2015 MITSUBISHI OUTLANDER III warning

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-25
5
1. Stop the vehicle. 2. Fully engage the parking brake while depressing the brake pedal. 3. Move the selector lever to the “P”(PARK) position, and then press the engine switch to
stop the engine.
N00568301041
Insert the F.A.S.T.-key into the key slot in the instrument panel. St
arting the engine and
changing the operation
mode should be now
possible.
Remove the F.A.S.T.-key from the key slot after starting the engine or changing the oper-ation mode.
Warning display (color liquid crystal display type) Warning light (mono-color liquid crystal dis- play type) If the operation mode is in OFF and the driver’s door is opened with the F.A.S.T.-key in the key slot, a warning is issued with thewarning display and the buzzer buzzing for approximately 3 seconds to remind you to remove the key.
N00514800017 N00515201158
The emergency key is built into the F.A.S.T.- key.
NOTE
 If you have to bring the engine to an emer- gency stop while drivi
ng, press and hold the
engine switch for 3 sec
onds or more, or press
it quickly 3 times or more. The engine will stop and the operation mode will go to ACC.  Do not stop the engine wi
th the selector lever
in any position other than the “P” (PARK) position. If the engine
is stopped with the
selector lever in any
position other than the
“P” (PARK) position, the operation mode will go to ACC rather than OFF.Put the operation mode
in OFF after placing
the selector lever in the “P” (PARK) posi- tion.
If the F.A.S.T.-key is not operat- ing properly

NOTE
 Do not insert into the
key slot anything other
than the F.A.S.T.-key. This could cause dam- age or a malfunction.  Remove the object or
additional key from the
F.A.S.T.-key before inserting the key into the key slot. The vehicle may not be able toreceive the registered ID code from the regis- tered key. Therefore, the engine may not start and the operation mode
may not change.
 The F.A.S.T.-key is fixed in the key slot when inserted in the illustrated direction.Simply pull out the key to
remove it from the
key slot.
F.A.S.T.-key reminder

To operate without using the F. A . S . T. - k e y

Emergency key

BK0211800US.book 25 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Door locks 5-32 Features and controls
5
Turn the key toward the front of the vehicle to lock the door. After checking that the door is locked, turn the key back to the center and remove it.
Move the lock knob to the lock position to lock the door. All doors should be kept locked while driv-ing. The driver’s door can be unlocked without using the lock knob by pulling on the insidedoor handle. 1. Move the inside lock knob to the locked position.
 When closing a door,
make sure that the
door is fully closed
and the door-ajar
warning display goes
out on the informa-
tion screen on the multi-information dis- play. If the door is aj
ar it could open while
driving and caus
e an accident.
To lock and unlock with the key (driver’s door) 1- Insert or remove the key 2- Lock 3- UnlockWA R N I N G
NOTE
 When locking or unlocking with the key, only the driver’s door will be locked orunlocked.To lock or unlock all doors and liftgate, use the power door lock swit
ch, the keyless entry
system or the F.A.S.T.-key operation.Refer to “Power door locks” on page 5-33, “Keyless entry system” on pages 5-7 and 5-28, and “To operate using the F.A.S.T.-key” on page 5-14.  In vehicles equipped wi
th the F.A.S.T.-key,
the driver’s door can be locked and unlocked using the emergency key. Refer to “Emergency key” on page 5-25.
To lock or unlock the door from the inside 1- Lock 2- UnlockTo lock the door without using the key
BK0211800US.book 32 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Power door locks
Features and controls 5-33
5
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549601250
If the ignition switch is turned off and thedriver’s door is opened with the key in theignition switch, the ke
y reminder buzzer will
sound intermittently to remind you to remove the key.The warning display will be displayed on the information screen in
the multi-information
display. (Color liquid crystal display type only)
N00517301052
If the key is in the ignition switch or the oper-ation mode is in any mode other than OFF,when you push the lock knob forward with the driver’s door or passenger’s door open, the lock knob will automatically return to the unlocked position.
N00503801157
If the driver’s door is opened while the engineis stopped and the operation mode is in any mode other than OFF, the operation mode ONbuzzer will sound interm
ittently to remind
you put the operation mode in OFF. The warning display will be displayed on theinformation screen in the multi-information display. (Color liquid crystal display type only)
N00509301617
Key reminder system (except for vehicles equipped with the F. A . S . T. - k e y )
Lock out protection Operation mode ON reminder system (vehicles equipped with F.A.S.T.-key)
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door willlock or unlock.  Repeated continuous
operation between lock
and unlock could acti
vate the power door
locking system’s built
-in protection circuit,
and prevent the system from operating. Ifthis occurs, wait about
1 minute before oper-
ating the power door lock switch.
BK0211800US.book 33 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Power liftgate (if so equipped) 5-38 Features and controls
5
N00576100025
The power liftgate ca
n be opened automati-
cally when all of the
following conditions are
met.  The operation mode is in OFF.  The power liftgate is completely closed.  The power liftgate is unlocked.
 The operation mode is in ON with the selector lever in the “P” (PARK) position.  The power liftgate is completely closed.  The power liftgate is unlocked.
WA R N I N GTo avoid accidental
or unintended opera-
tion of the power li
ftgate, turn off the
power liftgate main switch when not oper- ating the power liftgate. Do not turn off the power liftgate main switch while the power liftgate is opening or closing.CAUTION Do not apply excessive force to the power liftgate when opening
or closing it. Doing so
could damage to the power liftgate.
NOTE
 Do not start the engine while the power lift- gate is operating. The sudden operation pre-vention mechanism c
ould operate, making
the power liftgate stop intermittently while it moves.  The power liftgate
cannot be opened when
the battery is discha
rged or disconnected.
The liftgate must be then opened using theinside liftgate release. Refer to “Inside lift
gate release” on page
5-43.  If the keyless entry system or close switch is operated when the power liftgate mainswitch is off, the warning buzzer sounds 4 times to notify the driver that the power lift- gate cannot
be operated.
 The power liftgate doe
s not operate normally
under the following conditions: • When parked on an incline • In strong winds • When the power liftga
te is covered with
snow
 Repeated continuous
opening and closing
operation of the power lif
tgate will activate a
built-in protection ci
rcuit and switch the
power liftgate to
manual operation.
 If one of the power liftgate switches is oper- ated while the power lift
gate is operating, the
power liftgate will reverse and return to the full open or
close position.
If the selector lever is moved from “P” (PARK) position to another position whilethe power liftgate is operating or completelyopen, a warning buzzer will sound for approximately 10 sec
onds to notify the
driver that the power liftgate is open.  If the battery or fuse is replaced while the power liftgate is open,
it cannot be closed
automatically. In this case close the power liftgate manu- ally.
Operating conditions

NOTE
BK0211800US.book 38 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Power liftgate (if so equipped) Features and controls 5-39
5
 The power liftgate is unlocked.  The F.A.S.T.-key is within the operating range (2.3 feet (70 cm) from the power liftgate open switch) and the power lift-gate is locked.
The power liftgate can be closed automati- cally when all of the
following conditions are
met.  The operation mode is in OFF.  The power liftgate is completely open.  Nothing is touching the auto reverse sen- sors (A) on the power liftgate.

 The operation mode is in ON with the selector lever in the “P” (PARK) position,or the operation mode is in ACC or OFF.  The power liftgate is completely open.  Nothing is touching the auto reverse sen- sors on the power liftgate.
After unlocking the doors and the power lift- gate, the power liftgate can be operated bypressing the switch (A) of the F.A.S.T.-key or the driver’s side power liftgate switch (B).
If the power liftgate switch is pressed twice in a row, the power liftgate operates after the warning buzzer sounds and the hazard warn-ing flasher blinks 2 times. The power liftgate operates as follows:
Operating the power liftgate using the F.A.S.T.-key or the driver’s side power liftgate switch

•While closed: The warning buzzer sounds 4
times and the power liftgate completely opens.
BK0211800US.book 39 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Power liftgate (if so equipped) 5-40 Features and controls
5
If the power liftgate switch is pressed once while the power liftgate is operating, thewarning buzzer sounds
once and the liftgate
will reverse and return to the full open or closed position. If the driver’s side power liftgate switch is pressed for more than 1 second, the power liftgate will operate after the buzzer soundsand the hazard warning
flasher blinks 2 times.
The power liftgate operates as follows.
If the driver’s side power liftgate switch is pressed once while the
power liftgate is oper-
ating, the warning buzzer will sound once and the power liftgate will
move in the direction
opposite to the one in
which it was operating.
The power liftgate can
be opened by pressing
the open switch (C). If the open switch is pressed while the power liftgate and all doors are unlocked, the power
liftgate will open after the warning buzzer sounds 4 times and the hazard warningflasher blinks 2 times. The power liftgate can
be closed by pressing
the close switch (D) on the power liftgate. If the close switch on the power liftgate is pressed, the power liftgate will close after thewarning buzzer sounds 3
times and the hazard
warning flasher blinks 2 times.
•While open: The warning buzzer sounds 3
times and the power liftgate completely closes.
NOTE
 If the power liftgate sw
itch is pressed 3 or
more times in a row, the power liftgate may not operate normally. If this occurs, wait a short time before againpressing the power lift
gate switch twice.
•While closed: The warning buzzer sounds 4
times and the power liftgate completely opens.
•While open: The warning buzzer sounds 3
times and the power liftgate completely closes.
WA R N I N G When operating the
power liftgate, make
sure that there are no people near the power liftgate and that there is sufficient space behind and ab
ove the vehicle.
Opening the power liftgate using the open switch

NOTE
 When you are carrying the F.A.S.T.-key with the power liftgate is locked, the power lift-gate can be opened by pressing the open switch even if the power liftgate is locked.
Closing the power liftgate using the close switch

BK0211800US.book 40 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Power liftgate (if so equipped) Features and controls 5-41
5
If the close switch is pressed once while the power liftgate is clos
ing, the warning buzzer
sounds once and the power liftgate opens.
N00576200026
If the auto reverse sensors (A) on either sideof the power liftgate de
tect that something is
being trapped by the cl
osing power liftgate,
the warning buzzer will sound once and the liftgate will automatically reverse directionand return to the full open position.
After the power liftgate has opened automati- cally, if it is detected that the power liftgate is dropping due to factors such as accumulated snow, the power liftgate will close automati-cally.
A warning buzzer w
ill sound continuously
while the drop prevention mechanism is oper-ating. If the engine is started while the power lift- gate is operating, the power liftgate mayintermittently move
or stop moving to pre-
vent the power liftgate from moving abruptly. Approximately 10 seconds after the powerliftgate has fully closed or opened, power lift- gate operation will again resume.
NOTE
 If the close switch is again pressed once while the power liftgate
is operating in the
opening direction, th
e warning buzzer will
sound once and the power liftgate will close.
Auto reverse

WA R N I N G The auto reverse mechanism will not oper- ate just before the power liftgate becomesfully closed. Therefore, be careful not totrap a hand, part of your body or an object at this time. When the power liftgate is closed manu- ally, the auto reverse mechanism will not operate.  If the auto reverse mechanism has been repeatedly activated
, the power liftgate
may stop and then, de
pending on its posi-
tion, may abruptly open
or close. Once the
power liftgate is completely closed oropen, automatic operation will be resumed.CAUTION Do not damage the auto reverse sensor, when loading or unloading lugga
ge. If the sensor is
damaged, the power liftgate will not close automatically.
Drop prevention mechanism

NOTE
 If snow has accumulate
d on the power lift-
gate, remove it befo
re operating the power
liftgate.  Do not install any acce
ssory other than Mit-
subishi Motors Genui
ne parts on the power
liftgate. The drop prevention mechanism may be activated due to
the weight of the
accessory.  The drop prevention mechanism could be activated if you attempt to close the liftgate manually immediately af
ter the power lift-
gate has been comple
tely opened automati-
cally.
Sudden operation prevention mechanism

BK0211800US.book 41 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Parking brake 5-52 Features and controls
5
N00511401400
To park the vehicle, first bring it to a com- plete stop, fully engage the parking brake,and then move the selector lever to the “P” (PARK) position.
When parking on a hill, set the parking brake, and turn the front wheels toward the curb on a downhill, or away from
the curb on an uphill.
Operating the sunroof repeatedly with the engine turned off will
run down the battery.
Operate the sunroof onl
y while the engine is
running.
Parking brake
NOTE
To apply 1- Pull the lever up without pushing the
button at the end of hand grip. When the parking brake is set and theignition switch is in the “ON” position, the brake warning light in the instru- ment cluster will come on. Before driving, be sure to release the parking brake.
To deactivate 1- Pull the lever up slightly. 2- Press and hold the button at the end of
the hand grip.
3- Push the lever downward.
BK0211800US.book 52 ページ ２０１４年３月１２日　水曜日　午後２時４２分
