Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-157
5
 There is a fault in the automatic transaxle or CVT.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “Automatic tr
ansaxle” on page 5-60.
Refer to “Continuously variable transmission (CVT)” on page 5-67.
 The electronically controll
ed 4WD system is hot. Refer to “Elect
ronically controlled 4WD system” on
page 5-74.
 The S-AWC system is hot. Refer to “S-AWC (Super-All Wheel Control)” on page
5-77.
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining
display screen” on page
5-129.
 The outside temperature is 37 °F (3 °C) or less.
Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so
drive carefully.
 The Adaptive Cruise Control System (ACC) has detected the approach of
the vehicles in front.
 Increase the following distance by depressing the brake pedal or marking ot
her decelerating control.
Refer to “Adaptive Cruise Control System (ACC): Approach alarm” on page 5-100.
 The Forward Collision Mi
tigation System (FCM)
has detected the danger of collision.
 Take appropriate action such as depressing the brake to avoid collision.Refer to “Forward collis
ion warning function” on
page 5-107.
Screen
Cause
Do this (Reference)
BK0211800US.book 157 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-158 Features and controls
5
 The Adaptive Cruise Control System (ACC) detected a stop of the vehi
cle in front and stopped
your vehicle, but the brake
will be released soon.
 Depress the brake pedal as soon as your vehicle comes to a stop.Refer to “When ACC dete
cts a vehicle in front
within the set distance” on page 5-99.
 The Adaptive Cruise Control System (ACC) control is automatically canceled and the system is placed in the ‘standby’ state.
Refer to “How to use ACC” on page 5-98.
 Conditions for the start of control are not met, the Adaptive Cruise Control Sy
stem (ACC) can not start
the control.  The Adaptive Cruise Control System (ACC) can not start the control because th
e speed is out of speed
range.  The Adaptive Cruise Control System (ACC) can not start the control because not
detected the approach of
the vehicles in front.  The Adaptive Cruise Control System (ACC) is tem- porarily unavailable due to conditions such as the adhesion of contaminants to the sensor. This is not a malfunction.
Screen
Cause
Do this (Reference)
BK0211800US.book 158 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-159
5
 There is a fault in the Adaptive Cruise Control Sys- tem (ACC).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “When ACC dete
cts a vehicle in front
within the set dist
ance” on page 5-99.
 There is a fault in the Forward Collision Mitigation System (FCM).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “FCM ON/OFF switch: When a problem is detected” on page 5-109.
 FCM braking function of the Forward Collision Mit- igation System (FCM) has been activated.
Refer to “FCM braking
function” on page 5-107.
 The Forward Collision Mitig
ation System (FCM) is
temporarily unavailable due
to conditions such as the
adhesion of contaminants to the sensor. This is not a malfunction.  The Lane Departure Warn
ing (LDW) has detected
that your vehicle is about to
leave or has left the lane.
Refer to “Lane Departure
Warning (LDW)” on page
5-111.
 The Lane Departure Warni
ng (LDW) is temporarily
unavailable due to too high of a temperature of the LDW camera.
Screen
Cause
Do this (Reference)
BK0211800US.book 159 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-160 Features and controls
5
N00579100026
On vehicles equipped
with Mitsubishi Multi-
Communication System, the following infor- mation on navigation will
be displayed when
guidance location such as junction and desti- nation is approached af
ter you set the destina-
tion and started the route guidance.
 There is a fault in the
Lane Departure Warning
(LDW).
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Lane Departure
Warning (LDW)” on page
5-111.
Screen
Cause
Do this (Reference)
Navigation information display
(if
so equipped)1- Guidance display
Shows the direction of vehicle travel and the guidance location.
2- Remaining distance display
Shows the distance to the location where the guidance is displayed.
Direction of vehicle travel (Example) Destination Ferry terminal Tollbooth Intermediate destination (Example)
NOTE
 Please read this section and also the separate owner’s manual for Mi
tsubishi Multi-Com-
munication System.
BK0211800US.book 160 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-161
5
N00558201278
The operation status of each syst
em is displayed on the informat
ion screen. For furthe
r details, refer to
the appropriate page
for each system.
Other interrupt displays
Screen
System operation status
Reference
 When starting the engine, the selector lever is in a positi
on other than the “P”
(PARK) or the “N” (NEUTRAL) posi-tion, or you pressed the engine switch without depressing the brake pedal.
 Place the selector lever in the “P” (PARK) position, depress and hold the brake pedal with the right foot, and then press the engine switch to start the engine. Refer to “Starting and stopping the engine” on page 5-23.
Screen
System operation status
Reference
 When “4WD ECO” drive mode is selected with the drive mode selector.
Refer to “Electronica
lly controlled 4WD
system” on page 5-74.
 When “4WD AUTO” mode is selected with the drive mode selector.  When “4WD LOCK” mode is selected with the drive mode selector.
BK0211800US.book 161 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-162 Features and controls
5
 When “AWC ECO” mode of S-AWC is selected.
Refer to “S-AWC (Super-All Wheel Con- trol)” on page 5-77.
 When “NORMAL” mode of S-AWC is selected.  When “SNOW” mode of S-AWC is selected.  When “LOCK” mode of S-AWC is selected.  When the ECO mode is ac
tivated. Refer to “ECO m
ode switch” on page 5-177.
Screen
System operation status
Reference
BK0211800US.book 162 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-163
5
This informs you that a periodic inspection is due.
 When the Forward Collision Mitigation System (FCM) is acti
vated or the timing
of an alarm is changed.
Refer to “FCM ON/OFF switch” on page 5-109.
 When the Forward Collision Mitigation System (FCM) is deactivated.  When the operation mode of the Lane Departure Warning (LDW) is switched.
Refer to “Lane Departure Warning (LDW): Turning off the LDW” on page 5-112.
Screen
Do this
Have an inspection made by an authorized Mi
tsubishi Motors dealer
. For further details,
refer to “Service remin
der” on page 5-130.
Screen
System operation status
Reference
BK0211800US.book 163 ページ ２０１４年３月１２日　水曜日　午後２時４２分

Indicator light, warning light, and information screen display list (multi information display - Type 1) 5-164 Features and controls
5
The rest time can be set.
Screen
Do this
Park the vehicle in a safe place, tu
rn off the engine,
and take a rest.
Use this display as rough guide
for taking rests during a long drive.
The interval from the start of your trip
until this message is
displayed can be set.
Refer to “Changing the function settings” on page 5-134. The display and buzzer alert the driver when th
e set time is reached.
If you continue to drive
without having a rest, the buzzer sounds about
every 5 minutes to encourage you to take a
rest.  In the following cases, the time driven is reset and the display returns to the previous display screen. After this, when the set time
is reached again,
the display and buzzer
encourage you to take a rest. • The buzzer sounds 3 times.• The ignition switch is turned to the “OFF”
or “LOCK” position or the operation mode
is put in OFF. • The multi information display switch is
held (for about 2 seconds or more).
