Open doors, hood, and rear hatch
The instrument cluster display indicates if any doors, the engine hood, or rear hatch are open once the vehicle has been unlocked, and while the vehicle is in motion. There may also be an audible warning chime. Different models and equipment versions may have different displays.

Key to ⇒ fig. 11 See
A

▪ Range
▪ Range b (Diesel engines only: visible only when the AdBlue range has fallen to less than 1500 mi or 2400 km)
▪ Avg. consumption
▪ Consumption
▪ Speed warning
▪ Digital speed display
▪ Average speed
▪ Distance
Assist systems
▪ Front Assist on/off
Navigation ⇒ Booklet Radio, Navigation System
Audio ⇒ Booklet Radio, Navigation System
Telephone ⇒ Booklet Mobile Phone Package
Vehicle status
Using the instrument cluster menus

Fig. 14 Right side of the multi-function steering wheel (if equipped): Controls for the menus and information displays in the instrument cluster.

Display Function
Travel time Driving time in hours (h) and minutes (min) corresponding
to trip memories 1, 2, and 3 (toggle).
Conv. con-
sumer
Displays any convenience equipment in the vehicle that
is currently affecting fuel consumption.
Range  --
mi Estimated distance in miles (km) that the vehicle can go
with the fuel left in the tank the way you are currently
driving. Takes account of the current fuel consumption,
among other things. Range  --
km
Range b
Diesel engines only: Estimated distance in miles (km)
that the vehicle can go with the AdBlue left in the tank.
Visible only when the AdBlue range has fallen to less
than 1500 mi or 2400 km.
Avg. con-
sumption
--.- mpg
Average fuel consumption in miles per gallon (l/100 km)
on trips per trip memories 1, 2, and 3 (toggle). For the
since start trip memory, the value is displayed once
the vehicle has been driven about 330 feet (100 m). Until
then, dashes appear instead of a number. The value
displayed is updated every second.
Avg. con-
sumption
--.-
l/100 km
Consumption
--.- mpg
Current fuel consumption in miles per gallon (l/100 km)
while driving.
When units are set to miles, dashes appear instead of a
number when the engine is running and the vehicle is
standing still.
When units are set to kilometers, the display shows liters
consumed per hour when the engine is running and the
vehicle is standing still.
Consumption
--.-
l/100 km
Speed warn-
ing
--- mph
When the set speed (from 20–155 mph or 30–250 km/h)
is exceeded, an acoustic warning sounds and a visual
message may also appear in the instrument cluster dis-

Selective catalytic reduction (AdBlue®)

Lights
up
Possible cause or meaning
⇒  Proper response
together
with
ing or not filled with standard
AdBlue.
authorized Volkswagen dealer
or an authorized Volkswagen
Service Facility.
>

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
AdBlue information

Refilling AdBlue

Fig. 163 Right rear side of the vehicle: Opening the fuel filler flap.

Fig. 164 AdBlue tank with filler neck cap 1 and refill bottle 2.

x Vertically insert the neck of the refill container (2) into the AdBlue tank filler neck and turn clock-wise to hand-tighten.
x Press the refill container in the direction of the tank filler neck and keep pressed.
x Add at least 1 gallon (3.8 liters) of AdBlue, which is 2 refill bottles. Adding a smaller amount is not sufficient.
x Wait until the contents of the refill container have flowed into the AdBlue tank. Do not squeeze or damage the refill container!
x Unscrew the refill container counterclockwise and lift it out carefully ⇒ .
x AdBlue stops flowing from the refill bottle when the AdBlue tank is completely full.
Closing the fuel filler neck
x Screw the fuel filler neck cap (1) clockwise onto the fuel filler neck until the cap locks into place.
x Close the cover.
Things to do before driving again
x After refilling, switch on only the ignition.
x Leave the ignition switched on for at least 30 seconds so that system can detect the refill.
x Do not start the engine for 30 seconds!
WARNING
Store AdBlue only in its closed original container and in a safe place.
x To reduce the risk of poisoning, never keep AdBlue in empty food or beverage containers that might mislead someone into drinking from them.
x Always store AdBlue outside the reach of children.
NOTICE
x Use only AdBlue or any Diesel Exhaust Fluid that expressly conforms to International Or-ganization for Standardization specification ISO 22241-1. Using a DEF that does not meet the requirements of ISO 22241-1 can seriously damage your vehicle’s engine.
x Never mix water or any other substances or additives with AdBlue. Damage caused by such additives will not be covered by any Volkswagen limited warranty.
x Never put AdBlue into the diesel fuel tank! Otherwise the engine may be damaged!
x Do not carry a refill container in the vehicle all the time or routinely. Due to temperature fluctuations and damage, the container could start leaking and the AdBlue could damage the vehicle interior.
Dispose of the refill container in an environmentally-responsible manner.
Appropriate AdBlue refill containers can be obtained from an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
