Roof rack

Attaching the roof rack base carrier and roof rack

Fig. 96 Mounting points for the base carrier and roof rack on 2-door vehicles.

Fig. 97 Mounting points for the base carrier and roof rack on 4-door vehicles.

Mounting the roof rack base carrier and roof rack on 4-door vehicles
Always attach the base carrier and roof rack correctly.
Always carefully follow the installation instructions from the base carrier or roof rack manufacturer.
The front mounting holes are on the underside of the roof frame. They are sealed with plastic screws
that must be removed before installation ⇒ fig. 97 (magnified view on left). The rear markings for the base carrier are on the underside of the roof frame (magnified view on right).
The holes and markings are only visible when the door is open.
Only mount the roof rack base carrier on the markings shown in the illustration.
Once you have installed the base carrier correctly, you can secure the roof rack on the base carrier according to the manufacturer's instructions.
WARNING
Installing or using a base carrier or roof rack improperly can cause the entire system to fly off the vehicle, causing accidents and injuries.
x Always follow the installation instructions provided by the manufacturer.
x Use the base carrier and roof rack only if they are undamaged and properly installed.
x Secure the roof rack base carrier only at the attachment points shown in the illustration
⇒ fig. 96 or ⇒ fig. 97.
x Always install the base carrier and roof rack properly.
x Make sure that all bolts and fasteners are properly installed and properly tightened before every trip and retighten them as needed after driving a short distance. During a long trip, check all bolts and fasteners at each stop.
x Always properly install special fixtures for items such as bicycles, skis, surfboards, etc.
x Do not modify or repair the base carrier or roof rack.
Follow the installation instructions provided for installing the roof rack system. Always carry them in the vehicle.
Securing a load on the roof rack

Checking the mountings
After the base carrier and roof rack have been installed, check all bolts and fasteners after driving a short time and at regular intervals thereafter.
WARNING
If the maximum permissible roof load is exceeded, accidents and substantial vehicle damage may occur.
x Never exceed the specified roof load, the maximum Gross Axle Weight Rating, or the Gross Vehicle Weight Rating.
x Do not exceed the loading capacity of the roof rack, even if the permissible roof load is not fully utilized.
x Always make sure that loads are evenly distributed and that heavier items are, as far as possible, toward the front.
WARNING
Loose or improperly secured items can fall off the roof rack and cause accidents and injuries.
x Always use suitable, undamaged tie-down ropes and ratchet straps.
x Secure the load properly.

Trailer towing

WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and carrying heavy or large things can change the way the vehicle handles, increase the distance it needs to stop safely, and cause accidents.
x Always secure the load properly with suitable and undamaged straps so that the load will not shift.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under unfavorable load, weather, or wind conditions.
x Trailers with a high center of gravity tip more easily than trailers with a low center of gravi-ty.
x Always avoid sudden maneuvers and hard braking.
x Be especially careful when passing other vehicles.
x Reduce speed immediately if the trailer shows the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas, the speed limits for vehicles towing trailers are lower than for vehicles without trailers. Never drive faster than 50 mph (80 km/h; under ex-ceptional circumstances, 60 mph - 100 km/h) when towing a trailer. This applies even if the local speed limit is higher.
If you are driving a new vehicle or a vehicle with a new or rebuilt engine, do not tow a trailer
during the break-in period, about 600 miles (1000 km) ⇒ Parts, accessories, repairs, and modifica-tions.
If you tow a trailer, your vehicle may need maintenance more often because of the extra load it has to move.
When you are not towing, remove the trailer hitch ball. This helps keep the trailer hitch from causing damage to your vehicle and to others if your vehicle is hit from behind.
Some models need a trailer hitch to tow or tow-start other vehicles. You may want to always carry the ball mount in the vehicle after it has been removed. Be sure to stow it securely.
Technical requirements

Do not use a bumper-mounted trailer hitch
Never install a trailer hitch on the bumper or on the bumper attachments. The trailer hitch must not interfere with the impact-absorbing bumper system. Do not make any changes to the vehicle exhaust and brake systems. From time to time, check that all trailer hitch mounting bolts are securely fastened. When you are not towing, remove the trailer hitch. This helps keep the trailer hitch from causing dam-age if your vehicle is hit from behind.
Engine cooling system
Towing a trailer makes the engine and its cooling system work harder. It is important that the engine cooling system is up to the job. Make sure that the cooling system has enough coolant.
Trailer brakes
If your trailer has its own brakes, make sure it meets all regulations. The trailer brake system must never be directly connected to the vehicle's brake system.
Safety chains
Always use safety chains between your vehicle and the trailer ⇒ Hitching up and connecting a trailer.
Trailer taillights
Trailer lights must meet all regulations ⇒ Hitching up and connecting a trailer.
Never connect the trailer lights directly to the electrical system of your vehicle.
Outside mirrors
If you cannot see the traffic behind you using the regular outside mirrors, then you must install extend-ed mirrors. Extended mirrors may also be required by law in some countries/states/provinces. Always adjust the outside mirrors before driving. It's vital that you always have a clear view to the rear of the vehicle.
Maximum power consumption for the trailer
Do not exceed the power ratings listed in the chart below.

Electrical load Maximum power
Brake lights total 108 watts
Turn signals per side 54 watts
Side marker lights total 100 watts
Taillights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.

NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for the rear lights or to any other unsuitable power sources. Use only a suitable connector to provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the regular maintenance and inspection intervals because of the extra load it has to pull.
Hitching up and connecting a trailer
