2015 TOYOTA PRIUS C stop start

4848-2. Steps to take in an emergency
PRIUS c_U (OM52E68U)
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the hybrid system and turn the air conditioning system on to
check that the radiator cooling fan operates and to check for
coolant leaks from the radiator or hoses.
The fan operates when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fan is operating by checking the
fan sound and air flow. If it is difficult to check these, turn the air condi-
tioning system on and off repeatedly.
(The fan may not operate in freezing temperatures.)
If the fan is not operating:
Stop the hybrid system immediately and contact your Toyota
dealer.
If the fan is operating:
Have the vehicle inspected at the nearest Toyota dealer.
5
6
7

4858-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U (OM52E68U)■
If the hybrid system overheat warning message is shown on
the multi-information display
Stop the vehicle in a safe place.
Stop the hybrid system and carefully lift the hood.
After the hybrid system has
cooled down, inspect the
hoses and radiator core
(radiator) for any leaks. Radiator
Cooling fan
If a large amount of coolant
leaks, immediately contact
your Toyota dealer.
The coolant level is satisfac-
tory if it is between the “F”
and “L” lines on the reservoir.Reservoir
“F” line
“L” line
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the hybrid system and check for the multi-information dis-
play.
If the message does not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Toyota dealer.
1
2
3
1
2
4
1
2
3
5
6

4868-2. Steps to take in an emergency
PRIUS c_U (OM52E68U)
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injuries such as burns.
● After the hybrid system has been turned off, check that on the
multi-information display and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may automati-
cally start, or the cooling fan may suddenly operate even if the gasoline
engine stops. Do not touch or approach rotating parts such as the fan,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
● Do not loosen the radiator cap whil e the hybrid system and radiator are
hot.
Serious injuries, such as burns, may result from hot coolant and steam
released under pressure.
NOTICE
■ When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■ To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
● Do not use any coolant additive.

4878-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U (OM52E68U)
Shift the shift lever to P and set the parking brake. Stop the hybrid
system.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction.
Restart the hybrid system.
Shift the shift lever to the D or R position and carefully apply the
accelerator to free the vehicle.
■When it is difficult to free the vehicle
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC.
WARNING
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the
surrounding area is clear to avoid striking other vehicles, objects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may
cause an accident resulting in death or serious injury.
1
2
3
4
5

544Alphabetical index
PRIUS c_U (OM52E68U)
Eco drive mode ........................ 197
Electric power steering ........... 232
Electronic keyIf the electronic key does not operate properly ........... 476
Emergency flashers Switch ................................... 430
Emergency, in case of If a warning buzzer sounds........................ 441, 449
If a warning light
turns on .............................. 441
If a warning message is displayed ............................ 449
If the electronic key does not operate properly ........... 476
If the hybrid system will
not start .............................. 473
If the shift lever cannot be shifted from P ................ 475
If the vehicle becomes stuck ................................... 487
If the vehicle 12-volt
battery is discharged .......... 478
If you have a flat tire ............ 462
If you lose your keys ............. 120
If you think something is wrong.................................. 440
If your vehicle has to be stopped in an
emergency.......................... 431
If your vehicle needs to be towed............................. 433
If your vehicle overheats ....... 483 Engine
Compartment ........................ 385
Engine switch ............... 182, 186
Hood ..................................... 382
How to start the hybrid
system ........................ 182, 186
Identification number ............ 491
If the hybrid system will not start .............................. 473
Ignition switch ............... 182, 186
Overheating .......................... 483
“POWER” switch................... 186
Engine coolant Capacity................................ 494
Checking............................... 389
Preparing and checking
before winter ...................... 241
Engine oil Capacity................................ 493
Checking............................... 386
Preparing and checking before winter ...................... 241
Engine/power control unit coolantCapacity................................ 494
Checking............................... 389
Preparing and checking before winter ...................... 241
Engine switch .................. 182, 186
EPS ........................................... 232
EV drive mode ......................... 193
Event data recorder................... 10
Exclusive jump starting terminal .................... 478
E

549Alphabetical index
PRIUS c_U (OM52E68U)
Shift leverIf the shift lever cannot
be shifted from P ................ 475
Transmission ........................ 196
Shift lock system ..................... 475
Side airbags ............................... 38
Side marker lights Replacing light bulbs............. 422
Wattage ................................ 498
Side mirror Adjusting and folding ............ 156
Defogger ............................... 342
Smart key system Entry function ........................ 138
Starting the hybrid
system ........................ 182, 186
Spare tire Inflation pressure .................. 497
Storage location .................... 462
Spark plug ................................ 495
Specifications .......................... 490
Speedometer .............................. 91
Steering
Column lock release ..... 184, 189
Steering wheel Adjustment ............................ 153
Audio switches ...................... 249
Stop lights Replacing light bulbs............. 427
Storage feature ........................ 352
Storage precautions ................ 177
Stuck If the vehicle becomes
stuck ................................... 487
Sun visors ................................ 357 Switch
Cruise control ....................... 218
Eco drive mode switch.......... 197
Emergency flasher switch..... 430
Engine switch ............... 182, 186
EV drive mode switch ........... 193
Fog light switch ..................... 205
Hazard light switch ............... 430
Headlight switch ................... 201
Ignition switch ............... 182, 186
Light switches ....................... 201
Power door lock switch ......... 127
“POWER” switch................... 186
Power window switch ........... 158
Rear window wiper and
washer switch..................... 211
Steering wheel audio switches ............................. 249
VSC OFF switch ................... 233
Window lock switch .............. 158
Wiper and washer......... 207, 211
*: For vehicles with a navigation system, refer to the “NAVIGATION SYSTEM OWNER'S MANUAL”.
