2015 VOLKSWAGEN E GOLF ESP

If you continue to drive the vehicle closer to the obstacle despite a continuous signal chime, the sys-tem will no longer be able to measure the distance.
The intermittent signal chime volume decreases after a few seconds if the distance remains the same. The volume remains constant if the signal chime is continuous. As soon as the vehicle moves away from an obstacle again, the intermittent signal chime switches off automatically. If the vehicle moves towards an obstruction again, the intermittent signal chimes beep automatically.
Display
The graphic on the screen displays the scanned areas in several segments. The closer the vehicle drives towards an obstacle, the closer the segment will move to the vehicle in the display. The collision area has been reached at the latest when the second to last segment is displayed. Do not keep driving!

Vehicles with PDC at the front and rear
Area of the vehicle Distance of
the vehicle
from an ob-
stacle
Signal
tone
Segment color
if an obstacle
has been de-
tected
color display
only)
(A) Rear
center
Obstacle
not in
the ve-
hicle’s
path
about 12 –
63 in.
(31 – 160 cm)
– Grey
Rear
side
about 12 –
23 in.
(31 – 60 cm)
(B) Front
center
about 12 –
47 in.
(31 – 120 cm)
Front
side
about 12 –
23 in.
(31 – 60 cm)
(A) Rear
center
Obstacle
in the
vehicle’s
path
about 12 –
63 in.
(31 – 160 cm)
Intermittent
tone
Yellow
Rear
side
about 12 –
23 in.
(31 – 60 cm)

Opening the Air conditioning menu
x Press the -%.5 ⇒ fig. 150 button.
The current air conditioning settings are displayed in the upper section of the screen, for example, the temperatures that are currently set for the driver and passenger sides. Set temperatures up to +72 °F (+22 °C) are shown with blue arrows, while temperatures above +72 °F (+22 °C) are shown with red arrows.
Tap the corresponding function key to switch a function on or off, or to select a submenu.

Function
key
Effect
/&& Switch off the Climatronic.
/. Switch on the Climatronic.
Setup

WARNING
High voltage systems in the electric motor compartment can cause electrical shocks or even electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially careful when using jumper cables. The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the electric motor is acti-vated:
– Never touch ignition cables. Never touch other components of the high voltage elec-tronic ignition system.
– Never touch the wiring of the HID – High Intensity Discharge (Xenon) headlights.
x Read and heed the important information and warnings on cleaning the electric motor
compartment ⇒  Cleaning the electric motor compartment.
WARNING
Moving parts in the electric motor compartment can cause serious personal injury on con-tact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can cause serious personal injury. Always remember that the radiator fan is temperature-controlled and can come on suddenly even when the electric motor has been switched off for a while and the key has been removed from the ignition.
x If you have to perform a check or repair when the electric motor is activated, there are more risks from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the high-voltage ignition system. Always use extreme care.
– Always make sure that jewelry, loose clothing and long hair do not get caught in rotat-ing electric motor parts. Before starting any work remove your jewelry, take off your neck-tie, tie back and cover your hair, and do not wear clothing that can hang down and get caught in moving electric motor parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the electric motor compartment, for example cleaning rags and tools. Objects left behind can cause malfunctions, electric motor damage, and even fires.
WARNING
Additional materials in the electric motor compartment such as blankets can interfere with the operation of the electric motor and can cause fires, which can lead to serious injuries.
x Never cover the electric motor with blankets or other materials.
WARNING
Operating fluids and some materials in the electric motor compartment can catch fire easily, causing burns and other serious personal injuries!
x Never smoke near the electric motor compartment.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the electric motor. These fluids can ignite on hot electric motor parts and cause injuries.
x Always have a functional, approved fire extinguisher nearby.

Under normal driving conditions, the needle should be in the middle of the gauge. The temperature may go higher when the electric motor is working hard, especially in hot weather.
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
The following table explains what to do if the electric motor coolant temperature warning light ~ does not go out a few seconds after the electric motor is started or starts flashing while driving.

Flashes8 Possible cause Proper response
~
Electric motor coolant
temperature too high.

Flashes8 Possible cause Proper response
Electric motor coolant
system malfunction.

should always be replaced by a qualified technician, since the vehicle's onboard electrical system management has to be reset after replacing the battery. Only a qualified service facility is able to perform this necessary adjustment. Therefore, Volkswagen recommends to always have the 12 volt vehicle battery replaced by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Only use maintenance-free vehicle batteries meeting standards TL 825 06 and VW 7 50 73. These standards must date from July 2012 or later.
Disconnecting the 12 Volt vehicle battery
If the battery must be disconnected from the vehicle's electrical system, note the following:
x Switch off all electrical systems and devices and the ignition.
x Unlock the vehicle before disconnecting the battery; otherwise the alarm system will go off.
x First disconnect the negative cable (-) and then the positive cable (+) ⇒ .
Connecting the 12 volt vehicle battery
x Prior to reconnecting the battery, switch off all electrical systems and devices and the ignition.
x Connect the positive cable (+) first and then the negative cable (-) ⇒ .
After the battery is connected and the ignition is switched on, different indicator lights may light up. They should go out after you drive a short distance at 10–12 mph (15–20 km/h). If the indicator lights do not go out, contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility and have the vehicle checked.
If the battery was disconnected for a long time, the next scheduled service may not be correctly calcu-
lated and displayed ⇒  Instrument cluster. The maximum permissible service and maintenance inter-
vals are shown in the ⇒ Booklet Warranty and Maintenance.
Vehicles with Keyless Access
If the ignition will not start after reconnecting the vehicle battery, lock the vehicle from the outside and
unlock it again ⇒  Unlocking or locking the vehicle with Keyless Access. Then try to start the ignition again. If the ignition cannot be switched on, contact an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop for assistance.
Automatic electrical load deactivation
If the vehicle battery drain is high, the intelligent onboard electrical system management automatically takes steps to help prevent battery drain.
x The idle speed is increased so that the alternator provides more power.
x The power to devices that consume a lot of electricity is cut back or switched off completely.
The onboard electrical system management cannot always keep the battery from being drained. For example, the battery will drain if the electric motor is not activated, but the ignition is switched on or the parking lights are left on for a long time when parked.
What drains the vehicle battery?
x Long periods when the electric motor is not activated, especially when the ignition is on.
x Using electrical systems or devices when the electric motor is switched off.
x Leaving the vehicle unlocked for several days when not in use.
x The selector lever is left for a long period of time in any position other than Park (P) when the
ignition is switched off ⇒  Selector lever.

Treating stains
When treating stains, it may be necessary to clean the entire surface and not just the stain itself. This is especially true if the entire surface has become dirty from normal use. Otherwise, the area that is treated may become lighter than the untreated area. If you have questions or concerns, consult a professional cleaner.

Type of stain Recommended cleaning for fabric and uphol-
stery
Water-based stains,
such as coffee or
fruit juice.
– Moisten a sponge with water and rub the stain
gently with a circular motion.
– Wipe dry with an absorbent cloth.
Persistent stains,
such as chocolate
or make-up.
– Use only Volkswagen-approved cleaning products.
– If necessary, have the fabric or upholstery profes-
sionally cleaned.
Grease-based
stains, such as oil,
lipstick, etc.
– Use only Volkswagen-approved cleaning products.
– If necessary, have the fabric or upholstery profes-
sionally cleaned.

WARNING
If there is a malfunction in the airbag system, the airbag may not deploy correctly or at all, or it may deploy unexpectedly. This could cause fatal injuries.
x Have the airbag system inspected immediately by your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
NOTICE
If the upholstery on power seats, heated seats, or seats with airbag components is wet, electri-cal components and the vehicle electrical system could be damaged.
x If the seating surface becomes soaked, have it dried and the system components checked immediately by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Do not use steam cleaners because the steam could cause the dirt to penetrate deeper into the fabric and make it impossible to remove.
x Power washers and cooling sprays can damage the upholstery.
NOTICE
x Clean only the carpet and floor mats with brushes. Other textile surfaces can be damaged by brushes.
x If detergent pastes or mild detergent solutions are applied with a damp cloth or sponge, the surfactants in the detergent may cause visible lines to form at the edges of the area where the detergent was applied. These lines are generally difficult or impossible to remove.

WARNING
Inappropriate spare parts and accessories as well as improperly performed work, modifica-tions and repairs can cause vehicle damage, accidents and serious personal injuries.
x Volkswagen strongly recommends to only use accessories approved by Volkswagen and Genuine Volkswagen Parts®. These parts and accessories have been evaluated by Volkswagen for their suitability, reliability and safety.
x Have repairs and vehicle modifications performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities have the required tools, diagnostic equipment, repair infor-mation, and trained personnel to properly replace any airbag in your vehicle and assure sys-tem effectiveness in a crash.
x Only install parts on the vehicle that are consistent with factory-installed parts with re-spect to design and characteristics.
x Never store, mount, or attach objects, such as cup holders or phone cradles, on or next to the airbag module covers or within the airbags deployment zones.
x Only use wheel rim/tire combinations approved by Volkswagen for the respective vehicle type.
Break-in period
