., when shifting from Reverse (R) to Drive (D)). This makes it possible to “rock” the vehicle backwards and forwards if it is stuck in snow or mud. The ASL engages automatically if the brake pedal is not depressed and the lever is in Neutral (N) for more than about 1 second and the vehicle is traveling no faster than about 3 mph (5 km/h).
In rare cases, the ASL may not engage on vehicles with DSG® Direct Shift Gearbox. If this happens, power to the drive wheels will be interrupted to prevent the vehicle from moving unexpectedly. The green indicator light K will blink and a text message will be displayed. To engage the Automatic Shift Lock (ASL):
x Depress and then release the brake pedal. Try to engage the ASL again.
WARNING
Moving the selector lever to the wrong position can cause loss of vehicle control, a collision, and serious personal injury.
x Never accelerate when moving the selector lever.
x When the engine is running and a drive position is engaged, the vehicle will start to move as soon as the brake pedal is released.
x Never shift into Reverse or Park when the vehicle is moving.
WARNING
Unintended vehicle movement can cause serious personal injury.
x Never get out of the driver's seat while the engine is running, especially when the trans-mission is in a drive gear. If you must leave your vehicle while the engine is running, always set the parking brake and shift the transmission into Park (P).
x Never leave the vehicle in Neutral (N). It will roll down hills, whether the engine is running or not.
x When the engine is running and a drive gear - Drive (D), Sport Drive (S), or Reverse (R) - has been selected, press and hold the brake pedal to keep the vehicle from moving. The ve-hicle may “creep” and move forward or backward even if the engine is idling slowly.
x Never shift into Reverse (R) or Park (P) when the vehicle is moving.
NOTICE
Even though the transmission is in Park (P), the vehicle may move a couple of inches (a few centimeters) forwards or backwards if you take your foot off the brake pedal after stopping the vehicle without first setting the parking brake.
If the selector lever is moved into Neutral (N) by mistake when the vehicle is moving, take your foot off the accelerator pedal. Wait until the engine speed has dropped to idle speed before moving the selector lever into a drive gear.

Leaving the selector lever for a long period of time in any position other than Park (P) when the ignition is switched off can drain the vehicle battery.
Shifting with Tiptronic®

Fig. 160 Selector lever in Tiptronic position.

Fig. 161 Steering wheel with optional Tiptronic shift paddles.

Using Tiptronic with the shift paddles behind the steering wheel
x The paddles ⇒ fig. 161 work when the selector lever is in the Tiptronic position or when the selec-tor lever is in Drive (D) or Sport Drive (S). You do not have to move the selector lever over to the right into the Tiptronic position.
x To upshift, pull the paddle + /&& on the right toward you.
x To downshift, pull the paddle – on the left toward you.
x To switch off Tiptronic mode, pull the paddle on the right + /&& toward you and hold it there for about 1 second.
Tiptronic will switch off automatically if the shift paddles have not been used for a while and the selec-tor lever is not in the Tiptronic position.
NOTICE
x During acceleration, the transmission will shift automatically into the next higher gear before reaching maximum engine speed (rpm).
x If you use Tiptronic to shift into a lower gear, the transmission will downshift only when doing so will not over-rev the engine.
Driving with automatic transmission

WARNING
Rapid acceleration can cause skidding and loss of traction, especially on slippery roads, resulting in a loss of vehicle control, collisions, and serious personal injury.
x Only use the kick-down feature or fast acceleration if visibility, weather, road, and traffic conditions permit and other drivers will not be endangered by your driving and the vehicle's acceleration.
x Always adapt your driving to the traffic flow.
NOTICE
x When stopping on hills with the transmission in a drive gear, do not use the accelerator to help prevent the vehicle from rolling backwards. This can cause the automatic transmission to overheat and be damaged.
x Never let the vehicle coast or roll down a hill in Neutral (N), especially when the engine is not running. The transmission will not be lubricated and will be damaged.
Automatic transmission malfunction
