2015 TOYOTA 4RUNNER brake fluid

4107-2. Steps to take in an emergency
4RUNNER (U)_(OM35B18U)
●Fluid leaks under the vehicle.
(Water dripping from the air co nditioning after use is normal.)
● Flat-looking tires or uneven tire wear
● Engine coolant temperature gauge needle continually points higher
than normal.
● Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine
● Engine missing, stumbling or running roughly
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, spon gy feeling, pedal almost touches
the floor
If you think something is wrong
If you notice any of the follow ing symptoms, your vehicle proba-
bly needs adjustment or repair. Contact your Toyota dealer as
soon as possible.
Visible symptoms
Audible symptoms
Operational symptoms

4127-2. Steps to take in an emergency
4RUNNER (U)_(OM35B18U)
If a warning light turns on or a warning
buzzer sounds
Calmly perform the following actions if any of the warning lights
comes on or flashes. If a light comes on or flashes, but then
goes off, this does not necessarily indicate a malfunction in the
system. However, if this continues to occur, have the vehicle
inspected by your Toyota dealer.
Warning light and warning buzzer list
Warning lightWarning light/Details/Actions
(U.S.A.)
(Canada)
Brake system warning light (warning buzzer)*1
• Low brake fluid
• Malfunction in the brake system
This light also comes on when the parking brake is not
released. If the light turns off after the parking brake is
fully released the system is operating normally.
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer. Continuing to drive
the vehicle may be dangerous.
Charging system warning light
Indicates a malfunction in the vehicle’s charging sys-
tem
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer.
Low engine oil pressure warning light
Indicates that the engine oil pressure is too low
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer.
(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control sys-tem
 Have the vehicle inspected by your Toyota dealer
immediately.

4227-2. Steps to take in an emergency
4RUNNER (U)_(OM35B18U)
Indicates a malfunction in the intuitive parking
assist-sensorThe site of the malfunction flashes and stays
on.
A buzzer will sound for several seconds and
this warning message will disappear after sev-
eral seconds.
If the engine switch is turned to a mode other
than IGNITION ON mode and then back to
IGNITION ON mode, the buzzer will sound and
this message will be displayed again.
 Have the vehicle inspected by your Toyota
dealer.
Indicates that one or more of the doors is not fully
closed
If the vehicle reaches a speed of 3 mph (5 km/h), flashes and a buzzer sounds to indicate
that the door(s) are not yet fully closed.
 Make sure that all the doors are closed.
Indicates that the back door is not fully closed
If the vehicle reaches a speed of 3 mph (5 km/h), flashes and a buzzer sounds to indicate
that the back door is not yet fully closed.
 Close the back door.
Indicates that the moon roof is not fully closed
(with the engine switch off, and the driver's door
open)
A buzzer also sounds.
 Close the moon roof.
Indicates that the parking brake is still engaged
If the vehicle reaches a speed of 3 mph (5 km/h),
flashes and a buzzer sounds to indicate
that the parking brake is still engaged.
 Release the parking brake.
Indicates that the washer fluid level is low.
Add washer fluid.
Warning messageDetails/Actions
(Flashes)
(Flashes)
(Flashes)

4537-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35B18U)
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction.
Restart the engine.
Shift the shift lever to D or R position and carefully apply the accel-
erator to free the vehicle.
Turn off TRAC and VSC if these functions are hampering your attempts to
free the vehicle. (P. 261)
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
CAUTION
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the
surrounding area is clear to avoid striking other vehicles, objects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may
cause an accident resulting in death or serious injury.
NOTICE
■To avoid damaging the transm ission and other components
● Avoid spinning the wheels and depressing the accelerator pedal more
than necessary.
● If the vehicle remains stuck even after these procedures are performed,
the vehicle may require towing to be freed.
● When a warning message for the automatic transmission fluid temperature
is displayed while attempting to free a stuck vehicle, immediately remove
your foot from the accelerator pedal and wait until the warning message
disappears. Otherwise, the transmission may become damaged.
(
P. 421)
1
2
3
4
5

4638-1. Specifications
8
Vehicle specifications
4RUNNER (U)_(OM35B18U)
*: The fluid capacity is a reference quantity. If replacement is necessary, con-tact your Toyota dealer.
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,50 kgf) while the engine is running.
*2: Parking brake pedal travel when depre ssed with a force of 67 lbf (300 N,
30 kgf).
Automatic transmission
Fluid capacity*11.3 qt. (10.7 L, 9.4 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■ Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of the transmission accompanied by
vibration and, ultimately, damage to the vehicle’s transmission.
Brakes
Pedal clearance*13.62 in. (92 mm) Min.
Pedal free playLess than 0.04  0.24 in. (1  6 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel*25  7 clicks
Fluid typeSAE J1703 or FMVSS No.116 DOT 3

511Alphabetical index
4RUNNER (U)_(OM35B18U)
Back doorBack door.............................. 114
Back window ......................... 148
Smart key system ................. 103
Wireless remote control .......... 96
Back-up lights Replacing light bulbs............. 395
Wattage ................................ 465
Back window ............................ 148
Battery ...................................... 359 Battery checking ................... 359
If the vehicle battery is discharged ...................... 447
Preparing and checking before winter....................... 268
Warning light ......................... 412
Bottle holders .......................... 302
Brake Fluid ...................................... 356
Parking brake........................ 203
Warning light ......................... 412
Brake assist ............................. 259
Break-in tips ............................. 159
Brightness control
Instrument panel light control................................... 82 Care .................................. 334, 336
Aluminum wheels ................. 334
Exterior ................................. 334
Interior .................................. 336
Seat belts.............................. 337
Cargo capacity......................... 173
Cargo hooks ............................ 303
Cargo net hooks ...................... 304
Center differential lock ........... 235
Chains ...................................... 270
Child restraint system............... 53 Booster seats, definition ......... 54
Booster seats, installation....... 65
Convertible seats, definition ... 54
Convertible seats, installation ............................ 62
Front passenger occupant classification syst em ............ 46
Infant seats, definition............. 54
Infant seats, installation .......... 62
Installing CRS with LATCH anchors ............ 59
Installing CRS with seat belts...................................... 62
Installing CRS with top tether strap.............. 66
BC

514Alphabetical index
4RUNNER (U)_(OM35B18U)
Flat tire...................................... 428
Floor mats .................................. 26
FluidAutomatic transmission......... 463
Brake .................................... 463
Power steering ...................... 464
Washer ................................. 362
Fog lights ................................. 210 Replacing light bulbs............. 383
Switch ................................... 210
Wattage ................................ 465
Four-wheel drive system ............................ 231, 235
Front passenger occupant classification system .............. 46
Front personal lights ............... 294
Front seats ............................... 119
Adjustment ............................ 119
Cleaning................................ 336
Correct driving posture ........... 28
Driving position memory ....... 132
Head restraints ..................... 136
Seat heaters ......................... 291
Seat position memory ........... 132
Seat ventilators ..................... 291
Front side marker lights.......... 204
Light switch ........................... 204
Replacing light bulbs............. 390
Wattage ................................ 465 Front turn signal lights ........... 202
Replacing light bulbs ............ 388
Turn signal lever ................... 202
Wattage ................................ 465
Fuel ........................................... 218
Capacity................................ 458
Fuel gauge.............................. 81
Fuel pump shut off system ... 411
Information............................ 466
Refueling .............................. 218
Type.............................. 218, 458
Warning light......................... 414
Fuel filler door ......................... 218 Refueling .............................. 218
Fuel pump shut off system..... 411
Fuses ........................................ 380
Garage door opener ................ 320
Gauges ....................................... 81
Glove box ................................. 297
Grocery bag hooks.................. 306
F
G

518Alphabetical index
4RUNNER (U)_(OM35B18U)
Parking brake ........................... 203Operation .............................. 203
Parking brake engaged warning buzzer ................... 412
Parking lights ........................... 204 Light switch ........................... 204
Replacing light bulbs............. 388
Wattage ................................ 465
Pen holder ................................ 301
Personal lights ......................... 294
Power back window ................ 148 Jam protection function......... 150
Operation .............................. 148
Power outlets ................... 311, 316
Power steering Fluid ...................................... 358
Warning light ......................... 414
Power windows........................ 145 Door lock linked
window operation ............... 147
Jam protection function......... 146
Operation .............................. 145
Window lock switch............... 145 Radiator .................................... 355
Rear differential lock
system.................................... 243
Rear seats
Adjustment............................ 122
Folding down ........ 124, 126, 128
Rear step bumper .................... 115
Rear turn signal lights ............ 202
Replacing light bulbs ............ 394
Turn signal lever ................... 202
Wattage ................................ 465
Rear view mirror Inside rear view mirror .......... 141
Outside rear view mirrors ..... 143
Rear view monitor system
*
Rear window ............................ 148
Rear window defoggers....................... 280, 286
Rear window wiper .................. 215
Refueling .................................. 218
Capacity................................ 458
Fuel types ............................. 458
Opening the fuel tank cap..... 220
Replacing Fuses .................................... 380
Key battery ........................... 377
Light bulbs ............................ 383
Tires...................................... 428
Reporting safety defects
for U.S. owners...................... 490
Reset the maintenance data ... 340
Roof luggage carrier ............... 168
PR
