2015 VOLKSWAGEN E GOLF ESP

WARNING
Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control, collision, serious personal injury or even death.
x When the warning symbol appears in the instrument cluster, stop and inspect the tires.
x Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect the handling of the vehicle and stopping ability.
x Incorrect tire pressures and/or underinflation can also lead to sudden tire failure, includ-ing a blowout and sudden deflation, causing loss of vehicle control.
x The driver is responsible for the correct tire pressures for all tires on the vehicle. The
recommended tire pressure values are listed on a sticker inside the driver door ⇒ Tire infla-tion pressure.
x The TPMS can only work correctly when all tires on the vehicle are filled to the correct cold tire inflation pressure.
x Using incorrect tire pressure values can cause accidents or other damage. Always inflate the tires to the correct specified cold tire pressure values for the tires installed on the vehicle.
x Always maintain correct cold tire inflation pressure so that TPMS can do its job.
x Always inflate tires to the recommended and correct tire pressure before driving off.
x Driving with underinflated tires causes them to flex (bend) more, letting them get too hot, resulting in tread separation, sudden tire failure, and loss of control.
x Excessive speed and/overloading can cause heat buildup, sudden tire failure and loss of control.
x If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle will not handle well.
x If the tire is not “flat” and you do not have to change a wheel immediately, drive carefully and at reduced speed to the nearest service station to check the tire pressure and add air as required.
x When replacing tires or wheel rims on vehicles equipped with TPMS always read and heed
the information and all WARNINGS regarding ⇒  Tires and wheels.
x The Tire Pressure Monitoring System must be recalibrated whenever you remove and remount or change any wheel or tire on the vehicle, even if the reinstalled or replacement wheels and tires are identical to those that were removed and even if the tire pressure does
not change ⇒  Tire inflation pressure.
WARNING
Improper recalibration can cause the TPMS to give false warnings or to give no warning de-
spite dangerously low tire pressure ⇒  Tire Pressure Monitoring System (TPMS) and recali-bration through the Infotainment system.
Underinflation increases power consumption and tire wear.
Do not rely solely on the Tire Pressure Monitoring System. Check your tires regularly to make sure they are properly inflated and have no signs of damage, such as punctures, cuts, cracks, and blisters. Remove any objects that become embedded in the tire tread but have not penetrated into the body of tire itself.

When you take delivery of the vehicle, the Tire Pressure Monitoring System is calibrated for the factory-recommended cold tire inflation pressure for the tires on your vehicle, as shown on the label
inside the driver door ⇒  Tire inflation pressure.
x The system must be recalibrated through the Infotainment system whenever you remove and remount or change any wheel or tire on the vehicle, even if the reinstalled or replacement wheels and
tires are identical to those that were removed and even if the tire pressure does not change ⇒  Tire Pressure Monitoring System (TPMS) and recalibration through the Infotainment system.
x If you have to adjust the tire pressure on a warm tire, fill the tire with 2.0 - 4.35 psi (20 - 30 kPa)
more than the pressure specified on the tire pressure label inside the driver door ⇒  Tire inflation pressure.
x If the TPMS determines that the air pressure in at least one tire is too low, carefully check the pressure in all 4 tires with an accurate tire pressure gauge. Low tire pressure usually cannot be deter-mined by looking at the tire. This is especially true of low-profile tires.
If you have work done on your wheels or tires, inform the workshop that the vehicle is equipped with a Tire Pressure Monitoring System (TPMS).
New tires may expand slightly the first time they are driven at high speeds, which can trigger a tire pressure warning. Remember that tire pressure can only be properly measured when the tire is
“cold” ⇒  Tire inflation pressure.
Only replace old tires with tires that have been approved by Volkswagen for your vehicle type.
Indicator light (telltale)

Flashes Possible cause or meaning
⇒  Proper response

As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly underinflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly underinflated tire causes the tire to overheat and can lead to tire failure. Underinflation also reduces power efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.
Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s respon-sibility to maintain correct tire pressure, even if underinflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately 1 minute and then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists.
When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly.
Resetting and recalibrating the benchmark tire pressure
Resetting the tire pressures in the Infotainment system resets the benchmark tire pressure used by the TPMS to the current tire pressure in the tires based on the circumference of the tires.
x Switch on the ignition.
x Press the #!2 Infotainment button ⇒  Menu and system settings (SETUP).
x Tap the

To open, fold the center armrest down.
To close, fold the center armrest up.
WARNING
Always keep the armrest folded up when the vehicle is moving to reduce the risk of injury.
x Never let anybody, especially children, ride on the rear center armrest or in the center position on the rear seat when the armrest is folded down. An improper seating position can increase the risk of serious injury in a crash.
Cup holders in the rear trim

Fig. 116 In the trim next to the rear seats (2-door models only): Cup holder.

DANGER
High-voltage systems in the electric motor compartment and in other places on the vehicle can cause electrical shocks or even electrocution, severe burns, other serious injuries, and even death!
x The high-voltage system may also be active even when the ignition is switched off!
x Never touch high-voltage cables, the high-voltage battery, the poles of the high-voltage battery or any other parts of the high-voltage system, especially if these parts are damaged.
x Never attempt to work on any parts of the high-voltage system, the high-voltage cables or the high-voltage battery.
x Never open, maintain, disconnect or repair components or parts of the high-voltage sys-tem.
x Never damage, change or remove the orange high-voltage cables or disconnect them from the high-voltage system.
x Never open, modify or remove the cover of the high-voltage battery.
x Any work on the high-voltage system, or any other systems connected to it, should only be done by properly trained and qualified experts.
x Never perform any work near high-voltage components and high-voltage cables with ma-chining, shaping and sharp-edged tools or heat sources, for example, welding, soldering, hot air or thermal adhesives.
x The Volkswagen standards and guidelines must be adhered to when working on the high-voltage system or the high-voltage battery.
x During such work, keep the vehicle key safe and far enough away from the vehicle to pre-vent any risk of the ignition being accidentally switched on and the electrical system activat-ed.
x Any gasses emitted by or escaping from the high-voltage battery may be toxic or flamma-ble.
x Damage to the vehicle or to the high-voltage battery could lead to a leak of toxic gases, either immediately or at a later time. These emitted gases could also potentially cause a fire. If damage has been incurred, it is vital to then open the vehicle windows to allow any emitted gases to disperse. Do not inhale these gases.
x Never touch any liquids or expose yourself to any gases leaking from the high-voltage battery, especially if the battery has been damaged.
x Always inform any attending emergency services that the vehicle is equipped with a high-voltage battery.
WARNING
Switching off the electric drive while the vehicle is moving can make the vehicle harder to stop and result in loss of vehicle control, leading to collisions and severe personal injuries.
x Brake and steering assistance systems, the airbag system, safety belt pretensioners, and other vehicle safety features only work when the electric motor is activated.
x Switch off the electric drive only when the vehicle is not moving.

WARNING
The electric drive can get very hot. It can cause fires and serious personal injury.
x Never park the vehicle if oil, fuel, or other flammable substances are under or around the vehicle.
x Never leave the vehicle unattended with the electric motor drive ready, especially when it is in gear. The vehicle could move suddenly or some other unexpected event could occur, resulting in property damage, fire, or personal injury.
Indicator lights

Lights
up
Warning text in the instru-
ment cluster display / Pos-
sible meaning
Proper response
