2015 LEXUS LX570 display

5213-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Changing the angle (if the angle option is available)
Touch “Angle” on the “DVD Options” screen.
Each time you touch “Change”,
the next available angle is
selected. The angles available are restricted
to those available on the DVD disc.
: Returns to the previous
screen
Changing screen size
Touch “Wide” on the “DVD Options” screen.
Touch the desired display. After
setting, touch “Save”.
Displays a 3 : 4 screen, with
either side in black
Widens the 3 : 4 screen hori-
zontally to fill the screen
Widens the 3 : 4 screen verti-
cally and horizontally, in the
same ratio, to fill the screen : Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

5223-3. Using the audio system
LX570_OM_OM60L96U_(U) Adjusting the screen
Touch “Display” on the “DVD Options” screen.
Touch “<” or “>” to display the
desired item to be adjusted, and
then touch “OK”. The screen goes off when “Screen
Off” is touched. To turn the screen
back on, press any button. The
selected screen appears.STEP 1
STEP 2
R G
Color Red Green
- +
Tone Lighter Darker
Contrast Weaker Stronger
Brightness Darker Brighter

5233-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Initial DVD settings
■ Displaying “DVD Settings” screen
Touch “DVD Settings” on the “DVD Options” screen.
Touch the setting to be changed.
After you change the settings,
touch “Save”. “Default”: Restores default settings
: Returns to the previous
screenSTEP 1
STEP 2

5283-3. Using the audio system
LX570_OM_OM60L96U_(U) Setup operation from the rear seat (vehicles with rear seat entertain-
ment system)
Touch “Play” to cancel this setup
operation from the rear seat. This screen appears when a rear
passenger setting selects the setup
menu.Code Language Code Language Code Language
2023 Twi 2209 Vietnamese 2515 Yoruba
2111 Ukrainian 2215 Volapük 2621 Zulu
2118 Urdu 2315 Wolof
2126 Uzbek 2408 Xhosa
■
When a rear passenger selects set up menu
Follow the directions on the wa rning screen that is displayed.
Under the same condition, the rear passenger can cancel the set up operation from
the front seat. ■
Rear system lock
 P. 582■
Error messages
If “Region Code Error” is displayed, ch eck if the region code printed on the DVD
matches the player’s region code.
If a different message is displayed:  P. 529

5303-3. Using the audio system
LX570_OM_OM60L96U_(U) ■ DVD video discs
● The DVD player conforms to NTSC/PAL color TV formats. DVD
video discs conforming to anoth er format such as SECAM cannot
be used.
● Region code: Some DVD video disc s have a region code indicating
the region in which you can use the DVD video d isc. If the DVD
video disc is not labele d as “ALL” or “1”, yo u cannot use it on this
DVD player. If you attempt to play an inapp ropriate DVD video disc
on this player, “Region Code Erro r” appears on the screen. Even if
the DVD video disc does not ha ve a region code, you may not be
able to use it. ■
Symbols shown on DVD video discs
Symbol Meaning
NTSC/PAL Indicates NTSC/PAL format of color TV
Indicates the number of audio tracks
Indicates the number of language subtitles
Indicates the number of angles
Indicates the screen display ratios available
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s region code
ALL: in all countries
Number: region code

5413-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Listening to Bluetooth ®
audioThe Bluetooth ®
audio system enables users to enjoy music played on a
portable player from the vehicle speaker via wireless communication.
This audio system supports Bluetooth ®
, a wireless data system capable of
playing portable audio music without ca bles. If your portable player does
not support Bluetooth ®
, the Bluetooth ®
audio system will not function.
Press the “AUDIO” button if a Bluetooth ®
audio player has already been
connected.
Touch the “BT Audio” tab or press th e “AUDIO” button repeatedly until
the “BT Audio” tab is selected.
Random
playbackRepeat play
Audio control
screen display
button
Track selection/fast forward/rewindVolumePower Connection status
Play/pause Setting the sound
(  P. 572)Connecting Bluetooth ®
audio player
Track selection Play/pauseDisplays
folder/
album listDisplays
track listFolder/
album selec-

5423-3. Using the audio system
LX570_OM_OM60L96U_(U) Status display
You can check such indicators as si gnal strength and battery charge on
the screen.
Connection status
Battery charge
Indicators Conditions
Connection status Good No
connection
Battery charge Full Empty

5443-3. Using the audio system
LX570_OM_OM60L96U_(U) Touch the desired portable player.
When the connection is com-
pleted, this screen is displayed. It is
now possible to use the portable
player.STEP 2
STEP 3
